Service Diagnosis

6.2 Error Correction

Error Description
No green LED
No printed image
Label material is transported
insufficiently (buckled printed
image)
Label material is not
transported at all
Transfer ribbon is not
transported at all
Unauthorized Paper Jam- /
Paper End-Error Message
In dispensing mode the label is
retracted before it can be
taken out
Every error switches the display from the standard window to the error window, and activates the error-LED.
It is also possible that several errors occur at the same time, for example sequence errors, where the error
with the highest priority is displayed. The priority increases with the increasing error code number.
Inside the status display up to 8 error codes will be displayed in the 2nd status window
(depress status-key 2x).
The error-messages as displayed in the LCD-display are divided into 3 categories:
Error Codes:
01 - 99
100 - 239
240 - 255
F+D
Feinwerk- und Drucktechnik GmbH
Kirchenstraße 38, D-69239 Neckarsteinach
Tel.: 06229 7000, Fax: 06229 70067
E-Mail: hotline@fuddruck.de, Internet: http://www.fuddruck.de
ECO 200
User Manual
Reason for Error
Mains Cable
Mains Plug
Mains Fuse
Internal Power Supply defective
Print Parameter incorrect
Transfer ribbon inserted
incorrectly
Thermal Paper incorrect
Transfer ribbon of other quality
Dirty Transport Rollers
Transport rollers are not driven
Transfer ribbon torn
Paper Sensor set incorrectly
Paper Jam
- WARNING lowest priority
- ERROR
- HARDWARE highest priority
Error Correction
Change Mains Cable
Establish correct contact
Change Mains Fuse
Manufacturer Service
Adjust print parameter anew
Insert transfer ribbon (according to
drawing)
Use material recommended by
manufacturer
Use transfer ribbon recommended by
manufacturer
Clean transport rollers (see 4.3)
Manufacturer Service
Insert transfer ribbon anew and
depress Print-Key
Execute the option Start? in menu
Printer Data/Automat. Paper Sensor
Bring label into dispensing position
by using the -key and remove it
(remove Dispensing Table if
necessary )
