Summary of Contents for Comfort audio DM80

  • Page 1 Comfort Digisystem User Manual SecureStream Technology Microphone DM80 English...
  • Page 2: Table Of Contents

    User Manual Table of Contents Page Introduction to the Comfort Digisystem Presenting the Microphone DM80 Functions of the Microphone DM80 Getting Started First Time Use Menu More Functions Radio Range and Channels Attached Accessories Other original Accessories Troubleshooting Service and Warranty...
  • Page 3: Introduction To The Comfort Digisystem

    Presenting the Microphone DM80 A microphone that not only serves as a conference micro-phone, but can also be connected to telephones. The DM80 can be connected via Bluetooth to a mobile phone/portable phone, and the microphone can be connected via a cable to a telephone using a 2.5 mm headset socket.
  • Page 4: Functions Of The Microphone Dm80

    Functions of the Microphone DM80 Pairing button Answering button Menu control Multifunction socket Function indicator On / Off Clip Microphone Answering button Charging socket Display Microphone DM80 Microphone DM80...
  • Page 5: Getting Started

    Getting Started Charging The Microphone DM80 is chargeable. Charge the DM80 at least two hours before you use it for the first time. An empty battery is fully charged within two hours. During charging, the function indicator shows red and a lightning bolt appears through the battery symbol in the display.
  • Page 6: First Time Use

    Connect the clip-on-microphone (or other original microphone) or headset cable if desired. The clip-on-microphone can be attached to your clothes with its clip. The DM80 can be secured using the clip or hung around the neck using the necklace provided (two lengths). Microphone positions Two settings are possible;...
  • Page 7: Menu

    Scroll down To access the menu, press the menu control: Back Communication Channel Pair Bluetooth Phone Inputs Extern mic Line in Phone Mic gain Line gain Settings PIN code Charge Language Name Func. indicator Factory Reset Key lock About Microphone DM80...
  • Page 8 If the message Channel combination not possible appears during pairing, this indicates that the selected frequency is outside the frequency range within which the unit can transmit/receive. Check possible channels in the Communication - Channel menu. Microphone DM80...
  • Page 9 In units with both transmitters and receivers, the pairing button controls the transmitter. The transmitter and receiver are paired separately in these units. The code key is always the same for the transmitter and the receiver when these are built-in in the same unit. Microphone DM80...
  • Page 10 Use your telephone as usual; the voice of the person you are talking to is transferred via the cable to the DM80; from there it is sent wirelessly to your Digisystem receiver. In level adjusts the level of incoming sound level for telephony (not BT).
  • Page 11 This function does not affect charging and pairing status. Factory Reset Resets the unit to it´s original settings and erases all pairing information. To obtain security against eavesdropping, a new code key must be generated or received from another unit in existing coded system. Microphone DM80...
  • Page 12 Key lock Here you can activate the key lock and thereby lock all buttons. Once the key lock has been activated, Unlock keys? appears in the display. Select Yes to unlock. About Here you find software information. Microphone DM80...
  • Page 13: More Functions

    When a Bluetooth telephone has been successfully connected, the indicator flashes blue five times. During an ongoing telephone call, the indicator flashes blue every second second. When Clear settings is selected, the indicator flashes blue ten times. Microphone DM80...
  • Page 14 The Microphone DM80 can be connected to two Bluetooth telephones at the same time. During a telephone call the DM80 is used as a hands-free that receives the sound and transfers it on to the call partner. The sound from the call partner's telephone is sent from the DM80 to a paired Digisystem receiver.
  • Page 15 Telephone is activated and the headset cable is connected to the DM80. The reason for this is that it must not be possible for Bluetooth calls to be activated by mistake during an ongoing phone call.
  • Page 16 For more information, see “More Functions”. Number presentation At incoming calls, name and number of the caller are shown in the display, if they are registered in the telephone book and if the telephone supports this function. Microphone DM80...
  • Page 17: Radio Range And Channels

    In addition to channels 1-3, under Extended there are bands A-F, which require a licence in most European countries: B 854 - 863 MHz 833 - 854 MHz 865 - 872 MHz Microphone DM80...
  • Page 18: Attached Accessories

    The charger has short-circuit and automatic overload protection. Disconnect the charger from the socket after use. Other original Accessories Boom microphone Headset microphone. Earworn microphone A microphone that is attached around the ear. Charging stand For other accessories, please visit our website, www.comfortaudio.com Microphone DM80...
  • Page 19: Troubleshooting

    Loud hissing noise (no sound transfer) Check that the units are paired. The unit will not start during charging Disconnect the charger. Choose Settings - Charge - Auto power off in the menu. For more detailed troubleshooting, visit our website at www.comfortaudio.com Microphone DM80...
  • Page 20: Service And Warranty

    Service and Warranty Comfort Audio AB accords a limited warranty for two years as of the date of delivery. This covers all defects of manufacture and materials. For accessories the warranty period is 90 days as of the date of delivery. Local agreements or regulations may exist.
  • Page 21: Important Safety Instructions

    9) Protect the power cord from being walked on or pinched particularly at plugs convenience receptacles. and the point where they exit from the apparatus. 10) Only use attachments/accessories specified by Comfort Audio AB. 11) Unplug this apparatus during Iightning storms or when unused for long periods of time.
  • Page 22 19) Never charge product in closed, unaired spaces such as handbags, cases or other closed storage bags. 20) Only use batteries and power supply specified by Comfort Audio AB. 21) You must not change the battery yourself; please contact your point of purchase.
  • Page 23 Microphone DM80...
  • Page 24 Manufactured by: Comfort Audio AB Box 154, SE-301 05 Halmstad, Sweden Tel. +46 35 260 16 00 Fax +46 35 260 16 50 info comfortaudio.com www.comfortaudio.com...
