Abocom Bluetooth USB Dongle UBT3KH Specification Sheet

DESCRIPTION

The Bluetooth USB Dongle, UBT3KH is class 1 wireless
device which eliminates proprietary cables , allows you
to connect with your entire enable Bluetooth device such
as phones, PCs, PDA, Printer, Laptop, web pad., it will
automatically search its Bluetooth counterpart, allowing
mobile user to connect to mobile operating devices
wirelessly and effortlessly .

FEATURES

Bluetooth Specification V2.0 compliant
Class1 transmission range up to 100 meters
Supports Bluetooth software BTW5.0
AFH (Adoptive Frequency Hopping)
ESCO (Enhanced SCO) for voice quality
Easy to use-makes wireless networking simple
Easy to follow-friendly user interface provides an easy way to connect other Bluetooth devices

SPECIFICATION

Standards
Frequency Band
Tx Power
Rx Sensitivity
Distance
Output Interface
Compatible OS
Physical Specification:
Environmental Range:
Certifications:
Certifications:
2005-12-28
Bluetooth specification V2.0 compliant
EDR (Enhance Data Rate)
2402 ~ 2480 MHz
1 ~ 100mW (Bluetooth Power Class I)
< -80dBm (BER 0.1%)
> 100m (open space)
USB 2.0
Microsoft Windows 98SE/2000//ME/XP
Dimension: 65.5 x 19 x 8 mm (LxWxH)
Weight: 10g
Operating temperature:-10 ~ +50℃
Humidity: Relative humidity 0 ~ 95%
FCC, CE, BQB
FCC, CE, BQB
