POE-260 CAM
POE Pan-Tilt hision IP Camera
User's Manual
AirLive POE-260CAM User's Manual


Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the POE-260 CAM and is the answer not in the manual?

Questions and answers

Related Manuals for Air Live POE-260 CAM

Summary of Contents for Air Live POE-260 CAM

  • Page 1 Copyright & Disclaimer   POE-260 CAM POE Pan-Tilt hision IP Camera User’s Manual AirLive POE-260CAM User’s Manual  ...
  • Page 2 Copyright & Disclaimer   Copyright & Disclaimer No part of this publication may be reproduced in any form or by any means, whether electronic, mechanical, photocopying, or recording without the written consent of OvisLink Corp. OvisLink Corp. has made the best effort to ensure the accuracy of the information in this user’s guide.
  • Page 3         Before You Use this Product  This product has been designed with safety in mind. However, if not used properly, electrical products can cause fires which may lead to serious bodily injury. To avoid such accidents, be sure to heed the following: Legal Caution Video and audio surveillance can be forbidden by laws that vary from country to country.

  • Page 4: Table Of Contents

    Table of Content     Table of Content 1. Introduction Overview How to Use This Guide Firmware Upgrade and Tech Support Features 2. Hardware Installation Hardware Installation Steps Package Contents Overviews EZ Install CamPro Express 3. Using IP Camera via Mobile Phone 3G Mobile Phone Viewing 2.5G Mobile Phone Viewing 4. Using IP Camera via Web Browser...

  • Page 5: Introduction

    1.Introduction        Introduction Overview The POE-260CAM is an advanced POE IP camera with Pan and Tilt function. You can set a particular patrol area; it will then move its lens in both horizontal and vertical direction continuously to scan the area. Or you can remote control the camera to look in the desirable direction.

  • Page 6: How To Use This Guide

    1.Introduction       How to Use This Guide The AirLive POE-260CAM is a high performance camera designed for professional indoor surveillance and security applications. It is recommended that you read through the entire user’s guide whenever possible. The user guide is divided into different chapters, include hardware installation and campro express installation.

  • Page 7: Firmware Upgrade And Tech Support

    1.Introduction  APPENDIX –This section tell you most of the case study when you need to Setup Frame Rate & Bit Rate Table,Storage Requirement Table,DIDO in Motion detection,DIDO in Cam Pro Express. This is most of read if you need to setup DIDO.

  • Page 8: Features

    1.Introduction Features Simultaneous MPEG-4 and Motion JPEG video stream 12 pcs Infrared LEDs for night use up to 10 working distance IEEE 802.3 af Power over Ethernet Support 2-Way Audio Capability Support Mac OS Browser CAMPRO Express- 16 channel recording software. Support multiple Language firmware and Web Monitor Support DIDO function.

  • Page 9: Hardware Installation

    2.Hardware  Installation        Hardware Installation   This section describes the hardware features and the hardware installation procedure for the POE-260CAM. For software configuration, please go to chapter 3 for more details. 2.1 Hardware Installation Steps Follow these steps to install the POE-260CAM on your Ethernet: 1.

  • Page 10: Package Contents

    2.Hardware  Installation 2.2 Package Contents Camera POE-260CAM Dome IP Camera Quick Installation Guide Brief product information and quick installation Software CD IP Surveillance Software Intelligent IP Installer User Manuals Language Packs Screw Pack Two screws and plastic wall anchors 12V DC, max 6W Adaptor Camera POE-260CAM Dome IP Camera...

  • Page 11: Overviews

    2.Hardware  Installation      2.3 Overviews Front & Side:                         DI / DO Terminal connector diagram Please refer the following illustration below for connection method. NO    COM    D‐    D+   ...

  • Page 12: Ez Install Campro Express

    2.Hardware  Installation 2.4 EZ Install CamPro Express All ipcam use the factory default settings All ipcam and Airlive CamPro Express server in the same subnet Please see the detail setting in user manual [ Step 1 ] Install: 1. Select “Install Driver & Utility” 2.
  • Page 13 2.Hardware  Installation  For a better understanding, please read this manual before operate the AirLive CamPro Express system. System Requirement- SERVER version P-4 3.0G 1G or above Windows XP Professional Service Pack2 Operating System (English/Traditional Chinese/Simplified Chinese) Windows Vista Home Basic/Home Premium/Business/Ultimate Network 10/100 Mbps Fast Ethernet...
  • Page 14 2.Hardware Installation  AirLive CamPro Express is consisted of SERVER version and CLIENT version. SERVER version limits one installation. SERVER version includes Admin, Monitor, Control and Web Monitor programs. CLIENT version is designed for monitoring purpose, and the Admin program is an option while installation AirLive POE-260CAM User’s Manual ...
  • Page 15 2.Hardware  Installation  [ Step 2 ]Select language The Installation Wizard will select the language of your operation system intelligently. AirLive CamPro Express supports three languages ： Traditional Chinese, Simplified Chinese, English [ Step 3 ] The Installshield Wizard will check if IIS is installed at your system. If not, you can continue installing AirLive CamPro Express, but you will not be able to use the WEB monitoring feature without IIS.
  • Page 16 2.Hardware  Installation       [ Step 4 ] Select language. Click “Next” to begin the installation process.               [ Step 5 ] Please read the License Statement and select “Yes” to accept and continue.  ...
  • Page 17 2.Hardware  Installation  [ Step 7 ] Choose Destination Location or click “Next” simply Specify the Destination Folder; you may click “Browse…” to select a folder other than the default one. Click “Next” to continue. Note: The default location is deemed adequate for most situations, it is recommended that you  ...
  • Page 18 2.Hardware  Installation         [ Step 10 ] Start Copying Files page pop out, review all your configuration that you have made. Click “Next” to accept these setting and continue. Note: The installation process may take several minutes to complete, depending on the handling capability of your computer system (refer to Section 7.1.2 System Requirement for system requirement detail)
  • Page 19 2.Hardware  Installation  Setting: 1. Run the Airlive CamPro Express-->Admin. 2. Select “E-MAP” then “Add Area”. 3. Enter the Area Name then Create. 4. Select area name then select 5. When search completed select Create”. “Auto Add Device”.       15 ...
  • Page 20 2.Hardware  Installation 6. Select the ipcam device icon 7. Select the ipcam device icon then select “Image Setting” . then select “Motion Detcetion”. 8. Setting motion detection area in this page. 9. Select the ipcam device icon then select “Image Alarm”. 9.
  • Page 21 2.Hardware  Installation  10. Setting motion detection alarm in this page. 11. Select “SystemAdm” then select “Rotation” 12. Setting rotation place in the monitor   17  AirLive POE-260CAM User’s Manual       ...
  • Page 22 2.Hardware  Installation 13. Run the Airlive CamPro Express-->Monitor. 18  AirLive POE-260CAM User’s Manual   ...
  • Page 23 2.Hardware  Installation  Uninstall: Run windows “Add or Remove Programs” then select utility name to remove Select “Remove” then “Next” to start uninstall.         19  AirLive POE-260CAM User’s Manual       ...
  • Page 24 2.Hardware  Installation Appendix Save Into Network Storage If you want to save to local recording to your Network Storage, Please do the following. 1. Copy your file location that you want to save, and mapping network device. 20  AirLive POE-260CAM User’s Manual   ...
  • Page 25 2.Hardware  Installation  2. Or you can change the save location in 3. Make your 2 Saving Location to Nus the monitor mode for the local recording. 4. Sometimes when your network traffic is very busy or you wish to decrease your computer/networking loading that you can increase your compression.

