MaxLoader User's Guide
76
After inserting a memory device into the ZIF socket, select the memory type
from the device select "GENERIC RAM" selection screen and click on the
RAM test button, in the test menu.
The program will test each address of the memory. A "Defective memory"
message will be displayed with a current address if the memory has a defective
bit. "Good memory" will appear when the test has passed successfully.

Test / Vector Test

Verifies that the PLD (PAL, GAL EPLD, etc.) currently behaves without
having to prototype a circuit. In order to perform test vectors, test vectors
should be in the JEDEC file when the file is loaded. Most PLD development
software will generate valid test vectors automatically. Test vectors may be
examined and modified with Vector Pattern Edit/^F6 command in the buffer
menu screen.
