Sena SMH10R User Manual

Low profile motorcycle bluetooth headset & intercom
Hide thumbs Also See for SMH10R:
Table of Contents

Advertisement

Quick Links

SMH10R
Low Profile Motorcycle Bluetooth
Headset & Intercom
900m
980yds Intercom
®
Ultra Slim &
Feather Light
www.sena.com
User's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SMH10R and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sena SMH10R

Summary of Contents for Sena SMH10R

  • Page 1 SMH10R Low Profile Motorcycle Bluetooth ® Headset & Intercom 900m Ultra Slim & 980yds Intercom Feather Light User's Guide www.sena.com...
  • Page 2 These trademarks may not be used without the express permission of Sena. The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Sena is under license. ®...

  • Page 3: Table Of Contents

    7.4 Bluetooth GPS Navigation Pairing ……………………………… 19 4.4 Low Battery Warning ……………………………………………… 11 7.5 Pairing with the Sena SR10 Bluetooth Two-way Radio Adapter … 21 4.5 Checking the Battery Level ……………………………………… 11 8. PAIRING WITH SELECTIVE PROFILE: HFP OR A2DP STEREO …22 5.
  • Page 4 13.3 Intercom and Mobile Phone Call ……………………………… 29 22. FIRMWARE UPGRADE …………………………………………41 13.4 Intercom and GPS ……………………………………………… 30 23. SENA BLUETOOTH CONNECTION CASE STUDIES ………42 13.5 Intercom and Two-way Radio…………………………………… 30 14. THREE-WAY CONFERENCE INTERCOM ……………………31 24. OPERATION QUICK REFERENCE ……………………………50 14.1 Start Three-way Intercom ………………………………………...

  • Page 5: Introduction

    • Bluetooth stereo headset for Bluetooth audio devices such as MP3 players Thank you for choosing the Sena SMH10R, Low Profile Bluetooth • Bluetooth stereo headset for Bluetooth GPS navigation Stereo Headset and Intercom. With the SMH10R, you can call •...

  • Page 6: Package Contents

    SMH10R 2. PACKAGE CONTENTS • Speakers • Headset Main Unit • Attachable Boom Microphone (+) Button / (-) Button • Volume adjustment Speaker Connector • Navigate through voice • Wired Microphone configuration menu Microphone Connector • MP3 Track-forward and track-back...

  • Page 7: Installing The Smh10R On Your Helmet

    3. INSTALLING THE SMH10R ON YOUR HELMET • Velcro Pad for Battery Pack • Double Sided Adhesive Tapes To securely install the main unit of the SMH10R, you can use for Battery Pack Holder the velcro pad or double sided adhesive tape. Please follow the procedure below.
  • Page 8 SMH10R 4. Attach the main unit to the velcro pad of your helmet. 6. Place the speakers in the helmet along with the velcro pads, centered to your ear, in the ear pockets of the helmet. If the helmet has deep ear pockets, you can use the speaker pads to place the speakers closer to your ears.
  • Page 9 SMH10R In the case of the wired microphone, attach the velcro pad for 9. You can attach the battery pack on the inside of your helmet. the wired microphone to the inside of the chin guard for full- Attach the adhesive tape of the velcro pad on the back plate of face helmets.

  • Page 10: Powering On/Off And Charging

    SMH10R You can charge the SMH10R on a helmet by connecting the 4. POWERING ON/OFF AND CHARGING supplied USB power & data cable or cigarette charger. You can use any standard micro-USB cable to charge the SMH10R. 4.1 Powering On Press the Center Button and the (+) Button at the same time for 1 second to power on.

  • Page 11: Low Battery Warning

    SMH10R 4.4 Low Battery Warning 5. VOLUME ADJUSTMENT When the battery is low, the blinking blue LED in stand-by mode turns to red and you will hear mid-tone triple beeps and a voice prompt, “Low battery”. You can easily adjust the volume by tapping the (+) Button or 4.5 Checking the Battery Level...

  • Page 12: Smh10R Configuration Setting

    (8) VOX sensitivity (2) Multipoint pairing (9) Voice prompt (3) Phone selective pairing (10) Sidetone You can set the configuration of the SMH10R by the voice menu (4) Media selective pairing (11) Delete all pairings instructions as below. (5) Speed dial (12) Factory reset 1.

  • Page 13: Mobile Phone Pairing

    SMH10R 6.1 Mobile Phone Pairing 6.3 Phone Selective Pairing Voice Prompt “Phone pairing” Voice Prompt “Phone selective pairing” Factory Default Factory Default To go into mobile phone pairing mode, tap the (+) Button or the (-) To go into phone selective pairing mode, tap the (+) Button or Button until you hear the voice prompt, “Phone pairing”.