  • Page 26: Using Ip Camera Via Mobile Phone

    3.  Using  IP  Camera  via  Mobile  Phone  Using IP Camera via Mobile Phone  To use IP cameras via mobile phones, please make sure your RTSP is set to “ON”. (Default is “ON”) To change the settings of IP cameras, please see “Settings” for details. 3.1 3G Mobile Phone Viewing For 3G mobile phone viewing, type “rtsp://<IP>:<PORT>/video.3gp”...

  • Page 27: Using Ip Camera Via Web Browser

    4.Using  IP  Camera  via  Web  Browser       Using IP Camera via  Web Browser  This Chapter explain how to searching ip camera and basic system requirement. System Requirement  To use the product normally, we strongly recommend your computer follows our minimum system requirement (Computer level lower than this might cause some problems.) Item Requirements...

  • Page 28: Initial Accessing The Ip Camera

    5.  Initial  accessing  the  IP  Camera  Initial accessing the IP Camera This Chapter explains default setting of the device and how to access into ip camera 1. Start your web browser, and enter the IP address or host name of the IP camera in the Location / Address field of your browser.

  • Page 29: Accessing The Ip Camera

    6.  How  to  Use How to Use                     This chapter introduces how to monitor the image from the device using Microsoft web browser. The IP camera can be used with Microsoft web browsers and Intelligent IP Installer in Windows operation systems.

  • Page 30: Configuration Of Main Menu

    6.  How  to  Use 6.2 Configuration of Main Menu     6.2.1 Setting    This function is only for the Administrator. Click this button to get into the Basic and Advance settings menu. 6.2.2 Client Setting Mode: Click on the pull-down box to choose between MPEG4 and MJPEG video compression mode.

  • Page 31: Image Setup

    6.  How  to  Use 6.2.3 Image Setup You can use the tool bar to optimize video brightness, contrast, and saturation. 6.2.4 Live View Snapshot: You can capture a still image shot by the camera and save it in your computer. 1.
  • Page 32 6.  How  to  Use Audio buttons： ：Speakers turned on. ：Speakers turned off. ：Microphone turned on. ：Microphone turned off. ● : Volume control bar. Note： It means the speakers of your computer are turned on to transmit the sounds from the connected IP camera(s). Similarly, means you can broadcast to the connected IP camera(s) via the Ethernet using your microphone.

  • Page 33: Setting

    7.  Setting  Setting                       This chapter explain to you all of the function in the firmware. You can setup image, color network, and different level user in this chapter.  Basic Click on the “Basic”...
  • Page 34 7.  Setting  Date & Time Current date & time: This displays the current date and time of the device. PC clock : This displays the date and time of the monitoring PC clock. Date & time format : Click the pull-down box to select among different time display formats, including yyyy-mm-dd hh:mm:ss (year-month-day hour:minute:second), mm-dd-yyyy hh:mm:ss (month-day-year hour:minute:second), and dd-mm-yyyy hh:mm:ss (day-month-year hour:minute:second).
  • Page 35 7.  Setting  Initialize Reboot：Click this button to reboot the device. A confirmation dialogue will appear. Click OK to proceed. It takes about two minutes to reboot the device. Factory default：Click this button to reset the device to the factory default settings. A confirmation dialogue will appear.
  • Page 36 7.  Setting  7.1.2 Camera 7.1.3 General RTSP: Switch the RTSP streaming On/Off. Note： RTSP: Real Time Streaming Protocol. RTSP is supported by most of the media clients. (RealPlayer, Media Player, QuickTime, etc…) Image Rotate：Enables user to mirror or flip the display screen. Night Mode：Turn Night Mode ON/OFF.
  • Page 37 7.  Setting  7.1.3.1 MPEG4 Computer View RTSP (If RTSP mode is ON) RTSP port: Specify the transmission port number of RTSP streaming video. Default value is 554. Viewer authentication: If the viewer authentication is ON, users viewing through RTSP will be requested to key-in username and password. RTP (If RTSP mode is ON) Unicast streaming: Unicast streaming Video/Audio port range: Specify the transmission port range...
  • Page 38 7.  Setting  MPEG4 viewer port (If RTSP mode is OFF) Unicast streaming Video/Audio port number: Specify the transmission port number of the video data. It is initially set to 8090. Specify an even number from 1024 to 65534. Image Size：Specify the image size the network camera transmits. You can choose among 704 ×...
  • Page 39 7.  Setting  Mobile View  RTSP (If RTSP mode is ON) RTSP port: Specify the transmission port number of RTSP streaming video. Default value is 8554. RTP (If RTSP mode is ON) Unicast streaming: Unicast streaming Video/Audio port range: Specify the transmission port range of RTP streaming video.
  • Page 40 7.  Setting  7.1.3.2 MJPEG Note： MJPEG settings are unavailable if the RTSP mode is ON, which means the MJPEG streaming is closed. MJPEG viewer port Unicast streaming Video/Audio port number: Specify the transmission port number of the video data. It is initially set to 8070. Specify an even number from 1024 to 65534. Note：...
  • Page 41 7.  Setting  7.1.4 Network 7.1.4.1 Information MAC address：Display the MAC address of the device. Obtain an IP address automatically (DHCP)：If a DHCP server is installed on the network, to select this while the IP address is assigned by the DHCP server. Note：...
  • Page 42 7.  Setting  7.1.4.2 PPPoE Use this when you connect the device through PPPoE (Point-to-Point Protocol over Ethernet). PPPoE connection is the protocol that is widely used in xDSL (digital affiliate line such as ADSL, VDSL or SDSL) as the authentication and connection system. IP address：The IP address obtained at the PPPoE connecting with network.
  • Page 43 7.  Setting  7.1.4.3 DDNS Server name：Choose the DDNS Server from the list. User ID：Enter the user ID for authentication necessary for DDNS connections. Type it up to 64 characters. Password：Enter the password for authentication necessary for DDNS connections. Type it up to 32 characters. Re-type password：Re-type the password to confirm.
  • Page 44 7.  Setting  7.1.4.4 UPnP The device includes support for UPnP, which is enabled by default. If also enabled on your computer, the device will automatically be detected and a new icon will be added to “My Network Places.” It provides port forwarding for opening a port in a router or firewall in a private network in order to let a party from the outside world contact a user inside.
  • Page 45 7.  Setting  7.1.4.5 IP Notification When network notify type is set to On, you can send an e-mail notification of the completion of the network setting. Notify type：Select type of DHCP, Static IP and PPPoE will notify. SMTP server name ： Type the SMTP server name up to 64 characters, or the IP address of the SMTP server.
  • Page 46 7.  Setting  Recipient e-mail address：Type the recipient e-mail address up to 64 characters. You can specify up to three recipient e-mail addresses. Administrator e-mail address：Type the Administrator e-mail address up to 64 characters. This address is used for reply mail and sending system messages from the SMTP server.
  • Page 47 7.  Setting  7.1.6.2 HTTPS HTTPS is a URI scheme used to indicate a secure HTTP connection. It is syntactically identical to the http:// scheme normally used for accessing resources using HTTP. Using an https: URL indicates that HTTP is to be used, but with a different default TCP port (443) and an additional encryption/authentication layer between the HTTP and TCP.

