Fisher 1000 Owner's Manual

Low-profile tailgate spreader
Hide thumbs Also See for 1000:
Table of Contents

Advertisement

Quick Links

January 15, 2014
Lit. No. 94431, Rev. 07
Low‑Profile Tailgate Spreader
68810, 21927
Model 1000 & 2000
Owner's Manual
Original Instructions
CAUTION
Read this manual before installing or
operating the spreader.
This manual is for FISHER
Model 1000 & 2000 Low‑Profile Tailgate Spreaders
®
with serial numbers10003 and higher (Model 1000) and 20364 and higher (Model 2000).
This manual supersedes all editions with an earlier date.

Advertisement

Table of Contents
loading

Related Manuals for Fisher 1000

Summary of Contents for Fisher 1000

  • Page 1 Read this manual before installing or operating the spreader. This manual is for FISHER Model 1000 & 2000 Low‑Profile Tailgate Spreaders ® with serial numbers10003 and higher (Model 1000) and 20364 and higher (Model 2000). This manual supersedes all editions with an earlier date.

  • Page 3: Spreader Owner Data Sheet

    SPREADER OWNER DATA SHEET Register your spreader online at www.fisherplows.com Owner Name: ______________________________________________________________________________ Date Purchased: ____________________________________________________________________________ Dealer Name: ______________________________________________ Phone: _________________________ Dealer Address: _____________________________________________________________________________ Vehicle Model/Year: _________________________________________________________________________ Spreader Type/Size (Model): _________________________________________ Weight: ______________ lb/kg Spreader Serial Number:______________________________________________________________________ Lit. No. 94431, Rev. 07 January 15, 2014...

  • Page 5: Table Of Contents

    TABLE OF CONTENTS SPREADER OWNER DATA SHEET ......3 OPERATING THE SPREADER ........ 14 PREFACE ..............6 Driving and Spreading on Snow and Ice .... 14 SAFETY INFORMATION ..........7 Controls ............... 15 REMOVING THE SPREADER ......... 19 Safety Definitions ..........7 Warning and Caution Labels ........

  • Page 6: Preface

    PREFACE This manual has been prepared to acquaint you with When service is necessary, bring your spreader to the safety information, operation and maintenance of your local dealer. They know your spreader best and your new spreader. Please read this manual carefully are interested in your complete satisfaction.

  • Page 7: Safety Information

    SAFETY INFORMATION SAFETY DEFINITIONS WARNING/CAUTION LABELS Please become familiar with the Warning and Caution WARNING labels on the spreader. Indicates a potentially hazardous situation that, if not avoided, could result in death or NOTE: If labels are missing or cannot be read, see serious personal injury.

  • Page 8: Serial Number Label

    SAFETY INFORMATION SERIAL NUMBER LABEL SAFETY PRECAUTIONS Park the vehicle on a level surface, place shift lever in PARK or NEUTRAL and set the parking brake. Turn OFF the engine and remove keys. WARNING • Driver to keep bystanders minimum of 25 feet away from operating spreader.

  • Page 9: Fuses

    SAFETY INFORMATION PERSONAL SAFETY CAUTION • Do not operate a spreader in need of • Remove ignition key and put the vehicle in park or maintenance. in gear to prevent others from starting the vehicle • Before operating the spreader, reassemble during installation or service.

  • Page 10: Battery Safety

    SAFETY INFORMATION BATTERY SAFETY TORQUE CHART CAUTION CAUTION Batteries normally produce explosive gases, Read instructions before assembling. which can cause personal injury. Therefore, Fasteners should be finger tight until do not allow flames, sparks, or lit tobacco instructed to tighten according to torque to come near the battery.

  • Page 11: Loading

    Very Coarse = 35 lb/cu ft Coarse = 45 lb/cu ft Fine = 50 lb/cu ft Plus approximate base unit weights of 154 lb for Model 1000 and 161 lb for Model 2000, including mount. Lit. No. 94430/94431, Rev. 07...

  • Page 12: Mounting The Spreader

    MOUNTING THE SPREADER RECEIVER MOUNT SPREADER FIXED MOUNT SPREADER CAUTION During removal or mounting, securely grip spreader to avoid dropping. CAUTION During removal or mounting, securely grip NOTE: The spreader shall be installed according spreader to avoid dropping. to instructions supplied. Your local outlet is trained to provide this service and service your spreader with factory original parts.

  • Page 13: Swing Away ® Spreader

    MOUNTING THE SPREADER SWING AWAY SPREADER 1. Fasten the left and right top brackets along ® with any shims to the truck bed rail with two 1/2" cap screws, two 1/2" flat washers and two 1/2" locknuts per bracket. Install the two 5/16" cap screws and locknuts to the side of the top brackets.

