- Page 1 User's Manual 2-CHANNEL DJ MIXER DJM-2 WITH BEAT COUNTER www.altoproaudio.com Version 2.3 September 2005 English...
- Page 3 SAFETY RELATED SYMBOLS Fuse To prevent fire and damage to the product, use only the recommended fuse type as indicated in this CAUTION manual. Do not short-circuit the fuse holder. Before RISK OF ELECTRIC SHOCK DO NOT OPEN replacing the fuse, make sure that the product is OFF and disconnected from the AC outlet.
- Page 4 Nothing else to add, but that we would like to thank all the people that made the LTO DJM-2 2-CHANNEL DJ MIXER WITH BEAT COUNTER, and thank our designers and all the...
-
Page 5: Table Of Contents
TABLE OF CONTENTS 1. INTRODUCTION...........................4 2. FEATURES LIST............................4 3. CONTROL ELEMENTS........................5 3.1 The Top Cover 3.1.1 The CHANNEL Section 3.1.2 The MIC/MAIN Section 3.1.3 The PFL (pre fader level) Section 3.1.4 The LEVEL METER Section 3.1.5 The BPM Section 3.2 The Front Panel 3.2.1 MIC IN Jack 3.2.2 The PHONE OUT Jack 3.3 The Rear Panel... -
Page 6: Introduction
1. INTRODUCTION What a great DJ mixer you have just bought. your DJM 2 is packed with features such as digital beat counter, 2 turn- table inputs, 2 line inputs, microphone input, 2 bands equaliser and replaceable cross-fader just to mention a few. Your DJM 2 is VCA Controlled and it is very easy to operate. -
Page 7: Control Elements
3. CONTROL ELEMENTS 3.1 The Top Cover DJM-2 CHANNEL 1 CHANNEL 2 2-CHANNEL DJ MIXER WITH BEAT COUNTER MIC / MAIN PHONO/LINE PHONO/LINE LEVEL GAIN GAIN MAIN -30dB +15dB -30dB +15dB TREBLE MAIN TREBLE MIC LEVEL MAIN / PFL LEVEL METER... -
Page 8: The Channel Section
3.1.1 The CHANNEL Section -. PHONO / LINE switch CHANNEL 1 This switch is available on both input channels. You shall use the LINE position for all high level audio signals such as CD Players, DAT, MD, etc. You shall use the PHONO PHONO/LINE position to connect the turntables. -
Page 9: The Pfl (Pre Fader Level) Section
3.1.3 The PFL (pre fader level) Section When you connect a headphone to your DJM 2 you have the chance of pre-listen the audio signal before the signal reach the Main output. -. LEVEL control This knob will adjust the level of the headphone signal. LEVEL -. -
Page 10: The Bpm Section
3.1.5 The BPM Section CH 1 CH 2 This is a key and exclusive function in your DJM 2 mixer. What is the Beat Per Minute function/ It simply indicate the "speed" of the music through a 3-digit display. The beats (per minute) of the music are automatically measured by the BPM and then displayed on the 3-digit display. -
Page 11: The Front Panel
3.2 The Front Panel PHONE 3.2.1MIC IN Jack This input will accept any unbalanced low impedance microphone. The functions of the microphone will be controlled by the MIC/MAIN section on the Top Panel. 3.2.2The PHONE OUT Jack This input will accept a standard headphone with a 1/4" stereo jack. 3.3.The Rear Panel UK / AUST USA / Canada... -
Page 12: Ac Inlet And Fuse Holder
3.3.1 AC Inlet and Fuse Holder This connector is meant for the connection of the supplied power cord. Please check the Voltage accepted by the unit and the Voltage available from your AC sockets before connecting the unit to the Mains. 3.3.2 POWER Switch This switch turns the Mixer ON and OFF. -
Page 13: Technical Specifications
4. TECHNICAL SPECIFICATIONS INPUTS Phono Inputs 1 and 2 48dB gain@1kHz,unbalanced Line Inputs 1 and 2 8dB gain, unbalanced Mic Input 58dB gain, servo balanced OUTPUTS Headphones typically 125mW@ 1% THD Main Out max +21dBu Tape Out typically 0dBu GENERAL Stereo Bass +15dB/ 30dB Stereo Treble... -
Page 14: System Block Diagram
5. SYSTEM BLOCK DIAGRAM... -
Page 15: Warranty
6. WARRANTY 1. WARRANTY REGISTRATION CARD To obtain Warranty Service, the buyer should first fill out and return the enclosed Warranty Registration Card within 10 days of the Purchase Date. All the information presented in this Warranty Registration Card gives the manufacturer a better understanding of the sales status, so as to purport a more effective and efficient after-sales warranty service. - Page 16 No. 1, Lane 17, Sec. 2, Han Shi West Road, Taichung 40151 Taiwan http://www.altoproaudio.com Tel: 886-4-22313737 email: alto@altoproaudio.com Fax: 886-4-22346757 All rights reserved to ALTO. All features and content might be changed without prior notice. Any photocopy, translation, or reproduction of part of this manual without written permission is forbidden. Copyright...
