System Status Chirps

Action Number of Chirps
Arm 1
Arm 1 (3 second delay), 1
Disarm 2
Disarm 4
Disarm 5

Table of Zones

Zone No. Trigger type
1 Instant
2 On-board shock sensor
3 Door switch: two-stage
or instant
4 Multiplexed Input
5 Two-stage (similar to doors)
NOTE: The Warn Away
Long Term Event History
The system stores the last two full triggers in memory. These are not erasable. Each time the unit
sees a full trigger, the older of the two triggers in memory will be replaced by the new trigger. To
access long term event history:
1. With the ignition off, press and HOLD the Valet/Program switch.
26
Description
System armed
System armed with Bypass Notification
System disarmed
System disarmed with Tamper Alert
System disarmed FACT active
Input description
H1/6 BLUE - Connect to optional hood/trunk pins.
Heavy impact detected by the on-board shock
sensor.
H1/5 GREEN or H1/7 VIOLET door switch
BLUE and ORANGE wires of optional sensor
plug. Inputs shorter than 0.8 seconds will trigger
a Warn Away response, while inputs longer than
0.8 seconds will instantly trigger a full alarm
sequence and report Zone 4.
Ignition input. H1/9 YELLOW.
response does not report on the LED.
®