  • Page 14: Operating The Spreader

    OPERATING THE SPREADER DRIVING AND SPREADING ON SNOW Here are some tips for driving in these conditions: AND ICE • Drive defensively. • Do not drink, then drive or spread ice‑control CAUTION materials. Drinking and then driving or spreading is •...

  • Page 15: Controls

    OPERATING THE SPREADER CONTROLS Variable Speed (PWM) Control – New Style There are two control options. They include the ON/Maximum Diagnostic Variable Speed (PWM) Control and the ON/OFF Speed Button Indicator Light Control. Both have had design changes. Identify older and newer styles by the face plate diagrams below to find the appropriate operating instructions.
  • Page 16 OPERATING THE SPREADER Adjusting the Spinner Speed NOTE: Always place the cover on the hopper to prevent moisture buildup. Do not let the spreader The speed setting can be adjusted when the spreader sit idle with material in the hopper for an extended is either ON or OFF.
  • Page 17 OPERATING THE SPREADER Variable Speed (PWM) Control – Old Style Adjusting the Spinner Speed The speed setting can be adjusted when the spreader is either ON or OFF. 1. Turn the speed dial clockwise. Speed will increase as the numbers on the speed dial increase. 2.
  • Page 18 OPERATING THE SPREADER ON/OFF Control Starting and Stopping the Motor New Style WARNING Before starting the spreader, the driver shall Spinner Indicator Light verify that all bystanders are a minimum of (when lit, indicates 25 feet away from operating spreader. power to the motor) 1.

  • Page 19: Removing The Spreader

    REMOVING THE SPREADER SWING AWAY MOUNT ® CAUTION Empty the hopper before removing the Removing the Spreader spreader. 1. Unplug the spreader and CHMSL (if equipped). CAUTION 2. Remove the hitch pin from the latch‑side hinge pin. During removal or mounting, securely grip spreader to avoid dropping.

  • Page 20: Maintenance

    MAINTENANCE 5. Verify that all drive sprocket set screws are tight. CAUTION Verify that all other fasteners are tight. Refer to the Disconnect electric power at spreader Torque Chart in the Safety section of this manual. electrical wiring harness connection and tag out if required before servicing or performing 6.

  • Page 21: Postseason Maintenance

    MAINTENANCE POSTSEASON MAINTENANCE DRIVE BELT REPLACEMENT CAUTION CAUTION Disconnect electric power at spreader Disconnect electric power at spreader electrical wiring harness connection and tag electrical wiring harness connection and tag out if required before servicing or performing out if required before servicing or performing maintenance.

  • Page 22: Bearing And Set Screw Maintenance

    MAINTENANCE BEARING AND SET SCREW FUSE REPLACEMENT MAINTENANCE See the Harness Wiring Diagrams on the following pages for fuse ratings and locations. Disconnect the electrical plug between the spreader and the truck before performing any maintenance. If a problem should occur and fuse replacement is necessary, the replacement fuse must be of the same 1.

  • Page 23: 4-Pin Harness Wiring Diagram

    4‑PIN HARNESS WIRING DIAGRAM – LOW‑PROFILE SPREADERS Cab Control White Connector Two-Way Molded Connector Red Connector 6 Amp Fuse 14 ga Red 8 ga Red To vehicle ignition 8 ga Red (accessory wire or fuse box) 30 Amp Fuse 10 ga Red 14 ga Black 8 ga Black 14 ga Yellow...

  • Page 24: 2-Pin Harness Wiring Diagram

    2‑PIN HARNESS WIRING DIAGRAM – LOW‑PROFILE SPREADERS Old Style New Style (no adapter required) (adapter required) CHMSL Speed Speed Control Control Black White White Black Black Adapter White Vehicle Black Stoplight Harness Fuse Fuse holder Butt White Connector Black Power Lead Battery Harness Black...

  • Page 25: Troubleshooting Guide

    TROUBLESHOOTING GUIDE For control operation and use of diagnostic indicator lights, locate the section for your control style in the Operating the Spreader section of this manual. Problem Possible Cause Suggested Solution 1. Control connector plug is loose. 1. Check plug connection at cab control. 2.
  • Page 26 TROUBLESHOOTING GUIDE Problem Possible Cause Suggested Solution Unplug the spreader harness and tag out, if required, before performing any of the following repairs. 1. Obstruction is preventing rotation. 1. Clear obstruction. 2. Drive belt is loose or damaged. 2. Adjust tension or replace belt if worn or damaged.
  • Page 28 Fisher Engineering outlets or spreader owner is granted. Fisher Engineering reserves the right under its product improvement policy to change construction or design details and furnish equipment when so altered without reference to illustrations or specifications used. Fisher Engineering or the vehicle manufacturer may require or recommend optional equipment for spreaders.
