Owner's Manual & Safety Instructions
Save This Manual
inspection, maintenance and cleaning procedures. Write the product's serial number in the back of the manual
near the assembly diagram (or month and year of purchase if product has no number). Keep this manual and
the receipt in a safe and dry place for future reference.
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-800-444-3353 as soon as possible.
©
Copyright
2012 by Harbor Freight Tools
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Keep this manual for the safety warnings and precautions, assembly, operating,
Visit our website at: http://www.harborfreight.com
Email our technical support at: tech@harborfreight.com
®
. All rights reserved.
Read this material before using this product.
Failure to do so can result in serious injury.
SaVE thiS manual.
ITEM 67616
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Chicago Electric 67616
Summary of Contents for Chicago Electric 67616
- Page 1 Tools required for assembly and service may not be included. ® . All rights reserved. Read this material before using this product. Failure to do so can result in serious injury. SaVE thiS manual. ITEM 67616...
-
Page 2: Table Of Contents
Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury. Addresses practices not related to personal injury. 3. Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control. Item 67616... -
Page 3: Electrical Safety
A wrench or a key left attached to a rotating part of the power tool may result in personal injury. Item 67616 For technical questions, please call 1-800-444-3353. 4. Do not abuse the cord. never use the cord for carrying, pulling or unplugging the power tool. -
Page 4: Hammer Drill Safety Warnings
4. let bit cool before touching, changing or adjusting it. Bits heat up dramatically while in use, and can burn you. 5. if the drill bit jams, release the trigger immediately; drill torque can cause injury or break bit. 6. maintain labels and nameplates on the tool. -
Page 5: Vibration Safety
SaVE thESE inStRuCtiOnS. Item 67616 For technical questions, please call 1-800-444-3353. 14. WaRninG: handling the cord on this product will expose you to lead, a chemical known to the State of California to cause cancer, and birth defects or other reproductive harm. -
Page 6: Grounded Tools: Tools With Three Prong Plugs
Underwriters Laboratories, Inc., the Canadian Standard Association, and the National Electrical Code. 2. Double insulated tools may be used in either of the 120 volt outlets shown in the preceding illustration. (See Outlets for 2-prong plug.) Item 67616... -
Page 7: Extension Cords
Volts Alternating Current Amperes n 0 xxxx/min. No Load Revolutions per Minute (RPM) Item 67616 For technical questions, please call 1-800-444-3353. 7. Make sure the extension cord is properly wired and in good electrical condition. Always replace a damaged extension cord or have it repaired by a qualified electrician before using it. -
Page 8: Specifications
Page 8 For technical questions, please call 1-800-444-3353. 120V~ / 60Hz / 6.5A 0-2500 RPM 0-41,600 BPM 3/64" to 1/2" 1" (25mm) 5/8" (16mm) 1/2" (13mm) 39lh E194601 Mode Switch Forward/ Reverse Switch Trigger Figure a Lock Button Item 67616... -
Page 9: Operation
3. Securely tighten the Hex Bolt (3) until Auxiliary Handle is fastened securely onto Drill. 2. Insert the hammer bit or the drill bit (not included) all the way into the Chuck. 3. Turn the Chuck Key clockwise to tighten the Chuck on the bit. -
Page 10: General Operating Instructions
9. To switch between plain drilling and hammering mode (drilling with an oscillating hammer motion), slide the Mode Switch (21) to left or right. The “drill” symbol indicates plain drilling while the “hammer” symbol indicates hammer drilling. See Figure 3. - Page 11 2. Rock and masonry are generally drilled in the hammer (impact) drilling mode. Recommended Drill Bit Sets The chart below lists applicable Drill Bit sets that are available from Harbor Freight Tools. name 32925 29-Piece High Speed Steel Drill Bit Set 40547 20-Piece 1/8"...
-
Page 12: Maintenance
WaRninG! if the supply cord of this power tool is damaged, it must be replaced only by a qualified service technician. Item 67616... -
Page 13: Troubleshooting
5. Motor being strained by long or small diameter extension cord. Follow all safety precautions whenever diagnosing or servicing the tool. Disconnect power supply before service. Item 67616 For technical questions, please call 1-800-444-3353. likely Solutions 1. Check that cord is plugged in. -
Page 14: Parts List And Diagram
Armature Ball Bearing (608.2z) Bushing Label Housing Support Tapping Screw (ST4x18F) Stator Rubber Pin Switch Carbon Brush, Brush Holder Label Housing Cover Tapping Screw (ST4x14C) Cord Clamp Key Sleeve Chuck Key Power Cord Forward/Reverse Switch Trigger Lock Button Item 67616... -
Page 15: Assembly Diagram
Diagram Item 67616 For technical questions, please call 1-800-444-3353. Page 15... -
Page 16: Warranty
limited 90 Day Warranty Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase.