  • Page 14: Assigning Speed Dial

    Button to confirm. You will then hear a voice prompt saying you have to tap the Center Button to answer an incoming call. “Cancel”. If any button is not pressed within 1 minute, the SMH10R will exit the configuration menu and go back to stand-by mode.

  • Page 15: Enabling/Disabling Voice Activated Intercom

    “Voice prompt” Button to start an intercom conversation, it is not terminated by 20 Factory Default Enable seconds of silence. After turning the SMH10R off and on, you can start intercom by voice again. Enable / Disable Tap the Center Button You can disable voice prompts by configuration setting, but the following voice prompts are always on.

  • Page 16: Enabling/Disabling Sidetone

    6.10 Enabling/Disabling Sidetone Execute Tap the Center Button Voice Prompt “Sidetone” To restore factory default settings on the SMH10R, tap the (+) Factory Default Disable Button or the (-) Button until you hear the voice prompt, “Factory Enable / Disable Tap the Center Button reset”.

  • Page 17: Pairing The Smh10R With Bluetooth Devices

    MP3, or motorcycle specific Bluetooth GPS, and with a VOX Phone Enable / disable Bluetooth adapter or transmitter such as Sena SR10 or SM10. This VOX Intercom Enable / disable pairing operation is only required once for each Bluetooth device.

  • Page 18: Mobile Phone Pairing

    5. The mobile phone confirms that pairing has completed and the 5. The mobile phone confirms that pairing has completed and the SMH10R is ready to use. You will hear the voice prompt, “Your SMH10R is ready to use. You will hear the voice prompt, “Your headset is paired”.

  • Page 19: Bluetooth Stereo Device Pairing

    If the Bluetooth stereo device is integrated with a mobile phone You can listen to voice instruction from Bluetooth GPS navigation. such as a smartphone, you don’t need to pair the SMH10R with it Some GPS systems use a mobile phone profile (HFP, Hands-Free separately.
  • Page 20 SMH10R will return to stand-by mode. “7.1 Mobile Phone Pairing”. When you do this, the SMH10R thinks the GPS is a mobile phone. But the SMH10R can directly pair an The pairing diagram for multipoint GPS pairing is shown in the additional mobile phone.

  • Page 21: Pairing With The Sena Sr10 Bluetooth Two-Way Radio Adapter

    Please refer to the SR10 user's guide for details. GPS navigation systems. If you pair the SMH10R with an SR10 by multipoint pairing, the SMH10R is able to have two HFP devices at the same time: a mobile phone and the Sena SR10.

  • Page 22: Pairing With Selective Profile: Hfp Or A2Dp Stereo

    A2DP stereo music only or for mobile phone handsfree only. This Wired A2DP Connection instruction is for advanced users who want to pair the SMH10R to their smartphones with only one selective profile: A2DP stereo for music or HFP for phone call. Sena SR10...

  • Page 23: Phone Selective Pairing: Hfp For Phone Call Only

    Bluetooth intercom conversation. SMH10R in the list of devices detected on your phone. 1. Turn on the two SMH10R headsets (A and B) that you would like 4. Enter 0000 for the PIN. Some smart phones may not ask for a to pair with each other.

  • Page 24: Conversation

    Note: The SMH5 cannot participate in three-way or four-way conference intercom with the SMH10R. The SMH5 has a limited capability, and can only manage two-way intercom or with other Sena headset models. Pairing A & C Pairing A & D...

  • Page 25: Function Priority

    Audio/Video Remote Control Profile (AVRCP), so if your Bluetooth Bluetooth stereo music (lowest) audio device also supports AVRCP, you can use the SMH10R to remotely control music playback. You can not only adjust the A lower priority function is always interrupted by a higher priority volume but also use functions such as play, pause, next track and function.

  • Page 26: Mobile Phone Call Making And Answering

    SMH10R 2. To play or pause music, press the Center Button for 1 second 12. MOBILE PHONE CALL MAKING AND until you hear a mid-tone double beep. ANSWERING 12.1 Mobile Phone Call Making and Answering 1. When you have an incoming call, tap the Center Button to answer the call.

  • Page 27: Speed Dialing

    GPS, you may not be able to listen to the GPS voice instruction “Cancel”, and tap the Center Button. If any button is not during the phone call. pressed within 15 seconds, the SMH10R will exit the voice speed dial menu and goes back to stand-by mode. 12.2 Speed Dialing 7.

  • Page 28: Two-Way Intercom

    SMH10R Answer Tap the Center Button or Say “Hello” 13. TWO-WAY INTERCOM Press the Center Button for 2" Reject Press the Center Button for 2" 13.1 Start and End Two-way Intercom Call Use phone keypad 1. You can start a one-on-one intercom conversation with any Speed Dial Press the (+) Button for 3"...

