16
Operating

3.3.4 Label Data

Copies
- 0000 - 9999
Number of labels to be printed

Image Width

- 0000 - 0896 dots
Image Width determines the width of the print area.
Parameter: d = image width * 8 / mm in number of dots
minimum width = 8 mm (d=64), maximum width = 108 mm (d=864)
The value for the image width can at any time be smaller than the real
label format. The resulting print area will thus be in image middle.

Image Height

- 0000 - 4000 steps
Image Height determines the height of the print area.
Parameter: d = image height * 8 / mm in number of motor steps
minimum height = 10 mm (d=80), maximum height = 500 mm (d=4000)

Image Abort

- 0002 – 6000 steps
The Image Abort forces an abort of the printing process. This is
sensible, if at the end of an image area there are only blanks. The
image abort encourages the image creation at high printing speeds.
Parameter: d = image abort * 8 / mm in number of motor steps
automatically image abort (d = 0000):
Display: 0000 dot 002
The Printer automatically find out the image abort to get the best
printing.

Paper End

- 000 – 999 steps
In case that within the set step no new label is recognized, the error
message Paper End will be displayed.
Parameter: d = paper end * 8 / mm in number of motor steps

Paper Jam

- 0000 – 4000 steps
In case that within the set step no paper end is recognized, the error
message Paper Jam will be displayed.
Parameter: d = paper jam * 8 / mm in number of motor steps
Without Label Synchronization:
There will be no check if paper jam incurred.
With Label Synchronization:
The input value must be larger than the label height (in dots), otherwise an unauthorized paper end - error
message will be given.
F+D
Feinwerk- und Drucktechnik GmbH
Kirchenstraße 38, D-69239 Neckarsteinach
Tel.: 06229 7000, Fax: 06229 70067
E-Mail: hotline@fuddruck.de, Internet: http://www.fuddruck.de
ECO 200
User Manual
LABEL DATA
copies
LABEL DATA
image width
LABEL DATA
image hight
LABEL DATA
image abort
LABEL DATA
paper end at..
LABEL DATA
paper jam at..
LABEL DATA
dispensing pos.
LABEL DATA
cutting pos.
LABEL DATAv
TOF-Offset
