Troubleshooting

This trouble shooting guides cover some CleanMate problems that you might
have.
If problem persists, please contact your local warranty provider or
www.infinuvo.com for further assistance.
The repairs that marked * needs to be done by qualified service personal.
Problem Symptoms Possible Cause
Battery installation problem
Both ERROR & LOW BATT
indicators are on. (Page 6)
Battery malfunction
CleanMate is lifted off ground over 3
seconds while running
ERROR indicator on
CleanMate is stuck
LOW BATT indicator on Battery power is low
Can not power on the home
Malfunction charging base
charging base
Home base LCD display
Malfunction LCD display on home base Replace the LCD on charging base. *
malfunction (scheduler version
only)
Can not dock on the home Malfunction charging base
charging base Malfunction sensor on CleanMate unit Repair the CleanMate main unit *
Fall down steps or stairs Malfunction cliff sensors
Always turning in circles to left Left wheel stuck or malfunction
Always turning in circles to right Right wheel stuck or malfunction
Bumper protection pads not removed Remove bumper protection pads
Always going backwards
Malfunction front bumper sensor
Malfunction control board
Too much debris & hairs on brush
Main roller brush stuck
Malfunction brush motor
Too much debris & hairs on brush
Side brush stuck
Malfunction brush motor
Remote control battery bad
Remote control does not work
Remote control defective
QQ2 LT Series
Things to do
Make sure battery has good contact with charging
stripes, and battery lifting band faces up.
Charge battery manually for 2 days (see Page 10)
or replace battery.
Put the CleanMate back on to the ground.
Remove deris & hairs from brushes and wheels
Recharge the CleanMate battery
Replace the charging base
Replace the charging base *
Repair the CleanMate main unit *
Clean or replace left wheel
Clean or replace right wheel
Clean or replace front bumper sensor *
Replace control board *
Remove debris & hairs from roller brush. Replace
the roller brush if necessary
Replace brush motor *
Remove debris & hairs from side brush. Replace
the side brush if necessary
Replace brush motor *
Replace the button battery in the remote control .
Replace the remote control
Please fill in your warranty card completely and submit it to your local
customer service center.
Infinuvo provides you, as the owner of this Infinuvo product, with the
following Limited Warranty Policy.
One year Product Warranty:
Infinuvo warrants to the original purchaser of this Infinuvo product that the
product is free from defects in original materials and workmanship for a
period of up to one year from the date of initial purchase. This warranty is
only valid if the product has been properly installed and is used in the way
for which it is intended, and has received only factory-authorized repairs,
servicing or alterations.
Under-warranty products that meet these conditions and that function
improperly will be repaired or replaced, at the discretion of Infinuvo.
Six months Battery Warranty:
Infinuvo warrants to the original purchaser of this Infinuvo product that
the original batteries contained within this product will function for a
period of six months. This warranty is only valid if the product has been
properly installed and is used in the way of which it is intended, and has
received only factory-authorized repairs, servicing, or alterations.
Under-warranty batteries that meet these conditions and that function
improperly will be repaired or replaced, at the discretion of Infinuvo.
These warranties contain the sole express warranty of Infunuvo, which
makes no other warranties, expressed or implied. These warranties are
made in lieu of any implied warranties of merchantability or fitness for a
particular purpose. These warranties give you specific legal rights. You
may also have other rights, which vary from state to state.
WHEN YOU RETURN A CLEANMATE PRODUCT OR BATTERY
UNDER THIS WARRANTY, you must first obtain an RMA number by
calling your local customer service center or www. infinuvo.com
Infinuvo reserves the right to request that you submit a letter describing
the circumstances under which the problem occurred and that you submit
invoice and any other supporting evidence and documentation.
