- Page 1 OPERATION MANUAL REVERSIBLE DRILLS Read and understand all of the instructions and safety information in this manual before operating or servicing this tool. 999 3859.6 © 2000 Greenlee Textron 10/00...
-
Page 2: Table Of Contents
H6400C1 VDS6400 Keep this manual available to all personnel. Replacement manuals are available upon request at no charge. Super Spool™ is a trademark of Greenlee Textron. Other Publications Tool Owners/Users: Specifications and Parts Manuals: Publication 999 3860.0 SAE Standard J1273 (Hose and Hose Assemblies): Publication 999 3032.3... -
Page 3: Important Safety Information
Failure to observe this warning can result in severe injury or death. Greenlee Textron / Subsidiary of Textron Inc. Electric shock hazard: This tool is not insulated. When using this unit near energized electrical lines: •... - Page 4 Parts manual. Failure to observe this warning can result in severe injury or death. Greenlee Textron / Subsidiary of Textron Inc. Do not disconnect tool, hoses or fittings while the power source is running or if the hydraulic fluid is hot.
- Page 5 Emergency stop procedure: 1. Release the trigger. 2. Shut off the hydraulic power source. Greenlee Textron / Subsidiary of Textron Inc. Procedure for connecting or disconnecting hydraulic hoses, fittings or components: 1. Move the flow lever on the power source to the OFF position.
-
Page 6: Identification
Reversible Drills Identification H6400C VSD6400 Greenlee Textron / Subsidiary of Textron Inc. 1. Trigger 2. Chuck 3. Motor Cap 4. Serial Number 5. Directional Spool 6. Super Spool 7. Handle 8. Tank Port 9. Pressure Port 10. Auxiliary Handle (H6400C1 only) 11. -
Page 7: Setting The Super Spool
“C” on the spool is aligned with the letter “C” on the tool handle. Setting the Super Spool Position CLOSED - CENTER Greenlee Textron / Subsidiary of Textron Inc. Installing and Removing Accessories Inspect accessories before use. Discard accessories that have cracks, chips or gouges. -
Page 8: Hoses And Fittings
5. Install dust caps over the ports to prevent contami- nation. Typical Setup Greenlee Textron / Subsidiary of Textron Inc. Setup 1. Stop the hydraulic power source. 2. Install a drill bit according to the instructions under Installing and Removing Accessories. -
Page 9: Operation
Accidental start-up can result in serious injury. Failure to observe these warnings can result in severe injury or death. Greenlee Textron / Subsidiary of Textron Inc. 1. Start the power source. Note: Allow the power source to run for a few minutes to warm the hydraulic fluid. -
Page 10: Maintenance
Accidental start-up can result in serious injury. Failure to observe these warnings can result in severe injury or death. Greenlee Textron / Subsidiary of Textron Inc. Use this maintenance schedule to maximize the tool’s service life. Note: Keep all decals clean and legible. Replace decals when necessary. -
Page 11: Troubleshooting
Tool doesn’t operate. Tool operates slowly or erratically. Greenlee Textron / Subsidiary of Textron Inc. If the problem is in the tool, see the troubleshooting table in this manual. If the problem is in the power source, see the troubleshooting section of the power source instruction manual. -
Page 12: Troubleshooting
Hydraulic fluid level low. Incorrect hydraulic fluid viscosity. Hydraulic fluid dirty. Flow control cartridge not operating properly. Greenlee Textron / Subsidiary of Textron Inc. 4455 Boeing Drive, Rockford, IL 61109-2988 USA Canada Fax: 800/524-2853 PROBABLE REMEDY Check the fluid level. Check for leaks.
