Maintenance
7. Nest the thermal print head from the lower
side into the rectangular holes on the printer
upper via the tabs.
8. Rotate the print head to the upper side until
the thread bush mates with the knurled screw.
9. In order to tighten the knurled screw, draw
down the printer upper and lock.
Notice: Unfortunalety it is not possible to claim for warranty, as the lifetime of the thermal print head is
depending very much, on the boundary conditions (such as paper quality, printing speed, heating time,
quality of thermal ribbon, ...).

4.5 Update of printer software ECO 200

A new printer software / firmware can be load via the serial or parallel port to the ECO 200. Please take note
that an update is only possible if the present version is 1.20 or higher.
Running Update
1. Connect the printer via the parallel port to the LPT-port of the PC.
2. While switching on the printer, please press the buttons „Cut" and „Clear" to reach the programming
mode.
3. The display will show „PROGRAM UPDATE"
4. Please activate the MS- DOS mode at the PC or use the file „Update.bat" (position 5 is inapplicable
then).
5. Now the new version can be load to the printer under MS-DOS
copy/b file name lptx
(for example: copy/b ECES2126.upd lpt1 <Enter>)
6. During data transmission the display shows „READ DATA". (process will take approx. 15 sec.)
7. When data transmission is finished the printer will show „.....READY....."
8. Please restart the printer
9. Now the new software is available in the printer.
10. For doing a check please press the „status" button which effects the software version to be shown.
F+D
Feinwerk- und Drucktechnik GmbH
Kirchenstraße 38, D-69239 Neckarsteinach
Tel.: 06229 7000, Fax: 06229 70067
E-Mail: hotline@fuddruck.de, Internet: http://www.fuddruck.de
ECO 200
User Manual
thermal print head with print head adapter
tab
using the command
®
23
locking of printer upper
