19.2V 2-speed drill
set up and Operating instructiOns
distributed exclusively by Harbor Freight tools
Visit our website at: http://www.harborfreight.com
read this material before using this product.
Failure to do so can result in serious injury.
saVe tHis manual.
©
Copyright
2008 by Harbor Freight Tools
contained herein may be reproduced in any shape or form without the express written consent of
Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein. Tools required for
assembly and service may not be included.
For technical questions or replacement parts, please call 1-800-444-3353.
3491 Mission Oaks Blvd., Camarillo, CA 93011
®
. All rights reserved. No portion of this manual or any artwork
65756
®
.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 65756 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Chicago Electric 65756

Summary of Contents for Chicago Electric 65756

  • Page 1 19.2V 2-speed drill 65756 set up and Operating instructiOns ® distributed exclusively by Harbor Freight tools 3491 Mission Oaks Blvd., Camarillo, CA 93011 Visit our website at: http://www.harborfreight.com read this material before using this product. Failure to do so can result in serious injury.
  • Page 2 SKU 65756 For technical questions, please call 1-800-444-3353. Page 2...
  • Page 3 Eye protection injury. must be ANSI-approved and breath- use personal protective equip- ing protection must be NIOSH-ap- ment. always wear eye protection. SKU 65756 For technical questions, please call 1-800-444-3353. Page 3...
  • Page 4 Properly maintained cutting This will ensure that the safety of the tools with sharp cutting edges are power tool is maintained. less likely to bind and are easier to control. SKU 65756 For technical questions, please call 1-800-444-3353. Page 4...
  • Page 5 1 foot away from all designed to filter out microscopic flammable objects, such as drapes or SKU 65756 For technical questions, please call 1-800-444-3353. Page 5...

  • Page 6: Vibration Safety

    Raynaud’s Disease should not use Amperes this tool. If you feel any medical or No Load Revolutions per Minute physical symptoms related to vibra- n 0 xxxx/min. (RPM) tion (such as tingling, numbness, and SKU 65756 For technical questions, please call 1-800-444-3353. Page 6...

  • Page 7: Specifications

    Drill Bit in the beginning of this manual place. (see Figure a on page 8) including all text under subheadings therein before set up or use of this product. REV 09b SKU 65756 For technical questions, please call 1-800-444-3353. Page 7...
  • Page 8 (26) into the a 120 volt, electrical out- let. (see Figure a.) auxiliarY deptH Handle gauge cHucK (11) tOrQue selectOr ring CHARGE trigger INDICATOR (19) LIGHT BatterY pacK (22) FIGURE A SKU 65756 For technical questions, please call 1-800-444-3353. Page 8...

  • Page 9: Operating Instructions

    If possible, install the Side Handle (21) to allow better control of the drill. If desired, insert the Depth Gauge (25) through the hole in the BATTERY PACK (22) Side Handle. The Depth Gauge (25) SKU 65756 For technical questions, please call 1-800-444-3353. Page 9...
  • Page 10 Drill Bit breaks through full charge. Red and Yellow Lights the workpiece. illuminated means the Battery Pack Figure c speed selectOr red ligHt green ligHt leVel YellOW ligHt ligHt actiVatOr SKU 65756 For technical questions, please call 1-800-444-3353. Page 10...
  • Page 11 Also, make sure the springs operate freely. SKU 65756 For technical questions, please call 1-800-444-3353. Page 11...

  • Page 12: Parts List

    ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF RE- PLACEMENT PARTS THERETO. SKU 65756 For technical questions, please call 1-800-444-3353. Page 12...

  • Page 13: Assembly Diagram

    SKU 65756 For technical questions, please call 1-800-444-3353. Page 13...

  • Page 14: Limited 90 Day Warranty

    If product has no serial number, record month and year of purchase instead. note: Some parts are listed and shown for illustration purposes only, and are not avail- able individually as replacement parts. SKU 65756 For technical questions, please call 1-800-444-3353. Page 14...
