ANT-TAG Device/Asset Tag
The ANT-TAG Device/Asset Tag (FG5172-01) attaches to devices to identify and track location, and
trigger system events (FIG. 4). .
FIG. 4
ANT-TAG Device/Asset Tag
Attach the ANT-TAG to a stationary or mobile asset to monitor the location of the asset. A tagged asset
may be a non-controllable object not traditionally connected to a Master Control System, or a mobile
device that is regularly moved throughout a facility.
ANT-TAG Product Specifications
ANT-TAG Specifications
RF Specifications:
Electrical Specifications:
Environmental:
Enclosure:
Dimensions (HWD):
Weight:
Certifications:
Anterus RFID Solution
• Tx Frequency: 433 Mhz
• Field strength: < 1600 µV/m
• Modulation: ASK
• Stability: Saw Stabilized
• External Antenna
• Power: Internally powered Lithium Battery (non-replaceable)
• Battery Life span: approximately 5 years.
Note: All of the Anterus RFID tags run on non-replaceable batteries, which
provide approximately five years of normal use. Additional and replacement tags
are available from AMX. Contact your customer service representative for
details.
• Operational temperature: 32º F to 140º F (0º C to 60º C)
• Storage temperature: -4º F to 158º F (-20º C to 70º C)
• Humidity: 5% to 90% (non condensing)
• ABS (ultrasonically sealed) IP 65
• Charcoal Grey
2.52" x 1.18" x .35" (64 mm x 30 mm x 9 mm)
0.8 oz. (22.68 grams)
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
• This device may not cause harmful interference, and,
• This device must accept any interference received, including interference that
may cause undesired operation.
The following standards applied in accordance with Article 5 of the directive,
1999/5/EC:
• EN 300 220-1 V1.2.1 (1997-11)
• ETS 300 683 (1997-03)
Any modification of this device without the express consent of the manufacturer
could void the user authority to operate the equipment.
Anterus™ RFID Solution
5
