Opening Dimensions - Sub-Zero Built-In Refrigeration Installation Manual

SITE PREPARATION

Opening Dimensions

STANDARD INSTALLATION
3
83 / "
4
(2127)
OPENING
HEIGHT
SIDE VIEW
NOTE: Shaded line represents profile of unit.
OPENING WIDTH
BI-36R, BI-36RG, BI-36F
BI-30U, BI-30UG
BI-36U, BI-36UG, BI-36UFD
BI-36S
BI-42UFD
BI-42S, BI-42SID, BI-42SD
BI-48S, BI-48SID, BI-48SD
|
4 Sub-Zero Customer Care 800.222.7820
24"
(610)
OPENING
DEPTH
TOP VIEW
W
OPENING WIDTH
FRONT VIEW
35 1 / "
(902)
2
29 1 / "
(749)
2
35 1 / "
(902)
2
35 1 / "
(902)
2
41 1 / "
(1054)
2
41 1 / "
(1054)
2
1
47 / "
(1206)
2
If two units are installed side by side, refer to page 6.
