5" GPS Navigation 5" GPS Navigation
SN Component
1 Power key
2 Stylus slot
3 Speaker
4 Indicator light
5 Earphone jack
6 T-Flash card slot
7 AV-In port (option)
8 MINI USB port
9 Light sensor
10 Reset key
1.2 Power Supply & Charging
Charge the GPS navigator fully with the charger before first use.
1.2.1 Power Supply
The FreeWAY MX2 can be powered by the built-in battery or ex-
ternal power supply.
When the GPS navigator is unconnected to the charger, it is pow-
ered by the Li-polymer battery. The battery capacity icon
system main interface shows current residual battery capacity.
When the GPS navigator is connected to the charger, it is powered
by external power and the battery is charged.
[Attention] The GPS navigator adopts internal non-removable Li-
polymer battery. To avoid battery rupture, explosion, release of haz-
6 6
Explanation
Powering on/ off the device or enter sleep
mode
Location of the stylus
Playing sounds (such as navigation prompt
tones, music, etc.)
Indicating the operating state of external
power supply
Connected with the stereophone
T-Flash card inside
Use the AV-In cable to connect the naviga-
tor to a rear view camera via this port while
backing the vehicle. Refer to rear view cam-
era usage.
Communicating with PC via MINI USB
cable, or connected to TMC, or used as the
charging port
For automatic backlight adjustment
Restart the system
www.modecom.eu www.modecom.eu
in the
