IBM System x3100 M3 Product Manual page 8

Outstanding value in a high-performance single-socket tower
server
Memory access rate
Memory interleaving
DIMM capacities supported
# of DIMM sockets total / available
# of DIMMs supported
Chipkill protection supported
# of drive bays total / available
# of 3.5-inch HDD drive bays total /
available
# of 5.25-inch bays total / available
Maximum HDD capacity
HDD capacities supported
# of HDDs standard
# of optical drives standard / optional
# of floppy drives standard
Internal backup supported
Internal backup standard
Disk drive technology
Integrated disk controller
Integrated RAID controller
Optional RAID controllers supported
External disk drives supported
# of adapter slots total / available
# of PCIe x16/x8 Gen 2 slots (8GBps)
# of PCIe x8/x8 Gen 2 slots (8GBps)
# of PCIe x4/x4 Gen 1 slots (2GBps)
# of 32-bit PCI 5V legacy slots
# of video ports
Video controller
Video memory
Maximum video resolution at 32-bit
color
6
x16/x8 Gen 2 slots can accept x1, x4, x8, or x16 Gen 1 or Gen 2 adapters running at x1, x4, x8 or x8 throughput, respectively.
7
x8/x8 Gen 2 slots can accept x1, x4 or x8 Gen 1 or Gen 2 adapters running at x1, x4 or x8 throughput, respectively.
8
x4/x4 Gen 1 slots can accept x1 or x4 Gen 1 adapters running at x1 or x4 throughput, respectively.
Please see the Legal Information section for important notices and information.
x3100 M3 Specifications
6 / 4 (optical, 1HDD installed)
4 / 3 (22x, B2x)
1 x 250GB (22x, B2x)
1 DVD-ROM (in dedicated 5.25" bay) / DVD-RW
1 half-high (5.25-inch or 3.5-inch) DDS-5 or DDS-6 tape drive (SATA or USB); or
1 RDX Removable Disk Cartridge drive (SATA or USB); or
IBM Half-High 400/800GB LTO-3 (SAS)
ServeRAID-BR10il V2 (no cache)—
RAID-0/1/1E (D2x)
IBM 3Gbps SAS HBA v2 (no cache)—internal RAID-0/1 for SATA HDDs and
SAS/SATA tape drives; external RAID-0/1/1E for SAS/SATA HDDs and tape drives
6
7
8
1333MHz (62x, B2x, D2x)
1066MHz (22x, 42x)
Yes (two-way, with 2 or 4 DIMMs)
1GB, 2GB, 4GB UDIMMs
4 / 3
1, 2, or 4
No
6 / 3 (optical, 2 HDDs installed)
4 / 2 (42x, 62x, D2x)
2 / 1 (optical drive installed)
4TB (4 x 1TB)
3.5-inch SATA II
250, 500, 1TB — 7,200 RPMs
2 x 250GB (42x, 62x, D2x)
None (optional USB)
None
Fixed SATA II
4-port SATA II (via chipset)
RAID-0/1 via chipset (all other models)
No
4 / 4
1 full-height/half-length
1 full-height/full-length
1 full-height/full-length
1 full-height/full-length
1 (rear)
Shared with BMC
32MB DDR2 SDRAM
1024 x 768 x 32-bit color at 85Hz
8