  • Page 29: Voice Activated Intercom (Vox Intercom)

    SMH10R 2. To terminate a one-on-one intercom conversation, single tap the conversation by tapping the Center Button, you have to terminate the intercom conversation manually. Center Button. This will end the intercom conversation. 13.3 Intercom and Mobile Phone Call 1. When you have an incoming mobile phone call during an intercom conversation, you will hear a ring tone.

  • Page 30: Intercom And Gps

    13.4 Intercom and GPS interrupt an intercom conversation but is heard in background. If you pair a Bluetooth GPS to the SMH10R as described in 7.4 of This is useful when you have an intercom conversation with a this user's guide, you can hear the turn-by-turn voice instructions passenger on the back seat and use a two-way radio for group of the GPS while having an intercom conversation.

  • Page 31: Three-Way Conference Intercom

    14.1 Start Three-way Intercom Smart Phone You (A) can have a three-way conference intercom with two other Two-way Radio SMH10R friends (B & C) by establishing two intercom connections Mobile Phone at the same time. While a three-way conference intercom is in Pairing...
  • Page 32 Second Friend First Friend Second Friend 4. Now you (A) and two SMH10R intercom friends (B & C) are 2. Start an intercom conversation with one of the two friends in your having a three-way conference intercom. intercom group. For example, you (A) may start an intercom conversation with intercom friend (B).

  • Page 33: End Three-Way Intercom

    You can have four-way conference intercom with three other 1. Press the Center Button for 1 second until you hear a beep SMH10R users by adding one more intercom participant to the to terminate three-way conference intercom completely. It three-way intercom. While you are having three-way intercom as terminates both intercom connections with (B) and (C).

  • Page 34: End Four-Way Intercom

    GPS during music sharing, the function will be paused. End Four-way Intercom 3. In order to share music, make sure that you update both headsets with the firmware that has the music sharing feature, and enable the EDR setting in the Sena Device Manager.

  • Page 35: Universal Intercom

    1. Turn on the SMH10R and the non-Sena Bluetooth headset you want to pair with. 2. Press and hold the Center Button on the SMH10R for 8 seconds until the blue LED flashes rapidly. You will hear a voice prompt, “Universal Intercom pairing”.

  • Page 36: Three-Way Universal Intercom

    1. You (A) need to be paired with non-Sena Bluetooth headset (B) 3. The other SMH10R (C) may join the intercom conversation by and another SMH10R headset (C) for the three-way conference making an intercom call to you (A).

  • Page 37: Four-Way Universal Intercom

    You may have a couple of other four-way Universal Intercom configurations, 1) your headset (A), a non-Sena Bluetooth headset (B), another SMH10R (C), and a non-Sena Bluetooth headset (D, 2) your headset (A), a non-Sena Bluetooth headset (B), and two other SMH10R headsets (C and D).
  • Page 38 SMH10R 2. The other SMH10R (C) may join the intercom by making an 4. Now two SMH10R headsets (A & C) and two non-Sena Bluetooth intercom call to you (A). headsets (B & D) are connected with the four-way Universal Intercom.
  • Page 39 Universal Intercom. - If the non-Sena headset (that has been paired to the Sena headset) is powered on and is automatically connected, then the multipoint connection of the Sena headset will be deactivated. Therefore, the...

  • Page 40: Three-Way Conference Phone Call With

    Start call be disconnected. In this case, the SMH10R automatically tries to End intercom first Tap the Center Button reconnect the intercom every 8 seconds and you will hear high Press the Center Button for 2"...

  • Page 41: Fault Reset

    The SMH10R will be switched off, and you have to turn the system back on and try again. However, this will not restore the headset to...