  • Page 48: Advance

    7.  Setting  Advance 7.2.1 FTP Client Use this menu to set up for capturing and sending images to an FTP server. By using FTP client function, you can send the image and audio file which has been shot and recorded linked with the external sensor input or with the built-in motion detection function to FTP server.
  • Page 49   7.  Setting  7.2.1.2 Alarm Sending Set to forward the image and audio file to the specified FTP server linked with the alarm detection by the external sensor input or by the built-in motion detection function. Select On to send the image and audio file to FTP server linked with the alarm detection. Remote path：Type the path to the destination in FTP server up to 64 characters.
  • Page 50 7.  Setting  7.2.1.3 Periodical Sending You can set to send an image file to FTP server periodically by selecting On to send the image file to FTP server linked with setting period.   Remote path：Type the remote path up to 64 characters. Image file name：Type the file name of the image sent to FTP server up to 10 alphanumeric characters, - (hyphen) and _ (under score).
  • Page 51 7.  Setting  7.2.2 SNMP Set the SMTP menu when you want to send an image via e-mail. By using Mail (SMTP) function, you can send a mail with attached image which has been shot linked with the external sensor input or with the built-in motion detection function. The image file can also be sent periodically.
  • Page 52 7.  Setting  Off: Select if no authentication is necessary when an e-mail is sent. On: When authentication is necessary an e-mail is sent, select one of the authentication methods from the followings. SMTP: Select if SMTP authentication is necessary when an e-mail is sent. POP before SMTP: Select if POP before SMTP authentication is necessary when an e-mail is sent.
  • Page 53 7.  Setting  7.2.2.2 Alarm Sending Set to send the mail with connection to the alarm detection by the external sensor input or by the built-in motion detection function. Alarm sending：Select On to set to send mail with connection to the alarm detection. File attachment：Set whether an image file is attached to the mail sent or not.
  • Page 54 7.  Setting  7.2.2.3 Periodical Sending You can set to send an image file by SMTP server periodically by selecting On to send the image file by SMTP server linked with setting period. Image file name：Type the file name of the image sent by SMTP up to 10 alphanumeric characters, - (hyphen) and _ (under score).

  • Page 55: Http Event

    7.  Setting  7.2.3 HTTP Event Use this menu to set up for capturing and sending images to an HTTP server. By using HTTP client function, you can send the image and audio file which has been shot and recorded linked with the external sensor input or with the built-in motion detection function to HTTP server.
  • Page 56 7.  Setting  7.2.3.2 Alarm Sending Set to send the mail with connection to the alarm detection by the external sensor input or by the built-in motion detection function. Alarm sending：Select On to set to send mail with connection to the alarm detection. Motion Detection：Click it on for using Motion Detection function as a sensor.
  • Page 57 7.  Setting  7.2.4 Schedule When you click Schedule on the Advanced mode menu, the Schedule setting menu appears. This is the same menu as the setting menu which is displayed when you click Schedule to set Effective period and Schedule in FTP client setting menu, e-mail (SMTP) setting menu, Alarm out setting menu and so on.
  • Page 58 7.  Setting  7.2.5 Motion Detection When you click Motion Detection on the Advance mode menu, the Motion Detection setting menu appears. There are three Motion Detection functions as sensors to set for different detecting zones. Each one has Threshold and Sensitivity inputs which you can adjust to specific zone sequentially.
  • Page 59 7.  Setting  Carry out the following steps： 1. Click On to Motion Detection 1 choose one of eight orders. 2. A detecting zone 1 appears and use mouse to adjust and move the zone boundaries and position. 3. Use tool bar to set Threshold and Sensitivity value. 4.
  • Page 60 7.  Setting  7.2.7 Alarm Input When you click Alarm Input on the Advance mode menu, the Alarm input setting menu appears. You can set in this menu to control the external alarm input of I / O port on the rear of the device linked to FTP, SMTP, and HTTP sending function.
  • Page 61 7.  Setting  7.2.9 Alarm buffer You can set the Pre-alarm image and audio (the image and audio before the alarm detection) and the Post - alarm image and audio. These can be set when Alarm sending FTP client setting menu or Image memory setting menu is set to On, and besides when Use alarm buffer is selected.

