Adding a Tag to the System

1. Click the Add Tag button in the bottom-left corner of the Global Register page (FIG. 21) to add a
new RFID Tag to the system.
FIG. 21 Add Tag button
This invokes a set of fields for the new Tag at the bottom of the page (FIG. 22):
FIG. 22 New tag fields
2. Enter a Tag ID.
3. Enter a Tag Name.
4. Enter Tag Info.
5. Enter the desired Acquired Threshold value for the new tag.
6. Click on the Accept button to enter the newly defined tag into the Anterus system.

Removing a Tag from the System

In either the Global Register Page or the Reader Configuration Page (see below), click on the Delete
icon for any Tag (see FIG. 23 on page 22). Once deleted, the Tag is permanently removed from the
system.
Anterus RFID Solution
Click to add a new Tag
Tag ID Name
Anterus Configuration Manager
Acquired Threshold
Info
