OWNER'S MANUAL
AIM DIPOLE
Surround Home Cinema Speakers
AIM CINEMA DIPOLE FIVE | AIM CINEMA DIPOLE THREE | AIM CINEMA DIPOLE ONE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AIM CINEMA DIPOLE ONE and is the answer not in the manual?

Questions and answers

Summary of Contents for SpeakerCraft AIM CINEMA DIPOLE ONE

  • Page 1 OWNER'S MANUAL AIM DIPOLE Surround Home Cinema Speakers AIM CINEMA DIPOLE FIVE | AIM CINEMA DIPOLE THREE | AIM CINEMA DIPOLE ONE...
  • Page 2: Installation Considerations

    The area where you will most likely be sitting when listening to your speakers is your primary listening area. 2. Mounting Location The AIM DIPOLE speakers were designed to be mounted in the side or rear walls of a home theater system, slightly above the listening position. See Figure 1.
  • Page 3 Figure 3 INSTALLATION PREPARATION FINISHED WALL When installing the AIM DIPOLE into a finished wall, please follow these instructions carefully: 1. Determine Placement Determine where in the wall the speakers will be placed, using the recommendations under “PLACEMENT”. Pay careful attention to the section on avoiding obstructions.
  • Page 4: Speaker Installation

    SPEAKER INSTALLATION Figure 6 The unique integral six foot mounting system incorporated into each AIM DIPOLE speaker allows for a quick installation by following these easy steps: 1. Remove the grille. 2. Attach the speaker cable (observing the proper polarity with your amplifier, + to + and –...
  • Page 5: Painting The Speakers

    Before painting the grilles, remove the under grille material. Put this material back into place once the grille has been painted. SpeakerCraft recommends only light spray painting, using 5 parts thinning agent to 1 part paint.
  • Page 6 GRILLE DIMENSIONS 2.470” 62.78mm 7.330” 2.010” 186.250mm 50.980mm 15.480” 14.440” 393.300mm 366.700mm...
  • Page 7: Specifications

    (190.500mm x 397.010mm) In our attempt to constantly improve our products, features and specifications are subject to change without notice. Declaration of Conformity We, Speakercraft Inc. 940 Columbia Ave. Riverside, CA 92507 declare under our sole responsibility that the products described in...
  • Page 8: Limited Lifetime Warranty

    SpeakerCraft or the SpeakerCraft Authorized Dealer will, at its option, repair or replace this product at no additional charge, except as set forth below. If this model is no longer available and can not be repaired effectively, SpeakerCraft, at its sole option, may replace the unit with a current model of equal or greater value. In some cases where a new model is substituted, a modification to the mounting surface may be required.

This manual is also suitable for:

Aim cinema dipole fiveAim cinema dipole three
