Lit. No. 95903, Rev. 01
June 15, 2008
Regular and High Capacity
PRO-CASTER™
Hopper Spreader
Owner's Manual
CAUTION
Read this manual and engine owner's manual
before installing or operating the spreader.
This manual is for FISHER
PRO-CASTER Hopper Spreaders with serial numbers
®
beginning with 0609–0805.
This document supersedes all editions with an earlier date.
Advertisement
Table of Contents
Related Manuals for Fisher PRO-CASTER
Summary of Contents for Fisher PRO-CASTER
- Page 1 Owner's Manual CAUTION Read this manual and engine owner's manual before installing or operating the spreader. This manual is for FISHER PRO-CASTER Hopper Spreaders with serial numbers ® beginning with 0609–0805. This document supersedes all editions with an earlier date.
-
Page 2: Table Of Contents
TABLE OF CONTENTS PREFACE .................................. 1 SAFETY INFORMATION ............................2 Before You Begin ..............................2 Torque Chart ............................... 3 Gasoline Warning Label ............................. 4 Warning/Caution Label ............................4 LOADING .................................. 5 Certifi cation ................................. 5 Material Weights ..............................5 Regular Capacity Load Weight ........................... 5 High Capacity Load Weight .......................... -
Page 3: Preface
PREFACE This manual has been prepared to acquaint you with When service is necessary, bring your hopper the safety information, operation and maintenance of spreader to your local outlet. They know your spreader your new hopper spreader. Please read this manual best and are interested in your complete satisfaction. -
Page 4: Safety Information
SAFETY INFORMATION SAFETY DEFINITIONS WARNING WARNING Hydraulic fl uid under pressure could cause skin injection injury. If you are injured Indicates a potentially hazardous situation by hydraulic fl uid, get medical attention that, if not avoided, could result in death or immediately. -
Page 5: Torque Chart
SAFETY INFORMATION FUSES BATTERY SAFETY CAUTION The electrical system contains automotive blade-style fuses. If a problem should occur and fuse replacement Batteries normally produce explosive gases is necessary, the replacement fuse must be of the that can cause personal injury. Therefore, same type and amperage rating as the original. -
Page 6: Gasoline Warning Label
SAFETY INFORMATION WARNING/CAUTION LABELS Gasoline Warning Label Please become familiar with the Warning and Caution WARNING labels on the spreader. Gasoline is flammable. NOTE: If labels are missing or cannot be read, see • Turn off engine and allow it to cool before filling gas tank. your sales outlet. -
Page 7: Loading
LOADING This Manual covers vehicles which have been Certifi cation recommended for carrying the hopper spreader. Please see your local dealer for proper vehicle WARNING applications. New untitled vehicle installation of a spreader requires National Highway Traffi c Safety WARNING Administration altered vehicle certifi... -
Page 8: Spreader Specifi Cations
LOADING Spreader Specifi cations Overall Empty Spreader Weight (lb) Capacity Capacity Overall Overall Recom- Spreader Length (No screen Struck Rounded Width Height mended Description (inches) or battery) (cu yd) (cu yd) (inches) (inches) Regular Capacity 3/4 or 1 7’ Hopper Body 50-3/4 Ton Pick- 14 Gauge Stainless Steel... -
Page 9: Determining Vehicle Payload
LOADING Determining Vehicle Payload 5. Subtract the GVW from the GVWR to determine WARNING the available material payload. Overloading could result in an accident or damage. Do not exceed GVWR or GAWR ratings 6. Obtain the weight per cubic yard (lb./cu. yd.) of as found on the driver-side door cornerpost of the desired material. - Page 10 LOADING Determining Vehicle Payload Worksheet Example: Material Type Coarse Salt – Dry Equipment installed when 7' Poly Hopper vehicle was weighed Spreader Front Gross Axle Weight Rating (FGAWR) (lb) Rear Gross Axle Weight Rating (RGAWR) (lb) Gross Vehicle Weight Rating 8600 (GVWR) (lb) Gross Vehicle Weight (empty)
-
Page 11: Operating The Spreader - Cab Control