  • Page 62: Campro Express

                                                                8.  CamPro  Express  User’s  Manual    CamPro Express User’s Manual This Chapter explains how to install CamPro express and different between server and client version.
  • Page 63 8. CamPro Express User’s Manual  Networking Suggestion AirLive CamPro Express is optimized for small-scale project, simple LAN or simple WAN environment. Place the system behind firewall or IP sharing device to efficiently protect this system from hackers’ attack. AirLive CamPro Express is consisted of SERVER version and CLIENT version. SERVER version limits one installation.
  • Page 64 8.  CamPro  Express  User’s  Manual [ Step 1 ] Please insert AirLive CamPro Express CD into CD-ROM drive. Go to AirLive CamPro Express Server and click for the installation. [ Step 2 ] Select language The Installation Wizard will select the language of your operation system intelligently. AirLive CamPro Express supports three languages ：...
  • Page 65 8.  CamPro  Express 【Step 4】 Select language Click “Next” to begin the installation process.                   【Step 5】 Please read the License Statement and select “Yes” to accept and continue.        ...
  • Page 66 8.  CamPro  Express  User’s  Manual [ Step 7 ] Choose Destination Location or click “Next” simply Specify the Destination Folder; you may click “Browse…” to select a folder other than the default one. Click “Next” to continue. Note: The default location is deemed adequate for most situations, it is recommended that you  ...
  • Page 67 8. CamPro Express User’s Manual          [ Step 10 ] Start Copying Files page pop out, review all your configuration that you have made. Click “Next” to accept these setting and continue. Note: The installation process may take several minutes to complete, depending on the handling capability of your computer system (refer to Section 7.1.2 System Requirement for system requirement detail)
  • Page 68 8.  CamPro  Express  User’s  Manual Setting: 1. Run the Airlive CamPro Express-->Admin. 2. Select “E-MAP” then “Add Area”. 3. Enter the Area Name then Create. 4. Select area name then select 5. When search completed select “Create”. “Auto Add Device”.  ...
  • Page 69 8. CamPro Express User’s Manual  6. Select the ipcam device icon 7. Select the ipcam device icon then select “Image Setting” . then select “Motion Detcetion”. 10. Setting motion detection area in this page. 9. Select the ipcam device icon then select “Image Alarm”. 11.
  • Page 70 8.  CamPro  Express  User’s  Manual 10. Setting motion detection alarm in this page. 11. Select “SystemAdm” then select “Rotation” 12. Setting rotation place in the monitor 66  AirLive POE-260CAM User’s Manual   ...
  • Page 71 8. CamPro Express User’s Manual  12. Run the Airlive CamPro Express-->Monitor.   8.1.1 System Requirement AirLive CamPro Express is consisted of SERVER version and CLIENT version. SERVER version limits one installation, license key are required whenever adding devices for central management. SERVER version includes Admin, Monitor, Control and Web Monitor programs.
  • Page 72 8.  CamPro  Express  User’s  Manual System Requirement- SERVER version P-4 3.0G 1G or above Windows XP Professional Service Pack2 Operating System (English/Traditional Chinese/Simplified Chinese) Windows Vista Home Basic/Home Premium/Business/Ultimate 10/100 Mbps Fast Ethernet Network Display Card 1024 x 768 (XVGA) or above System Requirement- CLIENT version P-4 1.2G 1G or above...

  • Page 73: Start Service Program

    8. CamPro Express User’s Manual  8.2 Start Service Program 8.2.1 Automatically Starts Upon System Boot Up Only one instance of AirLive CamPro Express Server’s start service program can be running at a time. The computer with the running startup service program will become a AirLive CamPro Express Server.

