- Page 1 BU-3025 3-MegaPixel Outdoor 25 meter IR IPCAM User’s Manual AirLive BU-3025 Manual...
- Page 2 Model No. ____________________ Serial No. ____________________ To prevent fire or shock hazard, do not expose the unit to rain or moisture. For AC Adaptor to avoid electrical shock, do not open the cabinet. Refer servicing to qualified personnel only. AirLive BU-3025 Manual...
-
Page 3: Declaration Of Conformity
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. AirLive BU-3025 Manual... - Page 4 We reserve the right to make any modification to this manual or the information contained herein at any time without notice. The software described herein may also be governed by the terms of a separate user license agreement. AirLive BU-3025 Manual...
-
Page 5: Table Of Contents
4.3.2 Advanced....................21 4.4 IP Filter ......................23 4.5 Video .........................24 4.5.1 Image Setting ..................24 4.5.2 Video Setting ...................26 4.5.3 Overlay Setting ..................27 4.6 Audio........................28 4.7 Motion........................29 4.8 PTZ Control .......................30 4.9 Event .........................32 4.9.1 Image Setting ..................32 4.9.2 Media.......................34 AirLive BU-3025 Manual... - Page 6 Appendix D: Bandwidth Estimation................51 Appendix E: Specifications ..................52 Appendix F: Configure Port Forwarding Manually ...........53 Appendix G: DDNS Application ................56 Appendix H: Power Line Frequency ................63 Appendix I: 3GPP ....................64 Appendix J: Enable UPnP of Windows XP ..............65 AirLive BU-3025 Manual...
-
Page 7: Introduction
Introduction 1.1 Overview This user’s guide explains how to operate AirLive BU-3025 from a computer. A user should read this manual completely and carefully before you operate the device. AirLive BU-3025 is high-end 3.0 MegaPixel (MP) network camera which is designed for professional outdoor surveillance and security applications. -
Page 8: Package Contents
1. Introduction AirLive PoE cameras in locations without access to electrical source. With the IP-66 waterproof housing, AirLive BU-3025 suits for environments such as stairs, main entrance, street, and basement. The device is accessible via the LAN or Internet connection. Connect your device directly to a local area network or xDSL modem, and with Microsoft®... -
Page 9: Physical Overview And Connections
For connections to 10Base-T Ethernet or 100Base-TX Fast Ethernet cabling. This Ethernet port built N-Way protocol can detect or negotiate the transmission speed of the network automatically. Please use Category 5 cable to connect the Network Camera to a 100Mbps Fast Ethernet network switch or hub. AirLive BU-3025 Manual... - Page 10 Connect a loud speaker to the network camera. This function is for voice alerting and two-way audio. 6. BNC Connector: The composite video format will be sent out through this connector. A user might connect the IP Camera to a monitor or DVR via this connector. AirLive BU-3025 Manual...
-
Page 11: Mounting The Camera
Once you have installed the camera well and powered it on, the power LED (orange) will turn on later. The power LED turns on, which means the system is booting up successfully. Furthermore, if you have a proper network connection, and access to the camera, the LAN LED (green) will flash. AirLive BU-3025 Manual... -
Page 12: Preparation
Camera’s IP address and set up related parameter in a Camera. 2.1.1 Search When launch the IPWizard II, a searching window will pop up. IPWizard II is starting to search Network Cameras on the LAN. The existed devices will be listed as below. AirLive BU-3025 Manual... -
Page 13: Lan
LAN button. Relative settings will be carried out as below. You could modify the relative settings of the selected device. Click “<<” button will quit the LAN setting procedure and click “>>” button will move to next page as below. AirLive BU-3025 Manual... - Page 14 If you like to change username and/or password of the device, just click the check button. Then, the related fields will show up as below. After keying in new username and password, click “Submit” button to perform your setting accordingly. Click “<<” button will go back to previous page. AirLive BU-3025 Manual...
