Technical Data

8. Technical Data
Printing Method:
Print Resolution:
Printing Speed:
Print Width:
History Control:
Fonts:
Font Sizes:
Barcodes:
Drawing Capability:
Specialities:
Processor:
RAM:
Interfaces:
Operation Panel:
Labelling Material *:
Transfer Ribbon *:
Label Reverse:
Monitoring:
Measurements:
Weight:
Electrical:
Environmental Conditions:
Options:
Driver:
Software:
*F+D also supplies custom tailored consumables such as thermal papers, labels, and transfer ribbons
F+D
Feinwerk- und Drucktechnik GmbH
Kirchenstraße 38, D-69239 Neckarsteinach
Tel.: 06229 7000, Fax: 06229 70067
E-Mail: hotline@fuddruck.de, Internet: http://www.fuddruck.de
ECO 200
User Manual
Thermal Direct- or Thermal Transfer Printing
8 dots/mm
200 mm/sec
108 mm
Software
2 internal bitmap fonts: Courier bold, Arial bold; optional: bitmap fonts
loadable
Width and Height 2 - 6 mm, Courier: 6/8/10/12/14
Arial: 6/8/9/10/12/14/16/18/20/22 as well as by steps up to 255
Code 2 of 5 Interleaved, Code 39, Code 128, EAN 8, EAN 13, EAN 128,
PDF 417A, Barcodes variable in height, module width, and ratio.
Optionally with control line, check digit, subscript line, and start-/stop-code
line, box with varying line widths
2-level-technology for fixed and variable objects (text, barcode, logo). All
objects can be copied into the image memory in transparent / non
transparent mode. Text- as well as barcode-objects can be placed precisely
and indexed numerically
Intel 32 bit
8 MB
Parallel IEEE 1284 (ECP) , RS 232S 4800 - 38,400 baud
6 operation keys, 2 x 16 digit LCD, 2 LED's
Thermal paper, standard paper, plastic foils, self- adhesive and cardboard
labels, label height 10 - 500 mm Label width 30 - 110 mm, paper guide way
centred to the thermal print head, outer diameter 140 mm max., core
diameter 12, 40, and 50 mm
Length max. 450 m, width max. 110 mm, roll diameter max. 75 mm, core
diameter 25.4 mm
Yes
Paper- and ribbon-end, synchronization: "scan-through" optical sensoring
H x W x D in mm 275 x 250 x 351
9 kg
230/115 V (auto-switch), 50/60 Hz, Current 1.1/2.2 A, fuse T 3.15 A,
10 - 45°C, 20 - 80% humidity (non condensing)
Label dispenser, cutting device, RFID Device, internal and external rewinder
TM
Windows 95, 98, NT 4.0, 2000 und XP
Labelling Software SprintLabel
