Abocom CAS3047 Quick Installation Manual

Broadband router (with 4-port etherswitch)

BroadBand

Figure 1

1-1. Connect the power adapter to this product and power it on.

The LED of Power will illuminate after this step.

1-2. Apply the UTP cable to connect your Cable/DSL modem to this product's Internet port.

The LED of Internet will illuminate after this step.

1-3. Use a network cable to connect your PCs' Ethernet ports to one of this product's LAN (1

to 4) ports.

The LED of LAN port you plugged into will illuminate after this step.

Note: To configure this device, you must have IE 4.01 or above installed.

1. Load the setup CD-ROM onto your computer. The auto-execution file will start

automatically.

(with 4-Port EtherSwitch)

Quick Installation Guide

Router

- 1-

M73-APO07-480

Table of Contents

Do you have a question about the CAS3047 and is the answer not in the manual?

Page 1: Quick Installation Guide
BroadBand (with 4-Port EtherSwitch) Quick Installation Guide STEP 1: CABLING Figure 1 1-1. Connect the power adapter to this product and power it on. The LED of Power will illuminate after this step. 1-2. Apply the UTP cable to connect your Cable/DSL modem to this product’s Internet port. The LED of Internet will illuminate after this step.
Page 2 Select Quick Setup Wizard. 3. The self-explanatory wizard will guide you through the installation procedure. Follow the on-screen instruction to proceed. STEP 3: CHECKING THE INTERNET CONNECTION You can open a new web browser to surf the Internet now. Should the access fail, you can check by the following steps: 3-1.
