Display Confi Guration During The Dive; Stop Timer - SCUBAPRO-UWATEC Chromis User Manual

Depth: the depth is given in 10cm resolution
when metric mode. When the depth is
displayed in feet, the resolution is always 1
foot. At a depth shallower than 0.8m/3ft,
the display shows --. Maximum operating
depth is 120m/394ft.
No-stop time: calculated in real time and
updated every 4 seconds. Maximum
displayed no-stop times is 99 minutes.
During all dives, perform a safety stop
between 3 and 5 meters/10 and 15 feet for 3
to 5 minutes, even if no decompression stop
is required.
Temperature: Chromis displays the water
temperature during the dive and the air
temperature on the surface. However,
the skin
measurement when worn at the wrist.
Decompression information: when Chromis
calculates the need for a mandatory
decompression stop, it shows you how
long and how deep your deepest stop is. It
also gives you the total ascent time. Stops
deeper than 27m/90ft and total ascent times
longer than 99 minutes are shown as "- - ".
4.7.1.1 Display confi guration during
the dive
Throughout the dive, Chromis displays the
most important information with largest font
at the middle row: current depth (right), the
elapsed dive time (left) and the no-stop or
decompression information (bottom row).
CHROMIS USER MANUAL
WARNING:
temperature infl uences
In addition, Chromis utilizes the top row to
display additional information regarding the
dive. By pressing + button in the display is
shown, in sequence:
1. PDIS depth (If pending)
2. Maximum depth (only if 1m/3ft ascent
detected)
3. Water temperature
4. O %
2
5. CNS % if greater than 1%
6. Time of the day in the middle row
(temperature at top row)

7. Stop timer

4.7.1.2 Stop timer
There are many situations during a dive
where a simple stop timer which is
independent from dive time is practical;
for example timed tasks at dive courses or
special missions etc.
the
Chromis has a stop timer integrated on the
SCUBA mode. Stop timer can be selected
by pressing the + button and it is shown at
the top row.
During a dive, the stop timer starts at the
immersion. So when displayed for the fi rst
time during the dive, stop timer and dive
time are identical.
When displayed, the stop timer can be
stopped by pressing "-" button. This
generates a bookmark, which can be seen
on log book using PC/Mac interface software.
When displayed and stopped, stop timer
can be reset to zero by pressing and
holding "-" button.
29