  • Page 74: Admin Program

    8.  CamPro  Express  User’s  Manual 8.3 Admin Program 8.3.1 Running the Admin Program 【Step1.】Select Start \All Programs \AirLive CamPro Express \ Admin 【Step2】 System Log on window. Server Location: “127.0.0.1” is the default for local server. If you want to access server from client, then please enter the IP of server to this text box.
  • Page 75 8. CamPro Express User’s Manual  8.3.2 Admin Interface Overview                       Menu Bar System Setup eMap Interface   The System Admin screen is divided into three areas: The Menu Bar area The System Setup area The eMap Interface area If your system does not display the screen properly, please check if your display resolution is at least 1024 x 768, and that the font size is Windows system default.
  • Page 76 8.  CamPro  Express  User’s  Manual 8.3.3 System Management Overview Select SystemAdm icon in System Setup Area, you will see the button in Menu Bar change accordingly. Button Use To E-Mail Setting: Specify the email outgoing server for sending security alert. Holiday Setting: Specify the calendar holidays for schedule setting which is not included in weekly routine.
  • Page 77 8. CamPro Express User’s Manual  Email Setting 【Step1】 By selecting E-Mail button( ) from the Menu Bar. 【Step2】 You can specify the email server that will be used when sending security alerts via email. 【Step3】To authenticate on the mail server, check SMTP Authentication and enter your user name and password on the mail server.
  • Page 78 8.  CamPro  Express  User’s  Manual Holiday Setting   【Step1】By selecting Holiday button from Menu Bar. You may specify any calendar holidays except weekend that may affect the security system settings. Export: If you have installed multi sites with AirLive CamPro Express server they might require the same holiday setting, you can set on one server first, and use the “Export”...
  • Page 79 8. CamPro Express User’s Manual          DNS Setting It is designed for the DNS resolution between AirLive CamPro Express server and IP device. Your video IP device will connect server via IP address of server if you did not enable DNS Resolution. But your IP device will connect server via Domain Name which your server registered, so that alarm action could be executed. ...
  • Page 80 8.  CamPro  Express  User’s  Manual Storage By selecting Storage button from the Menu Bar, you may configure the storage and recycling rule. There is two different areas, namely area 1 (include path1 and storage1) and area 2 (include path2 and storage2): Area 1: is assigned the disk to store recorded data.
  • Page 81 8. CamPro Express User’s Manual  Note: Recording video over a long period of time will consume large amounts of disk space. Make sure that you have at least 2GB disk space available if you want to use recording function. Path 2 is assigned for the backup purpose, it is an optional service. If this is configured, identical recording information will be written to both path 1 and path 2.
  • Page 82 8.  CamPro  Express  User’s  Manual     Rotation By selecting Rotation button from the Menu Bar, you can set the camera to assigned split screen and rotation interval. 【Step 1】Select the Tab of split screen, 4CH, 9CH and 16CH. 【Step 2】 Assign camera to split screen: Take 16-splitscreen as example: select Tab of 16CH, and select the split-ed screen (remark the selection by changing color to...
  • Page 83 8. CamPro Express User’s Manual          8.3.4 User Group The User Group functions in System Setup area is for managing user privileges. Default user “Administrator” is created with full privileges during installation. You may add users to the system and differentiate their privilege by designating them to different groups. Button Use To Button...
  • Page 84 8.  CamPro  Express  User’s  Manual User Belongs 【Step3】 Designating a User to a Group Select the “User Belongs” tab to designate a user to a group. Select the group name and move it between “Selected group” and “Unselected group”. Click “OK” to continue.
  • Page 85 8. CamPro Express User’s Manual          Group Admin Group is the user group that has the full privilege to the Admin and Monitor programs. user “Administrator”, system default and belong to “Admin Group”, can add users and assign users to whatever user group.
  • Page 86 8.  CamPro  Express  User’s  Manual 【Step3】 Select the “Function” tab to designate function to a group. Select the function list and move them from “Unselected function” to “Selected function”. Click “OK” to continue. 【Step4】 After setting both Tab of “General” and “Function”, click “Create” to save the setting.
  • Page 87 8. CamPro Express User’s Manual          8.3.5 Area and eMap management   Area refers to the geography and device scope of AirLive CamPro Express. Area is a prerequisite of any device setting (device includes: video server, LanCam, camera image, relay or sensor), AirLive CamPro Express provides multi-areas to meet user different requirement.
  • Page 88 8.  CamPro  Express  User’s  Manual Button Overview When you select eMap icon, Menu Bar will display the following functions: Button Use to Add Area: This button allows you to add a new area under eMap branch. Remove SubArea: This button allows you to remove all areas and devices that are under the eMap branch.
  • Page 89 8. CamPro Express User’s Manual  Add Area 【Step1】 Select eMap icon from the System Setup. 【Step2】 Click Add Area button from the Menu Bar. An Aarea Setting window will pop up. Enter the name to the “Area Name” textbox. 【Step3】Click “Create” to save setting, a newly created area demonstrate as following: Before Add Area After Add Area  ...
  • Page 90 8.  CamPro  Express  User’s  Manual Remove SubArea Select eMap icon, then click the Remove All Areas button. A warning message pops up confirming if you want to remove all areas and devices under area. Click “OK” to confirm. Rename the Area Select Area icon, then click the Rename Area button.
  • Page 91 8. CamPro Express User’s Manual  Resize eMap Icon 【Step1】 Select Device Ratio button in the Menu Bar. A Resize eMap icon window pops up. 【Step2】Select the ratio of device and click “OK”, the icon display in eMap interface will change it’s ratio accordingly. Device Management (LanCam, Video Server, I/O Controller) New device should be added and configured in AirLive CamPro Express Admin program.
  • Page 92 8.  CamPro  Express  User’s  Manual 【Step2】After device is added, please process the Image Setting Note: In the left example, the LanCam now appears under Area icon - the device tree of System Setup area, and of cameras (images) icon appear under the camera tree.
  • Page 93 8. CamPro Express User’s Manual  LanCam Select LanCam icon When select LanCam icon in System Setup area, the buttons display in Menu Bar as left bar. LanCam Button Overview Button Use To LanCam Setting: to configure IP/ Port Number associated to a selected device, it displays the information set in Add LanCam button for further modify Remove LanCam: to remove the configuration of a selected LanCam including the image under it.
  • Page 94 8.  CamPro  Express  User’s  Manual LanCam Setting Overview When select Camera Image icon in System Setup area, the buttons display in Menu Bar as following: Button Use To Image Setting: to configure frame per second of recording and activate schedule recording for that camera image. Remove Image: to remove all the configuration of a selected camera image.
  • Page 95 8. CamPro Express User’s Manual  Schedule Recording: you may define the “frame per second” (only for MJPEG camera) and recording schedule. Save Location Schd1: here display the alias of recorded path. Recording Type: Schedule recording could be activated by clicking to select “Always” or “Schedule”, and check Recording Type of “Motion Detection” to significantly reduce the storage of schedule recording.
  • Page 96 8.  CamPro  Express  User’s  Manual Schedule Recording 【Step1】Select the Image icon and click Image Setting button to bring up the Image setting window. 【Step2】Select “Recording Type” Check the Schedule in Recording Type first, and you will find that the Schedule Setting button is enabled.
  • Page 97 8. CamPro Express User’s Manual  If an error message pops up, please check if any related device is unable to connect due to the information described in Error Message window. Solve the problem, and then go back to LanCam Setting button to configure this device again.  Remove Image Remove all the configuration of a selected camera image.
  • Page 98 8.  CamPro  Express  User’s  Manual 【Step3】The “Holiday” Option “Holiday” check box only works with Schedule, you may click to check “Holiday” to activate alarm action full day during holiday, regardless the scheduled time in previous setting. The holiday is also user-definable. 【Step4】The “Alarm Interval”...
  • Page 99 8. CamPro Express User’s Manual  Alarm Action Table Alarm Action Use To Email The email of breached device, one Email receiver at an action. Live Video The live video of breached camera, it will pop up in Monitor’s 4-split screen. Recording The alarm recording of breached camera; it is set by number of seconds.
  • Page 100 8.  CamPro  Express  User’s  Manual Preset Setting Click the Preset button to bring the preset setting dialog, as shown below: 【Step1】Select a Preset Location from the dropdown list and give it a meaningful name in Preset Name. 【Step2】 Press “||” to pause the video location.
  • Page 101 8. CamPro Express User’s Manual  【Step3】Sensitivity and Frequency setting. Sensitivity refers to the pixels of image changes, and Frequency refers to the No of frame mapping. Note: The size of red frame is configurable in Motion Detection Granularity. Different camera may have different interface for motion detection adjustment. Some may require you to install Active-X components.
  • Page 102 8.  CamPro  Express  User’s  Manual Remove LanCam Click the Remove LanCam button to remove the video node. You will be asked to confirm the removal. If you had dragged this video source to the e-map, the icon of this camera in the e-map will also be removed.
  • Page 103 8. CamPro Express User’s Manual  Sensor (Digital Input) Many video gateways and LAN cameras has GPIO port. The digital inputs can be connected to sensors, while digital outputs can be connecting to relay switches. In System Setup tree, a sensor is represented by (un-configured sensor) or (configured sensor) icon, and relay switch is represented by icon.
  • Page 104 8.  CamPro  Express  User’s  Manual Remove Sensor Click [Remove Sensor] to remove the selected sensor. You will be asked to confirm the deletion. Breach The alarm actions are the same as those for LAN camera, with two additional alarm actions: [Enable DI] and [Disable DI].
  • Page 105 8. CamPro Express User’s Manual  Tools in Menu Bar of eMap interface eMap tools bar will appear above the eMap Interface area after the picture that you uploaded to the eMap Interface area. The tools of eMap interface could be used to control the EMap background as following: Pointer：to drag the device icon on the interface Area Zoom：to enlarge background from the specified area selected by mouse...

