Owner's Manual & Safety Instructions
Save This Manual
operating, inspection, maintenance and cleaning procedures. Write the product's serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference.
18 VOLT CORDLESS
DRILL/DRIVER
WITH 1/2" CHUCK
REV 14h
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
©
Copyright
2014 by Harbor Freight Tools
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Keep this manual for the safety warnings and precautions, assembly,
Visit our website at: http://www.harborfreight.com
Email our technical support at: productsupport@harborfreight.com
®
. All rights reserved.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
ITEM 62427
Advertisement
Table of Contents
Related Manuals for Chicago Electric ITEM 62427
Summary of Contents for Chicago Electric ITEM 62427
- Page 1 (or month and year of purchase if product has no number). Keep this manual and the receipt in a safe and dry place for future reference. ITEM 62427 18 VOLT CORDLESS DRILL/DRIVER WITH 1/2"...
-
Page 2: Table Of Contents
2. Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes. Page 2 For technical questions, please call 1-888-866-5797. Item 62427... -
Page 3: Electrical Safety
Power tools are dangerous in the hands of untrained users. Item 62427 For technical questions, please call 1-888-866-5797. Page 3... -
Page 4: Drill Safety Warnings
Battery Pack is connected. Turn off the tool, physician(s) before use. Electromagnetic fields in and remove the Battery Pack before leaving. close proximity to heart pacemaker could cause pacemaker interference or pacemaker failure. Page 4 For technical questions, please call 1-888-866-5797. Item 62427... -
Page 5: Vibration Safety
If any abnormal as tingling, numbness, and white or blue fingers), vibration occurs, stop use immediately. seek medical advice as soon as possible. SAVE THESE INSTRUCTIONS. Item 62427 For technical questions, please call 1-888-866-5797. Page 5... -
Page 6: Extension Cords
WARNING marking concerning of Eye Injury. Wear ANSI-approved Risk of Explosion. safety goggles with side shields. Do not puncture, short, or open battery packs and do not charge damaged battery packs. Page 6 For technical questions, please call 1-888-866-5797. Item 62427... -
Page 7: Specifications
Specifications Charger Input Rating 120V~ / 60Hz Battery Rating 18V / 1500mAh Battery Type NiCd No Load Speed 0-400 / 0-1200 RPM Chuck Size 1/2" 3160002 Item 62427 For technical questions, please call 1-888-866-5797. Page 7... -
Page 8: Setup
Red LED: Flashing indicates that the battery is charging. Continuously lit (not flashing) indicates that the battery has finished charging and should be removed from the charger. Green Charger Page 8 For technical questions, please call 1-888-866-5797. Item 62427... -
Page 9: Operation
NOTICE: Use sharp bits. Dull, bent, or damaged forward and back to adjust from the lower speed bits will cause stress on the drill and/or break. (0-400 RPM) to the higher speed (0-1200 RPM). Item 62427 For technical questions, please call 1-888-866-5797. Page 9... - Page 10 (not included) to prevent movement while working. or pets to prevent distraction and injury. 3. There must not be objects, such as utility lines, nearby that will present a hazard while working. Page 10 For technical questions, please call 1-888-866-5797. Item 62427...
-
Page 11: General Operating Instructions
11. To prevent accidents, turn off the tool and remove its Battery Pack after use. Clean, then store the tool indoors out of children’s reach. Item 62427 For technical questions, please call 1-888-866-5797. Page 11... -
Page 12: Maintenance
• any other condition that may reach of children and away from metal objects affect its safe operation. (i.e., paperclips, coins) to prevent shorting. Page 12 For technical questions, please call 1-888-866-5797. Item 62427... -
Page 13: Troubleshooting
NIOSH-approved dust mask/respirator while blowing dust out of motor using compressed air. Follow all safety precautions whenever diagnosing or servicing the tool. Disconnect Battery pack and Charger power supply before service. Item 62427 For technical questions, please call 1-888-866-5797. Page 13... -
Page 14: Parts List And Diagram
Note: If product has no serial number, record month and year of purchase instead. Note: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. Page 14 For technical questions, please call 1-888-866-5797. Item 62427... -
Page 15: Assembly Diagram
Assembly Diagram Item 62427 For technical questions, please call 1-888-866-5797. Page 15... -
Page 16: Warranty
Limited 90 Day Warranty Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase.
