Summary of Contents for Comfort audio DC10
- Page 1 Comfort Digisystem User Manual Conference Microphone DC10 English...
-
Page 2: Table Of Contents
User Manual Table of Contents Page Introduction to the Comfort Digisystem Functions of the Conference Microphone DC10 Functions - Charger unit Getting Started First Time Use Menu More Functions Radio Range and Channels Attached Accessories Other original Accessories Trouble Shooting... -
Page 3: Introduction To The Comfort Digisystem
The products are easy to use, whether you use a hearing aid or not. Before using the product, please read this User Manual carefully. Using the Conference Microphone DC10 transmitter, the signal is transferred digitally, resulting in an excellent clear sound. -
Page 4: Functions Of The Conference Microphone Dc10
Functions of the Conference Microphone DC10 On / Off Function indicator Pairing button Menu control/ volume control for Bluetooth Answering button for Bluetooth Mode selector Charging socket Mic/line in Multifunction socket Conference Microphone DC10... -
Page 5: Functions - Charger Unit
Functions - Charger unit Multifunction socket USB-socket Mic in (for service) Charging Line in socket Conference Microphone DC10... -
Page 6: Getting Started
Getting Started Charging The Conference Microphone DC10 is chargeable. Charge the DC10 at least five hours before you use it for the first time. An empty battery is fully charged within five hours. During charging, the function indicator shows red and a lightning bolt appears through the battery symbol in the display. -
Page 7: First Time Use
Switch on the transmitter by pressing the On/Off button for around two seconds. The Conference Microphone DC10 always starts in Omni Mode Wide as default. The position is easily changed using the mode selector on the long side of the unit. -
Page 8: Menu
To access the menu, press the menu control: Back Communication Channel Pair Bluetooth Sound Treble and Bass Equalizer Advanced settings Inputs Mic/Line in Charger unit Settings Charge Language Key lock Name Factory reset Activate key lock About Conference Microphone DC10... - Page 9 To use a receiver and transmitter together, they must be paired. All transmit- ters and receivers are default paired at the factory and will work together. To prevent eavesdropping, a new code key must be generated and trans- mitted between the units by pairing. Conference Microphone DC10...
- Page 10 The easiest way to get the same code key in the whole Digisystem is to generate a new code key from the combined unit; in that way the built-in receiver gets the same code as the rest of the system. Conference Microphone DC10...
- Page 11 Bluetooth Here you can activate Bluetooth to be able to pair the Conference Microphone DC10 with a telephone or mobile. For detailed user information, see chapter More Functions - Bluetooth Sound Treble and Bass Treble and Bass control that allows simple adjustment of the unit’s equalizer.
- Page 12 When connecting a signal source to Line in (e.g. a TV), Line in mix is selected to also receive surrounding sound through the Conference Microphone DC10. Charger unit Here you can adjust the level for Line in and Microphone in. Line in mix can also be selected for use with charger unit.
-
Page 13: More Functions
When a Bluetooth telephone has been successfully connected, the indicator flashes blue five times. During an ongoing telephone call, the indicator flashes blue every second second. When Clear settings is selected, the indicator flashes blue ten times. Conference Microphone DC10... - Page 14 Pair Phone (Communication - Bluetooth - Pair BT- Pair Phone) (code 0000) is used to pair a landline-based, wireless (DECT) or mobile phone with the DC10. Select Clear settings (Communication - Bluetooth - Pair BT- Clear settings) to clear all information about paired units.
-
Page 15: More Functions
Make a call: When you make a call, the sound is automatically transferred via the relevant Bluetooth connection (depending on the telephone's settings) to the DC10. One of the Bluetooth connections (telephone, code 0000) has priority. This means that the voice dialling and re-dialling functions only work in this tele- phone if two telephones are connected. - Page 16 Charger unit The Conference Microphone DC10 is delivered with a charger unit. Apart from charging the microphone, the unit can be connected to external sound sources. There are 2 sockets at the right hand short side of the charger unit, marked 1 and 2 (look underneath).
-
Page 17: Radio Range And Channels
In addition to channels 1-3, under Extended there are several channels in bands A-F, which require a licence in most European countries: 768 - 790 MHz B 854 - 863 MHz 790 - 800 MHz D 800 - 820 MHz 820 - 854 MHz 865 - 872 MHz Conference Microphone DC10... -
Page 18: Attached Accessories
The charger has short-circuit and automatic overload protection. Dis- connect the charger from the socket after use. Boom microphone Headset microphone. Earworn microphone A microphone that is attached around the ear. For other accessories, please visit our website, www.comfortaudio.com Conference Microphone DC10... -
Page 19: Trouble Shooting
Check that the transmitter and receiver are set to the same channel. Loud hissing noise (no sound transfer) Check that the units are paired. The unit will not start during charging Disconnect the charger. Check the selection Auto power off under Settings in the menu. Conference Microphone DC10... -
Page 20: Service And Warranty
Under normal use, battery lifetime is up to five years. Contact your point of purchase once it is time to change the battery. You are always welcome to contact us at Comfort Audio if you have any questions. Technical Data Type of transmitter: SST –... -
Page 21: Important Safety Instructions
9) Protect the power cord from being walked on or pinched particularly at plugs convenience receptacles. and the point where they exit from the apparatus. 10) Only use attachments/accessories specified by Comfort Audio AB. 11) Unplug this apparatus during Iightning storms or when unused for long periods of time. - Page 22 19) Never charge product in closed, unaired spaces such as handbags, cases or other closed storage bags. 20) Only use batteries and power supply specified by Comfort Audio AB. 21) You must not change the battery yourself; please contact your point of purchase.
- Page 23 Conference Microphone DC10...
- Page 24 Manufactured by: Comfort Audio AB Box154, SE-301 05 Halmstad, Sweden Tel. +46 (0)35 260 16 00 Fax +46 (0)35 260 16 50 info comfortaudio.com www.comfortaudio.com...
