Operating Manual
SPECIFICATIONS AND PARTS
H6400C, H6400C1,
and VSD6400
Reversible Drills
Serial Codes FAB, FJL, and GAY
Read and understand all of the instructions and
safety information in this manual before operating
or servicing this tool.
999 3860.0 REV 3
© 2002 Greenlee Textron
3/02
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Greenlee Fairmont H6400C
Summary of Contents for Greenlee Fairmont H6400C
- Page 1 H6400C, H6400C1, and VSD6400 Reversible Drills Serial Codes FAB, FJL, and GAY Read and understand all of the instructions and safety information in this manual before operating or servicing this tool. 999 3860.0 REV 3 © 2002 Greenlee Textron 3/02...
- Page 2 (later models only) H6400C1 only 47A, 48 H6400C1 Models Only 47 , 48 (H6400C only)
- Page 3 H6400C, H6400C1, and VSD6400 Reversible Drills Parts List—H6400C and H6400C1 UPC No. Key 78-3310- Part No. Description 40584 128546 Handle, Insulated (includes items 2–5) ... 1 40152 103130 Gear ... 1 41809 F020886 Dowel Pin, .125 x .500 ... 1...
- Page 4 H6400C, H6400C1, and VSD6400 Reversible Drills Illustration—VSD6400 Greenlee Textron / Subsidiary of Textron Inc. 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815/397-7070...
- Page 5 H6400C, H6400C1, and VSD6400 Reversible Drills Parts List—VSD6400 UPC No. Key 78-3310- Part No. Description 48759 HANDLE AND MOTOR ASSEMBLY ... 1 43482 138339 HANDLE ASSEMBLY with ORIFICE, BEARINGS and GEAR ... 1 41503 F015305 O-ring, 1/2 x 3/32–90 ... 1...
-
Page 6: Purpose Of This Manual
Greenlee Textron shall not be liable for damages resulting from misapplication or misuse of its products. E-Z Bore and Nail Eater II are registered trademarks of Greenlee Textron. KEEP THIS MANUAL 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815/397-7070... - Page 7 Minimum ... 15.1 l/min (4 gpm) Recommended ... 22.7 l/min (6 gpm) Maximum H6400C and H6400C1 ... 30.3 l/min (8 gpm) VSD6400 ... 45.4 l/min (12 gpm) Filtration ... 10 micron (nominal) Pressure Relief Setting ... 138 bar (2000 psi) Back Pressure (maximum)* ...
- Page 8 H6400C, H6400C1, and VSD6400 Reversible Drills Accessories Accessories for the H6400C, H6400C1, and VSD6400 include a standard chuck, chuck key, and two types of wood-boring bits: Nail Eater II The Nail Eater II bits are made of super-tough heat-treated steel with a patented design cutting angle for smoother starts and reduced cutting loads.