-
Page 15: Wireless
Windows XP. Note: Windows 2000 does not support UPnP feature. To discover your device, go to your Desktop and click My Network Places. Click the targeted Device. Then Internet Explorer will connect to this Network Camera automatically. AirLive BU-3025 Manual... -
Page 16: Install The Device Behind A Nat Router
(2) Enable UPnP NAT traversal option of the Network Camera Refer to Setting Network UPnP page for detail NAT traversal setting. Note that this option is default enabled. (3) Access your Network Camera by DIPS Refer to Setting System System page for detail DIPS information. AirLive BU-3025 Manual... -
Page 17: Access The Device From The Internet Explorer For The First Time
Warning” window. If so, select “Yes” to install and run the ActiveX control into your PC. Otherwise, the system will load the ActiveX silently. 4. After the ActiveX control is installed and ran, the first image will be displayed. AirLive BU-3025 Manual... -
Page 18: Logging In As An User
If you log in the Camera as an ordinary User, “Configuration” function will be not accessible. 2.6 Logging in as an Administrator If you log in the Camera as the Administrator, you can perform all the settings provided by the device. AirLive BU-3025 Manual... -
Page 19: Operating The Network Camera
Click for configuring the camera settings. Language The device can provide multiple languages to meet customer’s requirement. Stream The device supports multi-profile function for H.264, MEPG4 and JPEG simultaneously. A user can choose the proper and/or preferred profile which is listed here. AirLive BU-3025 Manual... - Page 20 Please note: that digital zoom uses computer algorithm to enlarge the video and some details may lost. If you need to focus on detail of specific objects in video view, please use optical zoom ring on lens set of IP camera. AirLive BU-3025 Manual...
- Page 21 ASF format into your local PC. While you want to stop it, press Stop to stop recording. Recording Location Select Recording Location to select the save path and file name prefix, select OK to continue. AirLive BU-3025 Manual...
-
Page 22: Administrating The Device
Setup Event server, Motion Detection, I/O Ports and Event configuration. Recording Setup External storage Recording SDHC Status and configuration of SD card Check the usage log of IP camera Device info Check the information and network settings of this IP camera. Maintenance maintenance function of this IP camera Setup AirLive BU-3025 Manual... -
Page 23: System
Indicator LED: Turn on or off Indicator LED. Time Zone: Set the time difference from Greenwich Mean Time in the area where the device is installed. Daylight Saving: Disable or enable the daylight saving adjustment. AirLive BU-3025 Manual... -
Page 24: Security
NTP server (Network Time Protocol). Set Manually: Click this option to set time and date manually.. When you finish with above settings, click ‘Apply’ button to save changes. 4.2 Security In this menu, you can configure IP camera’s login account. AirLive BU-3025 Manual... -
Page 25: Network
(it will always be ‘administrator’). 4.3 Network In this menu, you can configure IP camera’s network setting. 4.3.1 General Setup the IP address for BU-3025. This IP camera supports both IPv4 and IPv6 IP address. AirLive BU-3025 Manual... - Page 26 IP camera. For example, if the IP camera’s IP address is 192.168.2.3 and you changed HTTP port number to 82, please input ‘http: //192.168.2.3:82’ in web browser’s address bar to access IP camera’s web configuration interface. AirLive BU-3025 Manual...
-
Page 27: Advanced
When you finish with above settings, click ‘Apply’ button to save changes. 4.3.2 Advanced You can setup advanced network settings in this page. This page is intended for advanced settings only, and this IP camera will work fine even you don’t make any changes to this page. AirLive BU-3025 Manual... - Page 28 Password: Input the password used to login dynamic IP service provider. HTTPS: Check ‘Enable HTTPS’ box to enable HTTPS channel to encrypt transferred data. You can also define HTTPS port number in ‘HTTPS Port’ field if you don’t want to use default value ‘443’. AirLive BU-3025 Manual...
