AMT Datasouth Fastmark M4 Series Specifications page 2

All M4s are ready for loading custom PAL applications
All M4s are ready for loading custom PAL applications
PRINTER SPECIFICATIONS INCLUDE:
M4
Printer Model
2,3 ips (typical)
Print Speed
203 dpi (8 dots/mm)
Resolution
203 dpi: PAL, EZPL, DPL
Command Set
San Serif and OCRB with smooth Scaling
Resident Fonts
Font and Barcode
Rotation 0, 90, 180, 270 degrees
Bar Code
Code 39, Code93, Code 128UCC, Code 128
Symbologies
subsets A.B.C., Codabar, Interleaved 2 of 5,
EAN-8, EAN-13, EAN-128, UPC-A, UPC-E,
EAN and UPC 2(5) digits add-on, RSS
2-D Bar Code
PDF-417, DataMatrix
Symbologies
4.09" (104mm)
Max Print Width
40" (1016mm)
Max Print Length
Thermal Transfer and Direct Thermal
Printing Method
Width: 1.0-4.4" (25.4-114mm)
Media Size
Thickness: 2.36-9.84 mil (0.06-0.25mm)
Media Diameter: 4.3" (109mm) OD (max)
Core Diameter: 1" (25.4mm)
Length: 0.4-39" (10-1000mm)
Media Sensor Type Auto sensor calibration
Gap transmissive sensor
Black mark reflective sensor
Ribbon end sensor
Continuous, die-cut, fan-fold, tag
Media Type
Corporate Headquarters
803 Camarillo Springs Road, Suite D,
Camarillo, California 93012
(805) 388-5799 PH
(805) 484-5282 FX
Ribbon Capacity
Memory
Software
Interface
Physical Dimension
Power
Operation Panel
Processor
Enclosure
Environment
Conditions
Safety Regulations
User Option
Accessories
Warranty
www.amtdatasouth.com
Max. Lenght: 984 ft. (300m)
Max. Width: 1" - 4.33" (25.4 - 110mm)
2MB Flash memory, 2MB DRAM
PAL Windows driver
Standard RS-232 (max. 19200 bps) & USB 1.1
9.13" (W) x 11.34" (D) x 6.14" (H) 5.9 lbs
(232mm (W) x 288mm (D) x 156mm (H))
DC 24V, 60W, universal switching power supply
One power switch. Feed button and Pause
button
32-bit RISC CPU
ABS Plastic
Operation: 41° to 104° F (5° to 40°C)
25-85% non-condensing
Storage: -40° to 140° F (-40° to 60°C)
10-90% non-condensing
FCC Class A, CE Class A, UL, CUL
KU-007 plus
External ethernet print server
External roll mount, media OD. 8.4" (214mm)
with 1" or 3" core 3" core label spindle
CD, Ribbon for TT, USB cable and
Quick Start Guide
One year Parts and Labor, Return to Depot
Six months Printhead
Specifications are subject to change without notice.
Charlotte Operation
4216 Stuart Andrew Blvd.,
Charlotte, NC 28217
(704) 523-8500 PH
(704) 525-6104 FX
Part No. 121580 rev. A
