Summary of Contents for Alto RMX508DFX
- Page 1 RMX508DFX QUICKSTART GUIDE ENGLISH...
-
Page 3: Box Contents
Connect phantom powered microphones before switching on the +48 Volt phantom power switch. Set the output level of your RMX508DFX at no more than 75%. Set the MAIN level at no more than 50%. In this way you will be able to hear the signal by connecting a pair of headphones or powered speakers. -
Page 4: Front Panel
FRONT PANEL -20dB PAD -20dB PAD -20dB PAD -20dB PAD -20dB PAD -20dB PAD -20dB PAD -20dB PAD -20dB PAD -20dB PAD -20dB PAD -20dB PAD -20dB PAD -20dB PAD -20dB PAD -20dB PAD POWER POWER HI HI HI HI HI HI HI HI HI HI... -
Page 5: Master Section
MASTER SECTION STEREO GRAPHIC EQ: There are two graphic EQs each with 9 adjustable bands; one is for the MAIN mix and the other is for the MONITOR mix. With the faders you can boost or cut the selected frequency by +/-15 dB at the indicated frequencies. -
Page 6: Rear Panel
DSP (DIGITAL SIGNAL PROCESSOR) EFFECTS SELECTOR – Selects the effect that the mixer's internal effects processor will apply to the various channels. Each channel can send different levels of audio to the processor by adjusting their Aux 2/FX Post knobs. FX MUTE –... - Page 7 EFFECTS TO HEAR THE EFFECTS ON A CHANNEL: Use the Effects Selector to choose one of the effects below, adjust the parameter with the Variations Selector, then turn up the Aux 2/FX Post knob for that channel. PRESET DESCRIPTION PARAMETER RANGE Decay time 0.8~1.1s...
- Page 8 AUDIO LINE/MIC CONNECTIONS You can connect unbalanced equipment to balanced inputs and outputs. Simply follow these schematics. Caution: Do not connect the rear panel speaker level ¼” outputs to anything other than a passive loudspeaker. Connecting this output to a line line/Mic level input may damage your equipment.
-
Page 9: Technical Specifications
TECHNICAL SPECIFICATIONS MONO INPUT CHANNELS • Microphone input: Electronically balanced, discrete input configuration • Frequency response: 10Hz to 55kHz, +/–3dB • Distortion: (THD & N) 0.006% at +4dBu, 1kHz • Gain: 50dB (MIC) • SNR: (Signal to Noise Ratio) >90dB •... - Page 12 www.altoprofessional.com MANUAL VERSION 1.2...