-
Page 29: Ip Filter
IP camera will only accept connections established from these IP address. If you want to specify one IP address only, input the same IP address in both field. Click ‘New’ button to add IP address into accepted IP list. AirLive BU-3025 Manual... -
Page 30: Video
If you want to specify one IP address only, input the same IP address in both field. Click ‘New’ button to add IP address into deny IP list. 4.5 Video 4.5.1 Image Setting You can adjust the image parameters in this page. AirLive BU-3025 Manual... - Page 31 Always OFF: IR filter is always off. Day: Select the condition that you’ll be using this IP camera from dropdown menu. Auto: IP camera will adjust its parameters automatically. Night: You’ll be using this IP camera in dark places where lights are insufficient. AirLive BU-3025 Manual...
-
Page 32: Video Setting
Select video bit rate. You can control bit rate by both Video quality and Bitrate. Video quality: There are 5 levels of video quality, select ‘very high’ to improve video quality but consumes more network bandwidth, and select ‘very low’ will decrease video quality and consumes less network bandwidth. AirLive BU-3025 Manual... -
Page 33: Overlay Setting
Check this box to display certain text on video; this will help when you need to identify certain IP camera when you have a lot of IP cameras. Please input the text in ‘Text’ field. You can input up to 15 characters. AirLive BU-3025 Manual... -
Page 34: Audio
You can adjust audio input / output parameters here. Enable Microphone: Check this box to enable microphone. If you don't want to hear voice from IP camera, you can uncheck this box to disable it. Audio Type(Microphone): The format is fixed as G.711 AirLive BU-3025 Manual... -
Page 35: Motion
This IP camera is capable to detect object’s motion, so IP camera will only record when there’s motion and save disk storage space. Motion detection is performed by examine the movement of objects in rectangular motion detection area. You can define up to 3 motion detection areas. AirLive BU-3025 Manual... -
Page 36: Ptz Control
If you mount the IP camera on pan tilt camera cradles that support pan tilt control via RS-485 connection, you can use this function to control pan tilt camera cradle. Therefore, you can control the orientation of IP camera from remote place. AirLive BU-3025 Manual... - Page 37 Command 1 ~ 5: You can define extra pan-tilt camera cradle control strings here by giving it a name (Command Name) and command string (Hexadecimal Message). You can also click ‘Test’ button to send command string for testing. AirLive BU-3025 Manual...
-
Page 38: Event
This page lists all existing events. You can click ‘Modify’ button to edit an existing event, or ‘Remove’ to delete an existing event. To create a new even, just click “New” button to add an Event setting. AirLive BU-3025 Manual... - Page 39 Input any description text for this event so you can identify it quickly. You can use alphabets, numbers, and symbols include:!$ .@^_~ (no spaces allowed). Trigger by:: Select the triggered sources. Enable Schedule Time: Define the feasible time slot. Action: Define the actions once event triggered. AirLive BU-3025 Manual...
-
Page 40: Media
Tips: You may want to know what happened before event is triggered in many cases, especially when object is outside of motion detection window. Note: If the “Pre Event” set to “0” second, the “Post Event” cannot set to “0” second. AirLive BU-3025 Manual... -
Page 41: Event Server
Input the path where you want to save file on FTP server, like ‘upload/record’. If you want to save file on this FTP user’s home directory, you can leave this field blank. Enable Passive Mode: Check this box to force IP camera to communicate with FTP server in passive AirLive BU-3025 Manual... - Page 42 Email server’s username and password in corresponding field. Requires SSL Encryption: If your Email server required SSL encryption, check this box. Please note that some Email server uses different port number than standard port 25 when SSL encryption is used. AirLive BU-3025 Manual...
-
Page 43: Recording
Note: 1. Be sure that the SD Card format should be FAT32. The NTFS format cannot be supported by this camera. 2. Unlink motion detection, this function will record video at specified time period on selected weekday(s). AirLive BU-3025 Manual... - Page 44 Recording Schedule: Define the recording schedule. You can check Sun to Sat boxes to represent a weekday, and specify time period in ‘From’ and ‘To’ field. Select ‘Always’ to record 24 hours in selected weekday(s). AirLive BU-3025 Manual...