  • Page 106: Monitor Program

    8.  CamPro  Express  User’s  Manual 8.4 Monitor Program AirLive CamPro Express Monitor program could be selected from the Program Path; user may log on monitor program through Monitor.exe or Web monitor. You may access AirLive CamPro Express server thru IE browsing by entering the URL. (Format is: IP address of server and \Web.
  • Page 107 8. CamPro Express User’s Manual  8.4.2 Monitor Program Interface Video Display Area Camera Selection Local Video Setting PT Control Interface System   Setting     Display Selection Alarm Notification Log Alarm eMap The User Interface has been classified into the following functions: Video Display Area Display Selection Alarm Notification Log Camera Selection...
  • Page 108 8.  CamPro  Express  User’s  Manual 8.4.4 Camera Selection Select the camera location by clicking the drop list. Display Selection Display Selection (Video of Single Camera) Select camera button in Display Selection.   Note: The number of camera varies according to the  ...
  • Page 109 8. CamPro Express User’s Manual  Start Local Record 【Step1】 Select a camera from display area by a red frame. 【Step2】Click “Local Record” button to start the recording. The text of the button will change from Local Record to Recording. The maximum of Local Record is 15 minutes and recording status will display in the Process Bar.
  • Page 110 8.  CamPro  Express  User’s  Manual Snapshot Click “Pause” button to get a still image first, then click “Snapshot” button to save the image in JPG format. Transfer to AVI Click the “Record AVI” to export the image to the AVI format. Assign a file name, a location, and a vide compression option.
  • Page 111 8. CamPro Express User’s Manual  8.4.6 PT Control Interface If your IP camera or analogue camera under Video Server has PTZ function, you may use AirLive CamPro Express control interface to view different angle of Camera by clicking button on PT Control Interface. 1: PT Speed: You may select the drop list to change speed of camera movement.
  • Page 112 8.  CamPro  Express  User’s  Manual Note: “Relay Setting” button use the same button of Cancel Alarm, the text varies according to alarm status. 【Step1】Disable a System Alarm When a “Breach Alert” message appears at the bottom of the Video display area, an alarm has occurred and warn user by following methods: The text of the “Relay Setting”...
  • Page 113 8. CamPro Express User’s Manual            Server Query The Server Query button allows you to playback recorded video of “Schedule Recording” or “Alarm Recording”. This function also provides functions of exporting video files to the AVI format and taking snapshots. Basic Operation 【Step1】Click “Server Query”...
  • Page 114 8.  CamPro  Express  User’s  Manual Alarm Query 【Step1】Click “Alarm Query” button. 【Step2】Open a window to set query criteria. Query Alarm Log via criteria setting of: “Display Alarm Only” or “Display Alarm and Actions” “Alarm location” ” Alarm Type” “Query date” 【Step3】A query result will appear in the lower spreadsheet.
  • Page 115 8. CamPro Express User’s Manual  Talk Enabled/Disabled (Two-way Audio)   The system provides two-way audio features that the user can use to start an audio conversation with another person near the camera. Talk Enable/Disabled displays three different status, as below: Talk Enabled The device support two-way audio function, click this button to start audio conversation.

  • Page 116: Web Monitor

    8.  CamPro  Express  User’s  Manual 8.5 Web Monitor Web Monitor provides User an easy access thru IE to get real time video and central monitoring. 8.5.1 Logon Web Monitor Log on Web Monitor from server Start Program Files AirLive CamPro Express Web Monitor。 Log on Web Monitor from client You may open IE browser and entering the URL in the format of server IP and “\Web”.
  • Page 117 8. CamPro Express User’s Manual  【Step3】 For the first time login Web Monitor, system will auto detect if this computer has installed VideoPlayer Control or not. It not installed yet, an installation page will pop up for user to install this program. 【Step4】 After install all these required program, the Web Monitor will pop up, the operation process are exactly same as Monitor program.

