Wifi Configuration - First Alert ReadyGuard Touch User Manual

USER FUNCTIONS USER FUNCTIONS USER FUNCTIONS USER FUNCTIONS

WiFi Configuration

View/Join Available WiFi Networks
Ready To Arm
Users
Events
Date Time Reminders
Ready To Arm
Scan Access Points
Manual Configure AP
Ready To Arm
SSID = Vtek, RSSI = -62dbm
SSID = JimC, RSSI = -66dbm
SSID = Toms_net, RSSI = -86dbm
Edit Scan
System Programming...
SSID Name
Toms_net
Security Network Type
WPA1 Infrastructure
Key
* * * *
Join
Test Keypad
Slide Show WiFi Config
Back
5100-100-006-V0
5100-100-032-V0
5100-100-085-V0
Save
5100-100-086-V0
1. At the Master User screen select the WiFi
Config icon. The system displays the WiFi
options screen.
2. Select the "Scan Access Points" button to
view the available networks. The available
networks are displayed. Use the down
arrow to scroll to the next page of options.
Use the arrow to return to the previous
page.
3. Select the desired Network and then select
the "Edit" button. The network information is
displayed. If a password is required, select the
"Key" button and enter the password.
4. Select the "Join" button. A confirmation screen
will be displayed.
5. Select the "Save button, then select the " "
button as required to return to the Master
User screen.
– 62 –