-
Page 45: Log
In this page, you can click: 1. First page / Final page: Jump to first / final page of log. 2. Previous / Next: Jump to previous or next page of log. 3. Remove: Clear log. You’ll be prompted for confirmation. AirLive BU-3025 Manual... -
Page 46: Device Info
You can check the information and network settings of this IP camera. This information is very useful when you need to repair or fix the problem of this IP camera. An example of device info page looks like below: AirLive BU-3025 Manual... -
Page 47: Maintenance
SD card slot when you click this button, or you’ll receive an error message. Restore: Restore a previous saved configuration file in your computer. Click ‘Browse’ button to select a file on your computer first, then click ‘Restore’ button. AirLive BU-3025 Manual... -
Page 48: Language
Upgrade IP camera’s firmware. Click ‘Browse’ button to select a firmware image file on your computer first, then click ‘Upgrade’ button. 4.14 Language You can change the display language of web interface. Click ‘Language’ button and select one language. More languages may available in latest firmware file. AirLive BU-3025 Manual... -
Page 49: Appendix
This Camera provides wires for general I/O terminal and RS485 interface as below: Cable for I/O connectors: Name Cable Color Function Sensor IN Blue Digital signal input Alarm OUT Green Digital signal output Black RS485 + Orange RS485 data + RS485 - Yellow RS485 data - AirLive BU-3025 Manual... -
Page 50: Appendix B: Troubleshooting & Frequently Asked Questions
If a firewall exists on the network, port 80 is open for installed and work if a ordinary data communication. The HTTP port and firewall exists on the RTSP port need to be opened on the firewall or NAT network. router. AirLive BU-3025 Manual... - Page 51 If you are experiencing problems, try upgrading with the device to the latest version of Microsoft’s Internet Explorer from the Microsoft webpage. IPWizard II program Network may have trouble. Confirm the parameters fails to save the and connections of the device. network parameters. AirLive BU-3025 Manual...
- Page 52 • The port number assigned in your Network Camera might not be available via Internet. Check your ISP for available port. • The proxy server may prevent you from connecting directly to the Network Camera, set up not to use the proxy server. AirLive BU-3025 Manual...
- Page 53 Internet Explorer are configured properly and then try reloading the device’s home page. Most likely, the ActiveX control did not download and install correctly. Check your Internet Explorer security settings and then close and restart Internet Explorer. Try to browse and log in again. AirLive BU-3025 Manual...
- Page 54 Your Internet connection may not have enough bandwidth to support streaming audio from the device. Image Transfer on • Default Gateway and DNS server address should be e-mail or FTP does not set up correctly. AirLive BU-3025 Manual...
- Page 55 White-light LED Miscellaneous Can not play the Have installed Microsoft®’s DirectX 9.0 or later and use recorded ASF file the Windows Media Player 11.0 or later to play the AVI filed recorded by the Device. AirLive BU-3025 Manual...
-
Page 56: Appendix C: Ping Ip Address
The replies, as illustrated below, will provide an explanation to the problem. If you want to detect any other devices conflicts with the IP address of Network Camera, also can utilize the PING command but you must disconnect the device from the network first. AirLive BU-3025 Manual... -
Page 57: Appendix D: Bandwidth Estimation
128 kbps. Thus, you may not be able to receive good quality video while also streaming audio on a 128 kbps or lower connection. Even though the upload speed is more than 128kbps, for optimal video performance, disabling audio streaming will get better video performance. AirLive BU-3025 Manual... -
Page 58: Appendix E: Specifications
Intelligent video motion detection and external input Up to 3 motion detection areas with included or excluded Motion Detection options File upload via FTP ,SD Card or email Alarm Events Notification via email, HTTP, External output activation General 128MB 128MB AirLive BU-3025 Manual... -
Page 59: Appendix F: Configure Port Forwarding Manually
Therefore, user could use this feature to configure port forwarding of NAT router first. However, if user needs to configure port forwarding manually, please follow the steps as below: Manually installing the device with a router on your network is an easy 3-step procedure as following: AirLive BU-3025 Manual... - Page 60 Internet. Be sure to uncheck the Reset IP address at next boot button at the top of the screen after modifying the IP address. Failure to do so will reset the IP address when you restart your computer. AirLive BU-3025 Manual...