  • Page 118: Multi Playback

    8.  CamPro  Express  User’s  Manual 8.6 Multi Playback Multi Playback is a program designed for quickly accessing and searching multiple schedule recording files. Since this program will consume a large amount of memory and CPU time, it is strongly recommended that this program only run on a remote computer, not on the server itself.
  • Page 119 8. CamPro Express User’s Manual  8.6.2 Main Display Area   Function Area Video Display and Query Result Area Query Criteria Area   The user interface of Multi Playback can be divided into three main areas: Function Area, Video Display and Query Result Area and Query Criteria Area. The following three sections will describe these three areas in detail.
  • Page 120 8.  CamPro  Express  User’s  Manual Recording History Query   【Step 1】Click “Recording history query”   button from the Function Area. Then click to bring up the Playback Group configuration window. 【Step 2】Playback Group Setting.   Add a new playback group. Click [Add] button at the group window.
  • Page 121 8. CamPro Express User’s Manual  Modify a playback group. Modify an existing playback group by first select a playback group and then click “Modify”. The system will show the window to modify group. Use the split screen to select playback location and to select/unselect cameras in the group.
  • Page 122 8.  CamPro  Express  User’s  Manual 【Step 4】 Playing Playback Group. The system will playback all recordings shown in the query result window. During the multiple playback, double clicking any screen will switch the display to single channel mode. The playback can be controlled with the following.
  • Page 123 8. CamPro Express User’s Manual    Recording History Playback Configuring and operating for the recording history playback function is very similar to recording history query. 【Step1】Click “Recording history playback” button from the Function Area. 【Step2】Select playback criteria. Select Group Name: When user clicks the group name, the image viewing area will automatically show the configured playback group with black channels.
  • Page 124 8.  CamPro  Express  User’s  Manual Video Display and Query Result Area Depending on the function in use and query criteria selected, this area will show either query result for recording history or multiple channel playback for historical recordings Query Criteria Area Query criteria area provides user ability to specify query criteria for searching historical recording.
  • Page 125 8. CamPro Express User’s Manual  APPENDIX A: IIS Installation for Windows Vista   To Install IIS for Windows Vista version, please do the followings:  【Step1】 .     Click “Continue”. 【Step2】 Start Control Panel Program and Features Click Turn Windows features on or off. The Windows Features dialog box opens. ...
  • Page 126 8.  CamPro  Express  User’s  Manual                     【Step3】 Select the Internet Information Services check box   【Step4】 Double-click (or expand) “Web Management Tools”, double-click “IIS 6 Management Compatibility”, then select the “IIS 6 Management Console, IIS 6 Scripting Tools, IIS 6 WMI Compatibility, IIS Metabase and IIS 6 Configuration...
  • Page 127 8. CamPro Express User’s Manual                【Step5】 Double-click (or expand) World Wide Web Services, double-click Application Development Features, then select the ASP and ISAPI Extensions check box.                        ...
  • Page 128 8.  CamPro  Express  User’s  Manual APPENDIX B: Security Setting in Web Monitor under Vista   【Step1】  Launch Internet Explorer Browser Select Internet Options Select Security Choose Trusted sites and click Sites button. 【Step2】  Input the web server IP, example: http://127.0.0.1.  ...
  • Page 129 8. CamPro Express User’s Manual              【Step3】 Select Trusted sites then click “Custom level…” button. 【Step4】  Find Initialize and script ActiveX controls not marked as safe option, then select “Enable”.     125  AirLive POE-260CAM User’s Manual       ...
  • Page 130 8.  CamPro  Express  User’s  Manual APPENDIX C: Frame Rate & Bit Rate Table This chapter provides tables that help you to optimize your IP camera with your network environment. Base on your network upload environment, choose the best Image-Quality setting. For example, if the network environment is ADSL 256Kb (upload) / 2Mb (download), the most fluent Image-Quality needs to set up under 256 Kb situation.
  • Page 131 8. CamPro Express User’s Manual  MJPEG @ 15fps / kbps Quality 640*480 320*240 160*120 Excellent 4000 1500 Detailed 2400 Good 1600 Standard 1300 Medium MJPEG / kbps, fps Quality Frame-Rate Current Current Image-Size Setting Setting Bitrate Frame-Rate 640*480 Excellent 4000 640*480 Excellent 1600 640*480 Good 1600 640*480...
  • Page 132 8.  CamPro  Express  User’s  Manual         System Requirement & D1 Performance of 16 Channel IP Camera   Equipment Configuration Software: MainConsole Version 2.6.4 Professional CPU: AMD Athlon 64*2 @3600+MHz Memory: 2048 MB (2 x 1024 DDR2-SDRAM ) Ethernet: VIA Rhine II Fast Ethernet Adapter Hard Disk:...
  • Page 133 8. CamPro Express User’s Manual  APPENDIX D: Storage Requirement Table This chapter provides tables that help you set your recording storage system. Please refer to the following table to find out the capability for recording into your hard disk. MPEG4 Storage Requirement GB / channel / day @ 30fps Quality 640*480 320*240...
  • Page 134 8.  CamPro  Express  User’s  Manual APPENDIX E: How can I configure Alarm Output with Alarm Input     1. DI/DO connection picture 2. DI need a sensor can output a DC voltage between 5V-12V. For example we are use a sensor can output DC12V IR sensor Input DC 12V Output DC12V 3.
  • Page 135 8. CamPro Express User’s Manual          4. Alarm output Setting like below picture   5. Alarm input Setting like below picture   131  AirLive POE-260CAM User’s Manual       ...
  • Page 136 8.  CamPro  Express  User’s  Manual 6. Connect all device to DI/DO connector (Below pictures are my example, not necessarily suits all kind of siren.) 7. Device connection pictures (Below pictures is the example, not necessarily suits each all kind of siren} 132 ...
  • Page 137 8. CamPro Express User’s Manual          2  1    1    133  AirLive POE-260CAM User’s Manual       ...
  • Page 138 8.  CamPro  Express  User’s  Manual         2                                    134  AirLive POE-260CAM User’s Manual   ...
  • Page 139 8. CamPro Express User’s Manual              Above pictures is the example, not necessarily suits each one When sensor receive signal will start the siren .   135  AirLive POE-260CAM User’s Manual       ...
  • Page 140 8.  CamPro  Express  User’s  Manual APPENDIX F: How can I configure Alarm Output with Motion Detection   1. DO connection picture         2. DO need a siren/buzzer. For example we are use a siren that use DC12V. Siren Input by DC 12V  ...
  • Page 141 8. CamPro Express User’s Manual          3. Alarm output Setting like below picture     4. When Motion Detection will start the siren.   137  AirLive POE-260CAM User’s Manual       ...
  • Page 142 8.  CamPro  Express  User’s  Manual APPENDIX G: How can I configure DI/DO at CamProExpress 1. Add an IPCAM then select Sensor   2. Click “Sensor setting “ then enter a name for Location                ...
  • Page 143 8. CamPro Express User’s Manual            3. Select Relay and click “Relay setting” then enter a name for Location      4. Select sensor then click “Sensor Alarm”                                  5. Select always or schedule enable alarm      139  AirLive POE-260CAM User’s Manual       ...
  • Page 144 8.  CamPro  Express  User’s  Manual           6. Add alarm action: when sensor alert will enable Relay1                                    7. Add alarm action: after 5 sec turn off Relay1    140  AirLive POE-260CAM User’s Manual   ...
  • Page 145 8. CamPro Express User’s Manual          8. Click “OK” to save setting          9. Turn on the “Sensor input1” in IPCAM WEB UI                    10. Connect DI/DO device to the IPACM    11. Click ok to finish the setting.        141  AirLive POE-260CAM User’s Manual       ...
  • Page 146 8.  CamPro  Express  User’s  Manual         APPENDIX H: How can I configure Motion Detection with Alarm output at CamProExpress Please refer the “How can I configure DIDO at CamProExpress” guide to setting DI/DO first Select IPCAM and click “MotionDetection” then setting motion detect area.  ...
  • Page 147 8. CamPro Express User’s Manual          Select always or schedule enable alarm Add alarm action: when MotionDetect will turn on Relay1 Add alarm action: after 5 sec turn off Relay1                        ...
  • Page 148 8.  CamPro  Express  User’s  Manual         Click “OK” to save setting   Click ok to finish setting.     144  AirLive POE-260CAM User’s Manual   ...

