1. Overview

1.2 Rear View

MIDI IN
1
1. MIDI IN
2. DMX Polarity Select
3. DMX Out
4. DC Input
DMX POLARITY
SELECT
1=Ground
1=Ground
2=Data +
2=Data -
3=Data +
3=Data
2
Receives MIDI data.
Used to select DMX polarity.
This connector sends your DMX value to the DMX fixture
or DMX pack.
DC 9-12V, 300mA min.
DMX OUT DC INPUT
2 1
-
3
9~12V, 300mA min.
3 4
6
