Summary of Contents for Comfort audio DM10
- Page 1 Comfort Digisystem User Manual SecureStream Technology Microphone DM10 English...
-
Page 2: Table Of Contents
User Manual Table of Contents Page Introduction to the Comfort Digisystem Functions of the Microphone DM10 Getting Started First Time Use Menu More Functions Radio Range and Channels Attached Accessories Other original Accessories Trouble Shooting Service and Warranty Technical Data... -
Page 3: Introduction To The Comfort Digisystem
The products are easy to use, whether you use a hearing aid or not. Before using the product, please read this User Manual carefully. Using the Microphone DM10 transmitter, the signal is transferred digitally, resulting in an excellent clear sound. -
Page 4: Functions Of The Microphone Dm10
Functions of the Microphone DM10 Pairing button Function button Menu control Input for external sound source Function indicator Charging socket On / Off Microphone Clips Display Microphone DM10 Microphone DM10... -
Page 5: Getting Started
Getting Started Charging The Microphone DM10 is chargeable. Charge the DM10 at least two hours before you use it for the first time. An empty battery is fully charged within two hours. During charging, the function indicator shows red and a lightning bolt appears through the battery symbol in the display. -
Page 6: First Time Use
30 cm. The clip-on-microphone can be attached to your clothes with its clip. DM10 can be attached with its clip or carried around the neck with the delivered neck loop (2 lengths available). Other functions are explained later in this manual. -
Page 7: Menu
Scroll down To access the menu, press the menu control: Back Communication Channel Pair Function Silence button Mic. On/Off Push to talk Push/Cont. FCR indicator Settings PIN-code Charge Language Name Inputs Func. indicator Factory Reset Key lock About Microphone DM10... - Page 8 Transmitting/receiving of pairing information along with a new code can be performed from any Comfort Digisystem unit with a display. Pairing (via pairing button) To pair units without a display, see sections more information. Pairing information or a new code key can be received by several activated units. Microphone DM10...
- Page 9 Here you can adjust the function button. If no choice has been made, the microphone sends continuously the sound it takes up. More settings are possible, see below. The chosen setting shows in the More functions display. For more information about the function indicator see Microphone DM10...
- Page 10 DM10 only sends when you press the function button. Push/Cont In this setting DM10 works like described above under Push to talk, but by pressing the menu control down (scrolling down) the microphone is switched to send continuously the sound it takes up.
- Page 11 When Line-in is activated and as soon as a cable is connected to the DM10, it switches automatically to continuous transmission, even if Push-to-talk or Mic. On/Off was chosen before. Like this it is possible to use a DM10 as a companion unit and as a multimedia connection without having to switch modes.
-
Page 12: More Functions
When using the Push to talk-function, the indicator shows green when transmission is possible and the microphone has been activated. If transmission is not possible because the channel is occupied (how to use Function FCR, see section ), the function indicator shows red. Microphone DM10... -
Page 13: Radio Range And Channels
In addition to channels 1-3, under Extended there are several channels in bands A-F, which require a licence in most European countries: 768 - 790 MHz B 854 - 863 MHz 790 - 800 MHz D 800 - 820 MHz 820 - 854 MHz 865 - 872 MHz Microphone DM10... -
Page 14: Attached Accessories
Several charging stands can be connected and used with one charger. If you use more than two charging stands, a bigger charger is necessary. Desk stand Desk stand for the Microphone DM10 . For other accessories, please visit our website, www.comfortaudio.com... -
Page 15: Trouble Shooting
Check that the transmitter and receiver are set to the same channel. Loud hissing noise (no sound transfer) Check that the units are paired. The unit will not start during charging Disconnect the charger. Choose Settings - Charge - Auto power off in the menu. Microphone DM10... -
Page 16: Service And Warranty
Service and Warranty Comfort Audio AB accords a limited warranty for two years as of the date of delivery. This covers all defects of manufacture and materials. For accessories the warranty period is 90 days as of the date of delivery. Local agreements or regulations may exist. -
Page 17: Important Safety Instructions
9) Protect the power cord from being walked on or pinched particularly at plugs convenience receptacles. and the point where they exit from the apparatus. 10) Only use attachments/accessories specified by Comfort Audio AB. 11) Unplug this apparatus during Iightning storms or when unused for long periods of time. - Page 18 19) Never charge product in closed, unaired spaces such as handbags, cases or other closed storage bags. 20) Only use batteries and power supply specified by Comfort Audio AB. 21) You must not change the battery yourself; please contact your point of purchase.
- Page 19 Microphone DM10...
- Page 20 Manufactured by: Comfort Audio AB Box154, SE-301 05 Halmstad, Sweden Tel. +46 35 260 16 00 Fax +46 35 260 16 50 info comfortaudio.com www.comfortaudio.com...
