- Page 1 Comfort Digisystem User Manual SecureStream Technology Microphone DM05 English...
-
Page 2: Table Of Contents
User Manual Table of Contents Page Introduction to the Comfort Digisystem Presenting the Microphone DM05 Functions of the Microphone DM05 Getting Started First Time Use Settings Pairing More Functions Radio Range and Channels Attached Accessories Other original Accessories Trouble Shooting... -
Page 3: Introduction To The Comfort Digisystem
The microphone is extremely discreet and can be simply attached to clothes with a clip. The Microphone DM05 is equipped with a voice AGC (Automatic Gain Control) to maintain a comfortable sound level at all times. -
Page 4: Functions Of The Microphone Dm05
Functions of the Microphone DM05 Charging socket On / Off Hole to secure neck pendant Clips Omnidirectional microphone Function indicator Pairing button Microphone DM05... -
Page 5: Getting Started
Getting Started Charging The Microphone DM05 is chargeable. Charge the DM05 at least two hours before you use it for the first time. An empty battery is fully charged within two hours. During charging, the function indicator shows red. Once the function indicator shows green the unit is fully charged and switches to automatic float charging. -
Page 6: First Time Use
The Microphone DM05 s a microphone for closer range. It works best within approx. 30 cm. Attach the DM05 to your clothes using the clip. The DM05 is supplied with a neck pendant, which can be connected to the unit to make sure that you do not drop it. -
Page 7: Settings
To do this, press the pairing button and hold it down immediately after starting up the unit (within two seconds). A selected mode can always be cancelled by switching off the DM05 and start- ing it up again. Factory Change... -
Page 8: Pairing
The channel and code are now reset to the factory settings. Pair Microphone DM05 must be paired using the pairing button, see section Pairing (via pairing button) Pairing To use a receiver and transmitter together, they must be paired. All transmitters and receivers are default paired at the factory and will work together. - Page 9 The easiest way to get the same code key in the whole Digisystem is to generate a new code key from the combined unit; in that way the built-in receiver gets the same code as the rest of the system. Microphone DM05...
-
Page 10: More Functions
Function indicator (LED) The function indicator shows the unit's status depending on its setting. When the DM05 starts, the function indicator shows which channel is selected (1-10) by flashing green 1-10 times. If another channel has been paired in, this is indicated by the green lamp lighting for four seconds when the unit is started up. -
Page 11: Radio Range And Channels
4. A25 - 780.000 MHz 5. A15 - 784.000 MHz 6. C25 - 790.400 MHz 7. C12 - 795.600 MHz 8. D45 - 802.000 MHz 9. D34 - 806.400 MHz 10. D15 - 814.000 MHz * Factory-set channel Microphone DM05... -
Page 12: Attached Accessories
10. B4 - 861.600 MHz * Factory-set channel In addition to these selectable channels, channels within the frequency range of each DM05 model can be set by means of pairing with other Digisystem units. Attached Accessories Safety neck pendant Charger... -
Page 13: Troubleshooting
There may also be equipment nearby causing interference. Change channel. No sound Check that the transmitter and receiver are set to the same channel. Loud hissing noise (no sound transfer) Check that the units are paired. Microphone DM05... -
Page 14: Service And Warranty
Battery lifetime depends on how the product is used. Contact your point of purchase when it is time to change the battery. You are always welcome to contact us at Comfort Audio if you have any questions. Technical Data... -
Page 15: Important Safety Instructions
9) Protect the power cord from being walked on or pinched particularly at plugs convenience receptacles. and the point where they exit from the apparatus. 10) Only use attachments/accessories specified by Comfort Audio AB. 11) Unplug this apparatus during Iightning storms or when unused for long periods of time. - Page 16 19) Never charge product in closed, unaired spaces such as handbags, cases or other closed storage bags. 20) Only use batteries and power supply specified by Comfort Audio AB. 21) You must not change the battery yourself; please contact your point of purchase.
- Page 17 Microphone DM05...
- Page 18 Microphone DM05...
- Page 19 Microphone DM05...
- Page 20 Manufactured by: Comfort Audio AB Box 154, SE-301 05 Halmstad, Sweden Tel. +46 35 260 16 00 Fax +46 35 260 16 50 info comfortaudio.com www.comfortaudio.com...
