- Page 1 ECO Setting Manual Applicable model: TSP100II U Rev. 1.0...
-
Page 2: Table Of Contents
Contents Introduction ........................ 1 1. Starting the Configuration Utility ..............1 2. ECO Settings ......................3 2-1. Auto Reduction Setting ..................3 2-2. Top Margin to First Line ..................4 2-3. On demand ......................... 5 3. Indicator ........................9 4. Revision History ................. 10... -
Page 3: Introduction
ECO Setting Manual Introduction The TSP100IIU is equipped with an ECO function to help protect the environment while also reducing costs. This manual contains information about the ECO function.(*1) How to set the ECO function and the results of the settings are the same for both the Star line mode and ESC/POS mode. - Page 4 ECO Setting Manual 5 Select an emulation, and then click the OK button. 6 The configuration utility starts and the following dialog box appears. - 2 -...
-
Page 5: Eco Settings
ECO Setting Manual 2. ECO Settings Click the ECO Settings tab on the left side of the dialog box. When changing the settings, be sure to click the Apply Changes button after changing the settings. The changed settings are enabled when the Apply Changes button is clicked. 2-1. -
Page 6: Top Margin To First Line
ECO Setting Manual Receipt length reduction The default setting is Original (no reduction). The printing area can be compressed 50% reduction or 25% reduction lengthwise. Because the size of printed barcodes is not reduced even if the receipt length reduction settings are selected, the receipt length will be longer than the length for the reduction Note ratio when printing data that contains barcodes. -
Page 7: On Demand
ECO Setting Manual 2-3. On demand This function reduces the amount of paper wasted on unnecessary printings by prompting the user to select whether or not to print the data. Enable on demand To enable the on demand function, select the check box. When the on demand function is enabled, the following confirmation dialog box will appear each time data is sent from the computer to the printer. - Page 8 ECO Setting Manual View Save Data The data for canceled printings can be viewed. In addition, to print data that was saved from a canceled printing, perform the following procedure. 1 Click View Save Data. 2 Click Search, specify the search date, and then click the OK button. - 6 -...
- Page 9 ECO Setting Manual 3 The saved data appears. Click Print to print the data. When using the on demand function, check the following information. Caution When the on demand function is enabled, the time that the confirmation dialog box appears may vary according to the printing channel that is used.
- Page 10 ECO Setting Manual When switching from the TSP100IIU to the TSP100U, the ECO settings may not appear Note in the TSP100U configuration utility. If the ECO settings were used for the TSP100IIU, perform the following procedure to reset all of the settings to the default settings, and then use the TSP100U.
-
Page 11: Indicator
ECO Setting Manual 3. Indicator When using the printer with the ECO settings, the percentage of paper saved can be confirmed by enabling this function. 1 Select ECO " Show ECO result from the menu bar. The ECO Indicator dialog box appears. 2 Select the Enabled check box. -
Page 12: Revision History
ECO Setting Manual 4. Revision History Rev. No. Date of Revision Changes Rev. 1.0 Mar. 2010 New release - 10 -... - Page 13 OVERSEAS SUBSIDIARY COMPANIES STAR MICRONICS AMERICA, INC. 1150 King Georges Post Road, Edison, NJ 08837-3729 U.S.A. Tel : (int+1)-732-623-5500 , Fax : (int+1)-732-623-5590 STAR MICRONICS EUROPE LTD. SPECIAL PRODUCTS DIVISION Star House, Peregrine Business Park, Gomm Road, STAR MICRONICS CO., LTD.