  • Page 149: Technical Specification

    9.  Technical  Specification Technical Specification POE260CAM Models 1/4” Progressive scan CMOS sensor Image sensor F2.0, 4.3 mm Lens 55° horizontal Angle of view 10x digital Digital Zoom 0.5 Lux Min Illumination 50dB S/N Ratio Motion JPEG Video Compression MPEG-4 Part2 (ISO/IEC 14496-2), Profile: SP Motion JPEG: Resolutions 3 resolutions from 640x480 to 160x120 via API,...
  • Page 150 9.  Technical  Specification Alarm input 5V/12V DC Alarm Input/Output Alarm output Max 30W Input: alarm buffer, alarm input, motion detection Alarm and event Output: FTP, SMTP, HTTP event, alarm output management Pre-and post alarm buffer RJ-45 for Ethernet 10/100 Base-T (with PoE) Connectors DC power jack Terminal blocks for 1 alarm input, 1 output...
  • Page 151 9.  Technical  Specification RJ-45 for Ethernet 10/100 Base-T (with PoE) Connectors DC power jack Terminal blocks for 1 alarm input, 1 output Reset push switch 3.5 mm jack for Mic/Line, 3.5 mm jack for line out PC+ABS casing Casing 12V DC, 1A, Max 5W Power PoE (Power over Ethernet) Built-in IEEE 802.3af 0 ~ 50 ℃...
  • Page 152 9.  Technical  Specification ActiveX - A standard that enables software components to interact with one another in a networked environment, regardless of the language(s) used to create them. Web browsers may come into contact with ActiveX controls, ActiveX documents, and ActiveX scripts.
  • Page 153 9.  Technical  Specification Bitmap - A bitmap is a data file representing a rectangular grid of pixels. It defines a display space and color for each pixel (or "bit") in the display space. This type of image is known as a "raster graphic." GIF and JPEG are examples of image file types that contain bitmaps.
  • Page 154 9.  Technical  Specification Client/Server - Client/server describes the relationship between two computer programs in which one program, the client, makes a service request from another program, the server, which fulfils the request. Typically, multiple client programs share the services of a common server program.
  • Page 155 9.  Technical  Specification DHCP also supports static addresses for example, computers running web servers, which need a permanent IP address. DNS (Domain Name System) - DNS is used to locate and translate Internet domain names into IP (Internet Protocol) addresses. A domain name is a meaningful and easy-to-remember name for an Internet address.
  • Page 156 9.  Technical  Specification computer, or it can be a standalone hardware device. Focal length - Measured in millimeters, the focal length of a camera lens determines the width of the horizontal field of view, which in turn is measured in degrees. FTP (File Transfer Protocol) - An application protocol that uses the TCP/IP protocols.
  • Page 157 9.  Technical  Specification GIF (Graphics Interchange Format) - GIF is one of the most common file formats used for images in web pages. There are two versions of the format, 87a and 89a. Version 89a supports animations, i.e. a short sequence of images within a single GIF file.
  • Page 158 9.  Technical  Specification Image compression - Image compression minimizes the file size (in bytes) of an image. Two of the most common compressed image formats are JPEG and GIF. Interlacing - Interlaced video is video captured at 50 pictures (known as fields) per second, of which every 2 consecutive fields (at half height) are then combined into 1 frame.
  • Page 159 9.  Technical  Specification VOP - See VOP. JPEG (Joint Photographic Experts Group) - Together with the GIF file format, JPEG is an image file type commonly used on the web. A JPEG image is a bitmap, and usually has the file suffix '.jpg' or ".jpeg." When creating a JPEG image, it is possible to configure the level of compression to use.
  • Page 160 9.  Technical  Specification Motion JPEG - Motion JPEG is a simple compression/decompression technique for networked video. Latency is low and image quality is guaranteed, regardless of movement or complexity of the image. Image quality is controlled by adjusting the compression level, which in turn provides control over the file size, and thereby the bit rate.
  • Page 161 9.  Technical  Specification Network connectivity - The physical (wired or wireless) and logical (protocol) connection of a computer network or an individual device to a network, such as the Internet or a LAN. NTSC (National Television System Committee) - NTSC is the television and video standard in the United States. NTSC delivers 525 lines at 60 half-frames/second.
  • Page 162 9.  Technical  Specification PPP (Point-to-Point Protocol) - A protocol that uses a serial interface for communication between two network devices. For example, a PC connected by a phone line to a server. PPTP (Point-to-Point Tunnelling Protocol) - A protocol (set of communication rules) that allows corporations to extend their own corporate network through private "tunnels"...
  • Page 163 9.  Technical  Specification A proxy server receives requests for Internet services (such as web page requests) from many users. If the proxy server is also a cache server, it looks in its local cache of previously downloaded web pages. If it finds the page, it is returned to the user without forwarding the request to the Internet.
  • Page 164 9.  Technical  Specification Router - A device that determines the next network point to which a packet should be forwarded on its way to its final destination. A router creates and/or maintains a special routing table that stores information on how best to reach certain destinations. A router is sometimes included as part of a network switch.
  • Page 165 9.  Technical  Specification Sockets - Sockets are a method for communication between a client program and a server program over a network. A socket is defined as "the endpoint in a connection." Sockets are created and used with a set of programming requests or "function calls"...

Table of Contents
