INSTALLATION
INSTRUCTIONS
PARTS LIST
Security System
P/N 08E51-EP4-100
Security unit
LED
Push nut
2-pin connector (for LED)
Microphone
Window decal
Owner's manual
© 2004 American Honda Motor Co., Inc - All Rights Reserved.
Accessory
SECURITY SYSTEM
Security System Attachment
P/N 08E55-S9A-100
Security harness
Unit bracket
Fuse label
2 Cushion tapes
Ground bolt
4 Wire ties
TOOL AND SUPPLIES REQUIRED
#2 Phillips screwdriver
Small flat-tip screwdriver
Felt-tip pen
10 mm Combination wrench
10 mm Socket
Ratchet
Center punch
Drill
3 mm, 5.5 mm, 8 mm Drill bits
Eye protection (face shield, safety goggles, etc.)
Isopropyl alcohol
Tape measure
AII 27188 (0409)
Application
CR-V
08E55-S9A-1002-91
Publications No.
AII 27188
Issue Date
SEP 2004
1 of 6

Advertisement

   Also See for Honda CR-V

   Related Manuals for Honda CR-V

   Summary of Contents for Honda CR-V

  • Page 1: Parts List

    Drill 3 mm, 5.5 mm, 8 mm Drill bits Eye protection (face shield, safety goggles, etc.) Isopropyl alcohol Owner’s manual Tape measure 1 of 6 © 2004 American Honda Motor Co., Inc - All Rights Reserved. AII 27188 (0409) 08E55-S9A-1002-91...

  • Page 2: Illustration Of Security System

    COLUMN COVER LOWER STEERING COLUMN COVER SELF- KNOB TAPPING Turn CLIP SCREW clockwise DRIVER’S 90°. SCREW DASHBOARD Push UNDER COVER TABS (6) 2904170M 2 of 6 AII 27188 (0409) © 2004 American Honda Motor Co., Inc - All Rights Reserved.

  • Page 3

    First drill a pilot hole with a 3 mm drill bit, then finish with an 8 mm drill bit. HALF OF CUSHION TAPE 3 of 6 © 2004 American Honda Motor Co., Inc - All Rights Reserved. AII 27188 (0409)

  • Page 4

    Install the new ground bolt connector area. from the kit. UNIT BRACKET SECURITY UNIT CONNECTOR AREA (Do not push here.) 4 of 6 AII 27188 (0409) © 2004 American Honda Motor Co., Inc - All Rights Reserved.

  • Page 5

    CONNECTOR HARNESS WHITE WIRE 1-PIN CONNECTOR FUSE BOX ACCESSORY TERMINAL (+B) 19. Attach the 2A fuse label to the security harness fuse case. 5 of 6 © 2004 American Honda Motor Co., Inc - All Rights Reserved. AII 27188 (0409)

  • Page 6

    2-pin connector, and wrap one cushion tape around the 2-pin connectors. 33. Test the driver’s window AUTO function. 22. Reinstall the lower column cover. 6 of 6 AII 27188 (0409) © 2004 American Honda Motor Co., Inc - All Rights Reserved.
