PARTS LIST

MODEL NO.: CHX9130SQB-1 (30")
CHX9136SQB-1 (36")
NO. DESCRIPTION
1
6" Exhaust
2 Vent Cover (Top)
3 3-1/4" x10" Exhaust
4
3-1/4" x10" Vent Cover
5
6" Round Plastic Collar
6 LED Light (3W)
7 Control Unit
8 Capacitor (3.5uf +3.5uF/ 350V)
9 Motor (102B-3P)
10 Motor (102A-3P)
11 Turbine Impeller (747B)
12 Turbine Impeller (747A)
13 Plastic Oil Tunnel
14 Impeller Plastic Cover
15 Safety Screen
16 Safety Screen Screws
17 Metal Oil Tunnel
18 Baffle Filter
19 Stainless Steel Spacer
Optional Duct Cover
NO.
01 Hood Mounting Bracket
02
Screws (3/16"x3/8") x 6
03 Duct Cover Support x 2
04 Duct Cover (Inner and Outer)
05 Duct Cover Mounting Bracket
06 Screws (TS 4 x 6mm) x 4
DESCRIPTION
MODEL /SIZE
CH9130SQB-1 (30")
CH9136SQB-1 (36")
CH9130SQB-1 (30")
CH9136SQB-1 (36")
MODEL /SIZE
CH1120DC-1
18
PART NO.
L1-0241-0001-A
L1-0241-0001-B
L1-0241-0002-A
L1-0241-0002-B
L1-0505-0002
L1-0403-0301
L1-0405-0301
L1-0301-0120-102B
L1-0301-0120-102B-3P
L1-0301-0120-102A-3P
L1-0251-0747-B
L1-0251-0747-A
L1-0502-0101
L1-0251-0001
L1-0602-0101
L1-0705-0001
B101-9130-14A
B101-9136-14A
L1-0214-0191
B101-9130-15
B101-9136-15
PART NO.
L1-0221-1630
L1-0707-0002
L1-0208-1630
12-16300-61
L1-0203-1630
L1-0708-0002
