SpeakerCraft AIM8 One Brochure

A I M 8 8 " P i v o t i n g I n - C e i l i n g S p e a k e r S e r i e s
™
Accu-Grille
This exclusive grille design
produces a flat-sound absorbing
baffle that elliminates midrange
coloration, often a problem with
pivoting speakers designs -
New Construction
Brackets
SpeakerCraft goes the extra mile to ensure top
performance from your AIM8 speakers, with
brackets designed for added ease in construction.
See your SpeakerCraft dealer for details.
Sound Enclosures
SpeakerCraft' s
fire-rated sound
enclosures provide
a one-hour safety
enclosure and up
to 10dB of sound
suppression between
adjacent rooms.
Additionally, they can
serve as brackets for
new construction.
See your dealer for
specifications.
New WavePlane ™ Design
The AIM8' s remarkable new WavePlane™
design allows the woofer a more open
path of projection, which in turn enhances
midrange clarity. At the same time it "horn-
loads" the tweeter for more efficiency. The
result is tight, accurate bass from a compact
unit that' s easily installed in new or existing
construction.
Effect without
WavePlane
™
Effect with
WavePlane
™
940 Columbia Avenue, Riverside CA 92507
(800) 448-0976 Fax (909) 787-8747
www.speakercraft.com
AIM8 Five
™
• Pivoting 1" liquid cooled dampened magnesium/aluminum dome tweeter.
• Pivoting and rotating 8" *Kevlar™ cone woofer with butyl rubber surround.
• Front mounted adjustable frequency switches to allow adjustment of bass ±3 dB
and treble ±3 dB.
• State-of-the-art cross-over, large gauge air core coils, and mylar capacitors.
Efficiency: 91 dB @1w/1m
Power Recommendations: 5 to 100 watts (undistorted)
Impedance: 8/6/4 ohms, depending on switch settings
Frequency Response: 33 - 20,000 Hz ±2 dB
Diameter x Depth: 11 15 ⁄ " x 5 1 ⁄ "
1 6 2
Cut-Out Diameter: 9 3 ⁄ "
4
AIM8 Four
™
• Pivoting 1" liquid cooled hard anodized magnesium/aluminum dome tweeter.
• Pivoting and rotating 8" hard anodized magnesium/aluminum cone woofer with butyl
rubber surround.
• Front mounted adjustable frequency switches to allow adjustment of bass ±3 dB
and treble ±3 dB.
Efficiency: 90 dB @ 1W/1m
Power Recommendations: 5 to 100 watts (undistorted)
Impedance: 8/6/4 ohms, depending on switch settings
Frequency Response: 35 - 20,000 Hz ±2 dB
Diameter x Depth: 11 15 ⁄ " x 5 1 ⁄ "
1 6 2
Cut-Out Diameter: 9 3 ⁄ "
4
AIM8 Three
™
• Pivoting 1" liquid cooled aluminum dome tweeter.
• Pivoting and rotating 8" aluminum cone woofer with butyl rubber surround.
• Front mounted adjustable frequency switches to allow adjustment of bass ±3 dB
and treble ±3 dB.
Efficiency: 89 dB @ 1W/1m
Power Recommendations: 5 to 100 watts (undistorted)
Impedance: 8/6/4 ohms, depending on switch settings
Frequency Response: 37 - 20,000 Hz ±2 dB
Diameter x Depth: 11 15 ⁄ " x 5 1 ⁄ "
1 6 2
Cut-Out Diameter: 9 ⁄ "
3
4
AIM8 Two
™
• Pivoting 1" liquid cooled treated silk dome tweeter.
• Pivoting and rotating 8" resin reinforced fiberglass cone woofer with butyl rubber surround.
• Adjustable frequency switch for treble ±3 dB.
Efficiency: 89 dB @ 1W/1m
Power Recommendations: 5 to 100 watts (undistorted)
Impedance: 8 ohms
Frequency Response: 40 - 20,000 Hz ±2 dB
Diameter x Depth: 11 ⁄ " x 5 ⁄ "
15 1
1 6 2
Cut-Out Diameter: 9 ⁄ "
3
4
AIM8 One
™
• Pivoting 1" treated silk dome tweeter.
• Pivoting and rotating 8" injection moulded polypropylene cone.
Efficiency: 88 dB 1W/1m
Power Recommendations: 5 to 100 watts (undistorted)
Impedance: 8 ohms
Frequency Response: 40 - 20,000 Hz ±2 dB
Diameter x Depth: 11 ⁄ " x 5 ⁄ "
15 1
1 6 2
Cut-out diameter: 9 ⁄ "
3
4
Limited
LIFETIME
*All AIM Speakers Hold U.S. Patent
™
# D419,561 & 6,101,262.