  • Page 42: Sena Bluetooth Connection Case Studies

    SMH10R 23. SENA BLUETOOTH CONNECTION CASE STUDIES Case 1 Bluetooth Pairing Procedure Mobile Phone Pairing Multipoint Pairing Intercom Pairing Mobile Phone Bluetooth GPS* Mobile Phone Pairing zumo 220/350/550/660/665, TomTom Rider Usage • Mobile phone: phone call, listening to music • GPS: GPS instruction...
  • Page 43 SMH10R Case 2 Case 3 GPS - Mobile Phone Pairing Bluetooth GPS* Bluetooth GPS* Mobile Phone Mobile Phone Pairing Mobile Phone Pairing Intercom Multipoint Pairing Pairing Mobile Phone Intercom Pairing Bluetooth Pairing Procedure Bluetooth Pairing Procedure Mobile Phone Pairing GPS - Mobile Phone Pairing...
  • Page 44 SMH10R Case 4 Case 5 Mobile Phone Mobile Phone Mobile Phone Mobile Phone Pairing Pairing Mobile Phone Intercom Intercom Mobile Phone Pairing Pairing Bluetooth GPS* Motorcycle Bluetooth Pairing Pairing Audio System* Music Bluetooth Pairing Procedure Bluetooth Pairing Procedure Mobile Phone Pairing...
  • Page 45 SMH10R Case 6 Bluetooth Pairing Procedure Mobile Phone Pairing Mobile Phone Pairing Multipoint Pairing Mobile Phone Intercom Pairing Mobile Phone Bluetooth GPS* Pairing zumo 220/350/550/660/665, TomTom Rider Motorcycle Bluetooth Audio System* BMW R1200RT, K1600GT, K1600GTL Intercom Usage Mobile Phone Music...
  • Page 46 SMH10R Case 7 Bluetooth Pairing Procedure Mobile Phone Pairing Multipoint Pairing Intercom Pairing Mobile Phone Usage Mobile Phone • Mobile Phone: phone call Pairing • SR10: two-way radio, GPS guidance, Radar detecting signal • Intercom SR10 Multipoint Pairing Two-way Radio...
  • Page 47 SMH10R Case 8 Bluetooth Pairing Procedure GPS - Mobile Phone Pairing Mobile Phone Pairing Mobile Phone Pairing GPS - Mobile Phone Mobile Phone Intercom Pairing Mobile Pairing Pairing Bluetooth GPS* MP3 Player Mobile Phone Phone Bluetooth GPS* Pairing Intercom zumo 220/350/550/660/665, TomTom Rider...
  • Page 48 SMH10R Case 9 Bluetooth Pairing Procedure Mobile Phone Pairing Mobile Phone Pairing Mobile Phone Pairing Mobile Phone Multipoint Pairing Mobile Phone Intercom Pairing Pairing Usage • Mobile Phone: phone call • SR10: two-way radio, GPS instruction, Radar detecting signal SM10 SR10 •...
  • Page 49 SMH10R Case 10 Bluetooth Pairing Procedure Mobile Phone Pairing Mobile Phone Pairing Mobile Phone Pairing Mobile Phone Multipoint Pairing Mobile Phone Intercom Pairing Pairing Bluetooth GPS* zumo 220/350/550/660/665, TomTom Rider Usage • Mobile Phone: phone call Multipoint Intercom Pairing • GPS: GPS instruction...

  • Page 50: Operation Quick Reference

    SMH10R 24. OPERATION QUICK REFERENCE Type Description Button Duration Beep Type Description Button Duration Beep Center Button & 1 sec Solid blue Ascending Center Button 5 sec Mid-tone Power-on (+) Button beeps flashing single beep Intercom pairing Basic Center Button &...

  • Page 51: Certification And Safety Approvals

    This product is CE marked according to the provisions of the R&TTE radio communications. However, there is no guarantee that interference Directive (99/5/EC). Hereby, Sena declares that this product is in will not occur in a particular installation. If this equipment does cause...

  • Page 52: Industry Canada Statement

    Bluetooth possible harm to the environment or human health from uncon- SIG, Inc. and any use of such marks by Sena is under license. Other trolled waste disposal, please do not dispose of these products trademarks and trade names are those of their respective owners.

  • Page 53: Safety Information

    SMH10R SAFETY INFORMATION Product Use • In some regions, it is prohibited by law to ride motorcycles or Please ensure that the product is properly used by observing the bicycles while wearing headsets. Therefore be certain to comply warnings and cautions below to prevent any risk and/or damage with all relevant laws in the region before using the product.

  • Page 54: Battery

    SMH10R • Do not use the product near hazardous explosives. When there • In recharging the battery, make sure to use an approved charger are near any explosion hazards, turn off the power and heed any provided by the manufacturer. Use of a non-approved charger regulations, instructions, and signs in the area.

  • Page 55: Product Warranty And Disclaimer

    Here, product warranty extends before using the product. Use of this product will constitute consent to the product only. Sena will not be liable for any loss, damage to this agreement, and forfeiture of rights to all claims. If you do not...

  • Page 56: Warranty Exclusions

    Further, Sena will • Use of the product on the road may cause such risks as fracture, not be liable for any substantial damage not related to the, condition, serious disability, or death.
  • Page 57 In addition to damages which may occur due to the use of the ITSELF AND ITS SUPPLIERS ANY LIABILITY, WHETHER BASED product, Sena will not be liable for damages of the product which IN CONTRACT OR TORT (INCLUDING NEGLIGENCE), FOR occur due to the following events.

  • Page 58: Warranty Service

    Sena will not be liable for any claim for Free-of-charge Service damages related with the product.
  • Page 59 1.3.0 www.sena.com User's Guide for Firmware v5.0...
