- Page 1 OPERATION MANUAL H6400C Reversible Drill Read and understand all of the instructions and safety information in this manual before operating or servicing this tool. Register this product at www.greenlee.com 99938596 REV 1 © 2010 Greenlee Textron Inc. 3/10...
-
Page 2: Table Of Contents
Super Spool™ is protected by U.S. Patent No. 4548229. All specifications are nominal and may change as design improvements occur. Greenlee Textron Inc. shall not be liable for damages resulting from misapplication or misuse of its products. Super Spool is a trademark of Greenlee Textron Inc. -
Page 3: Important Safety Information
H6400C Reversible Drill IMPORTANT SAFETY INFORMATION SAFETY ALERT Electric shock hazard: This tool is not insulated. When SYMBOL using this unit near energized elec- trical lines: This symbol is used to call your attention to hazards • Use only certified non-conductive... - Page 4 H6400C Reversible Drill IMPORTANT SAFETY INFORMATION Do not disconnect tool, hoses or fittings while the • Remove the chuck key from the chuck before drill- power source is running or if the hydraulic fluid is ing. Operation with the key in the chuck can result hot.
- Page 5 H6400C Reversible Drill IMPORTANT SAFETY INFORMATION Hydraulic oil can cause skin irritation. Procedure for connecting or disconnecting hydraulic hoses, fittings, or components: • Handle the tool and hoses with care to prevent skin contact with hydraulic oil. 1. Move the flow lever on the hydraulic power source to the OFF position.
-
Page 6: Identification
H6400C Reversible Drill Identification 1. Trigger 6. Super Spool™ 2. Chuck 7. Handle 3. Motor Cap 8. Tank Port 4. Serial Number 9. Pressure Port 5. Directional Spool Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 7: Setting The Super Spool
H6400C Reversible Drill Setting the Super Spool™ Installing and Removing Accessories The Super Spool™ allows the tool to be used with either Open-Center or Closed-Center hydraulic systems. Inspect accessories before use. Discard accessories Open-Center Hydraulic System that have cracks, chips or gouges. -
Page 8: Hoses And Fittings
H6400C Reversible Drill Hoses and Fittings Setup 1. Stop the hydraulic power source. Installation and Maintenance 2. Install a drill bit according to the instructions under See publication 99930323, SAE J1273 “Installing and Removing Accessories.” (Hose and Hose Assemblies) 3. Connect the hydraulic hoses according to the Replacement instructions under “Hose Connections.”... -
Page 9: Operation
H6400C Reversible Drill Operation 1. Start the power source. Note: Allow the power source to run for a few minutes to warm the hydraulic fluid. Electric shock hazard: 2. Set the directional control spool to the appropriate This tool is not insulated. When position (forward or reverse). -
Page 10: Maintenance
H6400C Reversible Drill Maintenance Use this maintenance schedule to maximize the tool’s service life. Note: Keep all decals clean and legible. Replace decals Wear eye protection when operating when necessary. Refer to the Specifications and Parts or servicing this tool. -
Page 11: Troubleshooting
H6400C Reversible Drill Troubleshooting Before troubleshooting, determine whether the problem If the problem is in the tool, see the troubleshoot- ing table in this manual. If the problem is in the power is in the tool, the hoses, or the power source. Substitute... - Page 12 800-435-0786 Fax: 800-451-2632 815-397-7070 Fax: 815-397-1865 Canada 800-435-0786 Fax: 800-524-2853 International +1-815-397-7070 Fax: +1-815-397-9247 4455 Boeing Drive • Rockford, IL 61109-2988 • USA • 815-397-7070 • An ISO 9001 Company Greenlee Textron Inc. is a subsidiary of Textron Inc. www.greenlee.com...
