8
Initial Start Up

2.8 Serial Interface

In order to connect the serial cable, align the wider side of the plug to the wider side of the printer connector.
Afterwards fasten the plug with the two existing screws in order to produce a stable electrical contact.
Then connect the cable to the computer (corresponding serial interface).
The serial interface also serves for communication with the PC, but it is slower than the parallel interface. By
using the keyboard you can set
Baud rate: 4800, 9600, 19200, 38400
Data bits: 7, 8
Stop bit: 1, 2 and
Parity: without, with (even, odd)
Protocol: without XON / XOFF, with XON / XOFF
Standard settings are printed in bold.
Notice: Before connecting the cable, the printer and the PC had to be switched off.

2.9 Transporting the Printer

1. Switch printer off.
2. Unplug carefully the mains cable and the interface cable (serial and/or Centronics-cable).
3. Use original packing material for transportation, where possible.
Notice: Before transporting the printer, all paper- and transfer ribbon rolls must be removed.
F+D
Feinwerk- und Drucktechnik GmbH
Kirchenstraße 38, D-69239 Neckarsteinach
Tel.: 06229 7000, Fax: 06229 70067
E-Mail: hotline@fuddruck.de, Internet: http://www.fuddruck.de
ECO 200
User Manual
