Abocom ARM914 Quick Installation Manual

802.11g Wireless Router
Check for Packing List:
1. One Wireless G BroadBand Router
2. One Power Adapter
3. One Ethernet Network Cable
4. One Set-up CD-ROM with User's
Guide
5. One Quick Installation Guide
Application Diagram
Connect the 802.11g Wireless
Router
Before you begin, ensure that the Wireless
Router, the DSL/Cable modem
your IP Provider, and PC are turned off.
Existing Connection

Quick Installation Guide

Before setting up the Wireless Router, make sure your
PCs are configured to "Obtain an IP (or TCP/IP) address
automatically".
For Windows 98/ME/Macintosh
Please refer to the User' s Guide found on the CD.
For Windows 2000 & XP
1. Go to Start
2. Make sure the box next to Internet Protocol (TCP/IP)
supplied by
3. Select "Obtain an IP address automatically".
4.
1
Connect your DSL/Cable Modem to the
Internet port on the Wireless Router using a
standard RJ-45 Ethernet cable.
Connect an Ethernet cable to one of the LAN
ports on the back of the Wireless Router to
the Ethernet port on your PC.
Turn on the DSL/Cable modem first.
Then turn on your wireless router.
Check the LEDs:
• The Power, Internet, and WLAN LEDs
should be ON.
• For each active LAN (PC) connection, the
LAN Activity LEDs (1-4) should be ON.
Turn on your PC.
Notes
Control Panel
Connections (Right-click
Connection Properties.
is checked. Click the Internet Protocol (TCP/IP) and
click the Properties button.
Select "Obtain DNS server address automatically".
Then click OK to complete the PC configuration.
Restart your computer.
Router Configuration
(for Internet Access)
For Windows 2000 & XP users, your computer
should obtain an IP Address automatically from
the Wireless Router' s DHCP Server, after you' ve
done the above steps and restarted your computer.
Network and Internet
on) Local Area
