1/2" HAMMER DRILL
SET UP AND OPERATING INSTRUCTIONS
Visit our website at: http://www.harborfreight.com
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
©
Copyright
2010 by Harbor Freight Tools
contained herein may be reproduced in any shape or form without the express written consent of
Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein. Tools required for
assembly and service may not be included.
For technical questions or replacement parts, please call 1-800-444-3353.
Model
68169
®
. All rights reserved. No portion of this manual or any artwork

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 68169 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Chicago Electric 68169

Summary of Contents for Chicago Electric 68169

  • Page 1 Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing improvements, actual product may differ slightly from the product described herein. Tools required for assembly and service may not be included.

  • Page 2: Important Safety Information

    Never modify the plug in any way. Do not use any adapter plugs with grounded power tools. Unmodified plugs and matching outlets will reduce risk of electric shock. b. Avoid body contact with grounded surfaces such as pipes, radiators, SKU 68169...
  • Page 3 Prevent unintentional starting. Ensure the switch is in the off- position before connecting to power source and/or battery pack, picking SKU 68169 For technical questions, please call 1-800-444-3353. up or carrying the tool. Carrying power tools with your finger on the switch or energizing power tools that have the switch on invites accidents.

  • Page 4: Drill And Impact Drill Safety Warnings

    Maintain labels and nameplates on the tool. These carry important safety information. If unreadable or missing, contact Harbor Freight Tools for a replacement. Avoid unintentional starting. Prepare to begin work before turning on the tool. Do not lay the tool down until it has come to a complete stop.

  • Page 5: Vibration Safety

    Safety Code § 25249.5, et seq.) 13. The warnings, precautions, and instructions discussed in this instruction manual cannot cover all possible SKU 68169 For technical questions, please call 1-800-444-3353. conditions and situations that may occur. It must be understood by the...

  • Page 6: Double Insulated Tools: Tools With Two Prong Plugs

    (See Table A.) If you are using one extension cord for more than one tool, add the nameplate amperes and use the sum to determine the required minimum cord size. (See Table A.) SKU 68169...
  • Page 7 Symbology Double Insulated Canadian Standards Association Underwriters Laboratories, Inc. Volts Alternating Current Amperes No Load Revolutions per Minute n 0 xxxx/min. (RPM) SKU 68169 For technical questions, please call 1-800-444-3353. (120/240 VOLT) LENGTH 75’ 100’ 150’ Page 7...

  • Page 8: Specifications

    Side Handle and slide the Depth Gauge into the gauge hole. See Figure 1, above. Set Depth Gauge to required depth and retighten grip to fasten Depth Gauge into place (read further explanation under General Operating Instructions). Key Holder SKU 68169...

  • Page 9: Tool Set Up

    Chuck. Follow these steps to insert bit: Insert Chuck Key (2) into the Chuck and turn counterclockwise to open the Chuck. Insert the hammer bit or the drill bit (not included) all the way into the Chuck. Turn the Chuck Key clockwise to tighten the Chuck on the bit.
  • Page 10 Do not drill or hammer drill hard materials such as steel or concrete with Lock Button pressed (ON). If drill bit catches on material, the high torque will cause the tool to twist around without stopping. This violent action could cause injury to your hands and arms.
  • Page 11 Do not lock Trigger in the ON position, as the bit can easily jam in wood and motor must be stopped quickly. The chart below lists applicable Drill Bit sets that are available from Harbor Freight Tools. Name 29-Piece High Speed Steel Drill...

  • Page 12: Maintenance And Servicing

    Page 12 For technical questions, please call 1-800-444-3353. WARNING! If the supply cord of this power tool is damaged, it must be replaced only by a qualified service technician. SKU 68169...

  • Page 13: Troubleshooting

    5. Improper internal parts lubrication. Follow all safety precautions whenever diagnosing or servicing the tool. Disconnect power supply before service. SKU 68169 For technical questions, please call 1-800-444-3353. Troubleshooting 1. Check that cord is plugged in. 2. Check power at outlet. If outlet is unpowered, turn off tool and check circuit breaker.

  • Page 14: Parts List

    Spring Mode Selector Bearing (607) Stator Housing O-Ring Inductor Trigger Cord Clamp Screw (ST4x14) Power Cord Cord Sleeve Screw (ST2.9x12) Carbon Brush Brush Holder Direction Switch Capacitor Screw (ST4x22) Housing Screw (ST4.2x16) Depth Gauge Side Handle Description Qty. SKU 68169...
  • Page 15 SKU 68169 For technical questions, please call 1-800-444-3353. Page 15...

  • Page 16: Limited 90-Day Warranty

    Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase. This...
