Abocom BUD200 Specification

Bluetooth Dongle
Plug-n-Play,
No software needed!
For your quality Stereo musical enjoyment
on PC/NB!

DESCRIPTION

The Bluetooth USB Audio Dongle, BUD200 is a wireless device, which connected to the USB port of a
PC/NB. It works automatically as your default sound card when plugged into your PC/NB. Yes, no
software installation required! Just like a breeze, it will automatically search its Bluetooth counterpart,
BSH201/202/203 for auto pairing and connection. You just enjoy a quality stereo music sounds from
your PC/NB.

FEATURES

Plug-n-Play, no software needed for PC/NB
Automatically pairs with AV stereo headset, and connected
Windows 2000, XP compatible

SPECIFICATION

Standards
Frequency Band
Tx Power
Rx Sensitivity
Distance
Physical Specification:
Environmental Range:
Certifications:
Audio Streaming Format SBC 48.000kHz
Audio Frequency Range

USER INTERFACE SPEC

LED
2005-5-09
Bluetooth specification V1.2 compliant
Bluetooth A2DP profile
Bluetooth AVRCP profile
2402 ~ 2480 MHz
0.25 ~ 2.5mW (Bluetooth Power Class II)
< -80dBm (BER 0.1%)
> 10m (open space)
Dimension: 69.53 x 26.68 x 9.19 mm (LxWxH)
Weight: 10g
Operating temperature:-10 ~ +50℃
Humidity: Relative humidity 0 ~ 95%
FCC, CE, BQB
20Hz ~ 22kHz
Discovery: Green on
Connected: Green slow blinking
