SHOWTEC Scanmaster 1 User Manual page 8

1. Overview
1.1 Front View
2. Scene Buttons
3. Segment Display
4. Bank Buttons(Up/Down)
5. Chase Buttons(1-6)
6. Program Button
7. MIDI/Rec Button
8. Auto/Del Button
9. Music/Bank Copy
10. Blackout Button
11. Tap Sync/Display
12. Fade Time Slider
13. Speed Slider
14. Page Select Button
15. Faders
5
Press the scene buttons to load or stored your scenes.
There are a maximum of 240 programmable scenes.
Shows the current activity or programming state.
Press the Up/Down buttons to select a bank from 30 banks.
Used to select your programmed chase consisting a
maximum of 240 scenes
Used to activate Program mode.
Used to control MIDI operation or to record programs.
Used to activate Auto mode or to delete scenes and chases.
Used to activate Music mode or to create scenes and
chase programs.
Used to disable channel output.
Used to create a standard beat or to change the values
display between % and 255.
Used to adjust the Fade Time. Fade Time is the amount
of time it takes for a fixture to move from one position to
another, for the dimmer to fade in or fade out.
Used to adjust the speed at which the scenes will chase.
Used to select faders for the fixture between Page A(1-8)
and Page B (9-16).
These faders are used to control the intensity of channel 1-8
or channel 9-16 depending upon the selected page.