OPERATING THE SPREADER – CAB CONTROL Cab Control Identifi cation NOTE: Do not hold the throttle switch in the FAST position until the choke re-engages. The engine will not run with the choke 100% engaged. See Electric Electric Spreader Choke Choke Adjustment Procedure for instructions for Throttle Clutch... -
Page 12: Operating The Hydraulic Spreader - Dual Cab Control
OPERATING THE HYDRAULIC SPREADER – DUAL CAB CONTROL Cab Control Identifi cation Typical Spreader Control Valve (Sold as an accessory) ON Position AUGER SPINNER OFF Position Operating the Cab Control WARNING • Driver to keep bystanders minimum of 25 1. Engage the hydraulic system with the spreader feet away from operating spreader. -
Page 13: Operating The Spreader
OPERATING THE SPREADER Tecumseh Choke Adjustment Procedure 1. The choke linkage and choke adjustment screw is Choke Butterfl y shipped from the factory with the choke butterfl y Choke Adjustment set to 75% fully closed choke. Screw Retainer Screw 2. With the choke set at 100% the engine will not stay running in the choked position. -
Page 14: Baffl E Adjustment
OPERATING THE SPREADER Baffl e Adjustment Spread pattern and the amount of material dispensed depends on engine RPM, gate position, and baffl e settings. • Decreasing RPM and/or gate-opening will decrease the amount of material coming to the spinner. • Increasing RPM and/or gate-opening will increase the amount of material coming to the spinner. -
Page 15: Spread Patterns - Center Belt Drive
OPERATING THE SPREADER Spread Patterns – Center Belt Drive These fi gures are as viewed from the top of the spinner looking down. Internal Baffl es External Baffl es Both internal baffles out All baffles adjusted down for a confined spread pattern Driver-side baffle in, curb-side baffle out Curb-side baffle deflects material down;... -
Page 16: Maintenance
MAINTENANCE Drive Chain, Spinner Belt and Conveyor CAUTION Chain Tension Disconnect electric and/or hydraulic power and tag out if required before servicing or performing • At the beginning of each season, and once a month maintenance. during the season, verify the drive sprocket set screws and the clutch sprocket mounting bolts are tight. -
Page 17: Electric Clutch
MAINTENANCE • Use the two 5/8" x 6" take-up bolts at the front of Electric Clutch the spreader to adjust the conveyor chain tension. Loosen the locknuts before attempting to adjust To minimize problems and extend the life of the the take-up bolts. -
Page 18: Hydraulic Hopper Spreaders
MAINTENANCE Hydraulic Hopper Spreaders To keep your spreader functioning properly, observe the following recommendations: 1. Check hydraulic fl uid level before every use. Add After each use: fl uid as required. 2. Periodically inspect the hoses and fi ttings for •... -
Page 19: Wiring Diagram (Spreader Battery Kit)
WIRING DIAGRAM (SPREADER BATTERY KIT) Choke Light Green Choke Switch Clutch Switch Start Switch Black Gray White Brown Black White/ Cab Control Black Yellow Wiring Blue Violet To Switched Accesory Circuit Note: Yellow, Blue and Violet Black wires are provided To Ground Point for accessory use. -
Page 20: Wiring Diagram (Vehicle Battery Kit)
WIRING DIAGRAM (VEHICLE BATTERY KIT) Choke Light Green Choke Switch Clutch Switch Start Switch Gray White Brown Black White/ Black Note: Yellow, Blue Yellow Cab Control and Violet wires Blue Wiring are provided for Violet accessory use. To Switched Note: 10 amps MAX load Accesory Circuit per wire or a Black... -
Page 21: Electric Throttle Motor Replacement
ELECTRIC THROTTLE MOTOR REPLACEMENT Crank (shown against the Electric Throttle Bracket according to step 4 of the installation instructions below.) Electric Throttle Arm Throttle Pin #6 Locknut #4 Locknut #4 Plain Washer #6 x 5/8" Cap Screw Choke Light #4 x 3/4" Socket Button Switch 1/4"... -
Page 22: Dual Hydraulic Circuit Diagram
DUAL HYDRAULIC CIRCUIT DIAGRAM Typical Hydraulic Circuit Dedicated Fixed Displacement Pump PUMP 23 GPM Min VALVE 1500 PSI Rated to 40 GPM 1500 PSI Inlet Flow from Tank Controlled Flow to Conveyor Motor: Excess Flow 10 GPM @ 1500 PSI to Tank Return Flow to Tank... - Page 24 Fisher Engineering or the vehicle manufacturer may require or recommend optional equipment for spreaders. Do not exceed vehicle ratings with a spreader. Fisher Engineering offers a limited warranty for all spreaders and accessories.
