M
O D E L S
NetFlex-2 DualPort TR
142132-001
High-performance Token
Ring controller, combining
two Token Ring interfaces
on a single EISA board
Q
UICK
. .
S
F
T A N D A R D
. .
. .
. .
Performance
. .
. .
Exceptional performance through each of two
. .
. .
channels; two packet blasters, one per channel
. .
. .
. .
Affordability
. .
. .
Aggressively priced below two Compaq 32-Bit 4/16
. .
. .
Token Ring controllers; leverages NetFlex-2
. .
. .
technology and only requires one EISA slot
. .
. .
. .
. .
Compatibility
. .
Complies with IEEE 802.5 standard and supports 4
. .
. .
or 16 Mb/s
. .
. .
. .
. .
Manageability
. .
. .
Network Interface Fault Recover Tracking:
. .
Compaq Insight Manager provides monitoring
. .
. .
and alerting features, tracking numerous failure
. .
. .
indication parameters such as alignment errors,
. .
. .
lost frames, and frame copy errors
. .
. .
. .
. .
Compatibility and Integration Testing
. .
. .
Fully tested on a wide variety of Compaq products
. .
including ProSignia, Systempro/LT, and ProLiant
. .
. .
. .
. .
Option Kit Contents
. .
. .
One EISA adapter with two RJ-45 for UTP and
. .
. .
one DB connector, one single-to-dual converter cable
. .
with two DB-9 connectors for STP, software support
. .
. .
CD and diskettes, user guide, product quality
. .
. .
statements, and warranty information
. .
. .
. .
. .
Warranty
. .
. .
Maximum: The remaining warranty of the Compaq
. .
PC Product in which it is installed (to a maximum
. .
. .
1
three-year
limited warranty)
. .
. .
1
Minimum: One-year
limited warranty
. .
. .
. .
. .
. .
. .
S
P E C I F I C A T I O N S
. .
. .
Network Interface
. .
. .
Two Token Ring Interfaces on a single controller
. .
. .
card
. .
. .
. .
. .
Expansion Bus Architecture
. .
. .
32-Bit EISA
. .
. .
. .
Data Transfer Method
. .
. .
32-Bit bus master
. .
. .
. .
. .
Network Transfer Rate
. .
. .
4 or 16 Mb/s
. .
. .
. .
. .
. .
. .
. .
. .
. .
6-28
S
PECS
E A T U R E S
DualPort TR Controller
Connectors
Two RJ-45 supporting UTP (unshielded twisted
pair); two 9-pin D-shell through a DB-26 STP
(shielded twisted pair) breakout cable (included)
Equipment Requirements
One EISA bus master slot
I/O Address
z000h-z000Fh, z020h-z02Fh, zC80h, z080h-zC87h
where z=slot #
Interrupt
Channels 11, 10, 9, 5, 3; software-selectable; level-
triggered
Environmental Requirements
Operating: 10
o
-50
o
C; 20%-80% humidity
(noncondensing); 3,048 m alt.
Non Operating: 10
o
-50
o
C; 5%-90% humidity
(noncondensing); 9,144 m alt.
o
o
Shipping: 30
-50
C; 20%-80% humidity
(noncondensing); 3,084 m alt.
Communication Processors
Two Texas Instruments TMS380C26 Super Eagle
Two Texas Instruments TMS380FPA Packet Blasters
Standard Compliance
IEEE 802.5 compliant
O/S Driver Support
Novell NetWare Server: ODI, ODI 3.3, Compliant
Novell NetWare DOS and OS/2 Client: ODI,
ODI 3.3 Compliant
MS LAN Manager: DOS NDIS and OS/2 NDIS
Compliant
MS Windows for Workgroups: DOS NDIS
Compliant
MS Windows NT Client: NDIS 3.0 Compliant
MS Windows NT Adv. Server: NDIS 3.0 Compliant
IBM LAN Server: DOS NDIS and OS/2 NDIS
Compliant
SCO UNIX 3.2V4: LLI Compliant
SCO Open DeskTop: LLI Compliant
NetFlex-2
