Sound Playback Operations; Music Browse Mode - Pioneer AVH-100DVD Owner's Manual

USB
Refer to Repeating playback on page 18.
7 Slow-motion playback key
(Function for DivX file/MPEG-1/MPEG-2/
MPEG-4)
Moving the selection ahead one frame at a
time during playback.
Touch and hold down the key for more than
two seconds to slow down playback speed.
8 Stop key
Stopping playback.
If you resume playback, playback will start
from the point where you stopped. Touch the
key again to stop playback completely.
9 Screen mode key
Changing the screen mode.
Refer to Changing the wide-screen mode on
page 8.
a Pause and play key
Pausing playback.
Returning to normal playback during
paused, slow motion, or frame-by-frame play-
back.
Basic operations
Playing back videos
1 Connect the USB device.
Playback will automatically start.
When the source icon is not displayed, it can
be displayed by touching the screen.
Fast forwarding or reversing using the buttons
1 Press and hold c or d (TRK).
Notes
! Touch panel keys not listed under Moving im-
ages operations may appear on the display.
Refer to Indicator list on page 44.
! You can also switch between languages/
audio systems using Video Setup menu. For
details, refer to Setting the audio language on
page 27.
! This unit will return to normal playback if you
change the audio language during fast for-
ward/fast reverse, pause or slow motion play-
back.
! You can also switch between subtitle lan-
guages using Video Setup menu. For de-
tails, refer to Setting the subtitle language on
page 27.
! This unit will return to normal playback if you
change the subtitle language during fast for-
ward/fast reverse, pause or slow motion play-
back.

Sound playback operations

You can use this unit to listen to USB audio files.
MTP connection
USB MTP (connecting to MTP-compatible
Android devices using a USB cable) is sup-
ported only for MP3/WMA/AAC files in this func-
tion.
Notes
! The play time may not display correctly.
! When playing back files recorded as VBR
(variable bit rate) files, the play time will not
be correctly displayed if fast forward or re-
verse operations are used.
! To ensure proper operation, connect the
dock connector cable from the iPod directly
to this unit.
! While the iPod is connected to this unit, the
iPod cannot be turned on or off.
! If the characters recorded on the USB stor-
age device are not compatible with this unit,
those characters will not be displayed.
USB
! Text information may not be correctly dis-
played depending on the recorded environ-
ment.
! Disconnect the USB portable audio player/
USB memory when you are done using it.
! When you select Speana on Selecting the
background display on page 33, the artwork is
not displayed.
Touch panel keys
1
USB JAN 12:43
PM
6 1
Abcdefghi
Abcdefghi
Abcdefghi
Abcdefghi
S.Rtrv
All All All
Media
00'01'' -00'03''
9 8 7 6 54 3
1 Information key
Switching the text information to display on
this unit when playing MP3/WMA/AAC/WAV
files.
2 Search key
Displaying the file name list to select the
files.
3 Media key
Switching between media file types to play
on USB.
4 Sound retriever key
Refer to Using sound retriever on page 7.
5 Random key
Playing songs in random order.
6 Repeat key
Selecting the repeat range.
7 DB key
Creating a database that enables searches
by artist name, genre, and other options.
Refer to Music browse mode on page 17.
8 Previous folder key/Next folder key
Selecting a folder.
2
9 Pause and play key
Pausing and starting playback.
Basic operations
Playing back tracks
1 Connect the USB device.
Playback will automatically start.
When the source icon is not displayed, it can
be displayed by touching the screen.
Fast forwarding or reversing using the buttons
1 Press and hold c or d (TRK).

Music browse mode

(Function for USB MSC)
This unit creates an index in order to facilitate
browsing for a song. You can search by the cate-
gories such as albums and artists.
CAUTION
! This function is not available when the USB
storage device is locked.
! This function is not available when the free
space of USB storage device is less than
5 MB.
! While this unit creates an index, do not turn
the unit off. It may cause loss of data on your
USB storage device.
Section
09
17
En