- Page 61 80, you will need to change the port the camera uses from 80 to something else, such as 8080. Not all routers are the same, so refer to your user manual for specific instructions on how to open ports. AirLive BU-3025 Manual...
-
Page 62: Appendix G: Ddns Application
DSL or cable modem internet connection where your computer's IP address changes all the time!! DDNS service supports all top level domain names including but not limited to .com, .net, .org, .to, .uk etc. AirLive BU-3025 Manual... - Page 63 DDNS and PPPoE of the Networked Device in order to let the outside administrator be able to access through internet. Application Steps—DDNS & Domain Name (1). Visit the following web site: http://www.dyndns.org/ (2). Click “Account” AirLive BU-3025 Manual...
- Page 64 (3). After the columns show up at the left side, click “Create Account”. (4). Fill the application agreement and necessary information. a. Username b. E-mail address and confirmation c. Password and confirmation d. Submit all the input information and finish creating an account AirLive BU-3025 Manual...
- Page 65 (5). Check your e-mail mailbox. There will be an e-mail with a title “Your DynDNS Account Information“. Click the hyperlink address to confirm the DDNS service that you just applied. Then DDNS you applied activated. Click to confirm AirLive BU-3025 Manual...
- Page 66 DDNS server. Input your account (7). If the correct username and password are input, you can see the following picture at the top-right of the login page. (8). Click the “Services”. (9). Click the “Dynamic DNS”. AirLive BU-3025 Manual...
- Page 67 (Pink No.1) Then we pick a domain that is easy to remember. (Pink No.2) The 3rd step is to click “Offline Hostname” from Service Type. (Pink No.3) Finally, click the “Create Host” to submit the domain name information and finish DDNS application. (Pink No.4) AirLive BU-3025 Manual...
- Page 68 DDNS and PPPoE after the application of DDNS service. Please check the user manual to access the DDNS and PPPoE pages. After saving the modification, restart the device. Then the external users could browse the Networked Device by the input of their domain name. AirLive BU-3025 Manual...
-
Page 69: Appendix H: Power Line Frequency
230V 50 Hz Italy 230V 50 Hz *Eastern Japan 50 Hz (Tokyo, Kawasaki, Sapporo, Yokohoma, and Japan 100V 50/60 Hz* Sendai); Western Japan 60 Hz (Osaka, Kyoto, Nagoya, Hiroshima) Malaysia 240V 50 Hz Netherlands 230V 50 Hz AirLive BU-3025 Manual... -
Page 70: Appendix I: 3Gpp
2. Use the following URL to access: rtsp://host/mpeg4/media.3gp Where host is the host name or IP address of the camera. Compatible 3G mobile phone: Please contact your dealer to get the approved list of compatible 3G phone. AirLive BU-3025 Manual... -
Page 71: Appendix J: Enable Upnp Of Windows Xp
Appendix J: Enable UPnP of Windows XP Use the following steps to enable UPnP settings only if your operating system of PC is running Windows XP. Go to Start > Settings. Click Control Panel Click Add or Remove Programs AirLive BU-3025 Manual... - Page 72 5. Appendix Click Add/Remove Windows Components The following screen will appear: Select Networking Services Click Details AirLive BU-3025 Manual...
- Page 73 5. Appendix Select Universal Plug and Play Click Ok Click Next AirLive BU-3025 Manual...
- Page 74 5. Appendix Please wait while Setup configures the components. Click Finish AirLive BU-3025 Manual...
