H1/10 BROWN
H1/11 RED
H1/12 RED/WHITE

Door Lock, 3-Pin Connector (H2)

1 GREEN
2 OPEN
3 BLUE
This security system can control two common power door lock types without
any additional parts. With certain vehicles, or if an actuator is to be installed,
either a 451M Door Lock Relay Satellite or two relays will be required.
Important:
For additional Door Lock information refer to Tech tip #1041 at
www.directechs.com or contact your local distributor.

Horn Honk, 3-pin connector

OPEN
H/1
BROWN/BLACK
H/2
OPEN
H/3
This wire outputs a single pulse when arming the system and two puls-
es when disarming the system. This wire will also output pulses for 30
seconds when the system is triggered or if panic mode is activated. If
the vehicle has a (+) horn circuit, a standard automotive SPDT relay or
a relay assembly package (p/n 8617) must be used.
© 2011 Directed Electronics. All rights reserved.
(+) Siren Output
(+)12 V Constant Power Input
(-) 200 mA Channel 2 Validity Output
(-) Lock, (+) unlock output
except if using 451M
(+) Lock, (-) unlock output
NO FUNCTION
(-) 200 mA HORN HONK OUTPUT
NO FUNCTION
3
