STAINLESS STEEL NATURAL GAS GRILL
MODEL NO.: 730-0337
Jenn-Air is a Trademark of the Maytag Corporation and is used under license to Lowe's Companies, Incorporated.
FOR OUTDOOR USE ONLY
PLEASE CONTACT 1-800-554-5799 FOR ASSISTANCE
DO NOT RETURN TO PLACE OF PURCHASE
ITEM NO: 27043
300
4 00
50 0
600
20 0
100
8 00
700
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 730-0337 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Jenn-Air 730-0337

Summary of Contents for Jenn-Air 730-0337

  • Page 1 STAINLESS STEEL NATURAL GAS GRILL MODEL NO.: 730-0337 ITEM NO: 27043 Jenn-Air is a Trademark of the Maytag Corporation and is used under license to Lowe’s Companies, Incorporated. ® 4 00 50 0 20 0 8 00 FOR OUTDOOR USE ONLY...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS SECTION ONE SECTION FIVE Safety Instructions Exploded View Placement of the Grill Parts List 24-25 SECTION TWO SECTION SIX Side Shelf & Side Burner Assembly Grilling Hints Spice Tray Assembly Grill Cooking Chart 26-28 Side Burner Hose Quick-Connect Grill Recipe Suggestions 29-30 Side Shelf Handle &...

  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS RECOGNIZED SAFETY SYMBOLS, WORDS AND LABELS WARNING WARNING Do not try lighting this appliance without first reading the “LIGHTING INSTRUCTIONS” section of this manual. WARNING – Hazards or unsafe practices which COULD result in severe personal injury or death. WARNING Spiders and insects can nest inside the burners of CAUTION...
  • Page 4 SAFETY INSTRUCTIONS WARNING WARNING Do not use the grill if the odor of gas is Failure to properly place the burner over the present. Contact customer service at 1-800- orifice could cause a fire to occur behind and 554-5799. beneath the valve panel, thereby damaging the grill and making it unsafe to operate.
  • Page 5 SAFETY INSTRUCTIONS USING THE SIDE BURNER WARNING Inspect the gas supply hose prior to turning on Do not attempt to light the grill if gas odor is the gas. If there is evidence of cuts, wear or present. Contact customer service at 1-800-554- abrasion, it must be replaced prior to use.
  • Page 6 SAFETY INSTRUCTIONS WARNING The grill is not intended to be installed in or on Do not try lighting this appliance without first reading recreational vehicles and/or boats. the “LIGHTING INSTRUCTIONS” section of this manual. Children should not be left alone or unattended in an area where the grill is being used.

  • Page 7: Placement Of The Grill

    Do not use briquettes of any kind in the grill. Clean the grill with caution. To avoid steam burns, The 730-0337 natural gas grill is designed for do not use a wet sponge or cloth to clean the grill optimum performance without the use of briquettes.

  • Page 8: Side Shelf & Side Burner Assembly

    SIDE SHELF ASSEMBLY Estimated Assembly Time: Approximately 10 minutes. Required Tools: Phillips Screwdriver (not included) 1. Open the grill lid and remove the side shelf from the fire box. 2. The screws used to attach the side shelf are already screwed into the side panels of the grill cart. Remove the screws from the side panels.

  • Page 9: Spice Tray Assembly

    SPICE TRAY ASSEMBLY Mount the tabs on the spice tray into the holes on the left door of the grill. 10 0...

  • Page 10: Side Burner Hose Quick-Connect

    SIDE BURNER HOSE QUICK-CONNECT Estimated Assembly Time: Approximately 5-7 minutes Required Tools: Phillips Screwdriver 1. Insert the side burner hose with female sleeve through side panel of cart (Top drawing). 2. Push the sleeve of the female socket back and insert the male end of connector. Release the sleeve. 3.

  • Page 11: Side Shelf Handle & Battery Installation

    SIDE SHELF HANDLE ASSEMBLY Estimated Assembly Time: Approximately 5-7 minutes Required Tools: Phillips Screwdriver (not included) 1. Remove the four side shelf handle screws from the side shelf. 2. Align the holes in the handle with the holes in the side shelf. 3.

  • Page 12: Installation Of Natural Gas Regulator

    BRAKING SYSTEM OPERATION 1. Push to the right to lock. 2. Push to the left to unlock. 60 0 80 0 INSTALLATION OF NATURAL GAS REGULATOR 1. Connect the PVC Natural Gas Hose to the house gas supply line using the quick-connect fitting as shown in figure A.

  • Page 13: Gas Hook Up & Leak Testing

    Total 77,000 BTU/Hr. Total gas consumption (per hour) of the 730-0337 The installation of this appliance must conform with Natural gas grill with all burners set on “HI”: local codes or, in the absence of local codes, with the National Fuel Gas Code ANSI Z223.1 and the...

  • Page 14: Installer Final Check

    INSTALLER FINAL CHECK The unit has been tested and is free of leaks. Specified clearance maintained of 24 inches The gas supply shut off valve has been located. from combustible materials/construction. All burners are factory installed. All internal packaging has been removed. Keep the instruction manual with the grill for The hose and regulator are properly connected.

  • Page 15: Operating Instructions

    OPERATING INSTRUCTIONS GENERAL USE OF THE GRILL AND ROTISSERIE Each main burner is rated at 13,000 BTU/Hr. The local codes, with the National Electrical Code, main grill burners encompass the entire cooking ANSI/NFPA 70. area and are side ported to minimize blockage from After its first use, the stainless steel adjacent to the falling grease and debris.

  • Page 16: Lighting Instructions

    NOTE Adjust the counter balance weight to balance the It is normal for the skewer to flex when larger cuts heavier side of the meat and avoid lopsided rotation of meat are being cooked. of the rotisserie motor. If the meat scrapes on the cooking grids during any CAUTION part of the rotation, the cooking grids must be When using the rotisserie burner, remove the...

  • Page 17: Lighting Illustrations

    LIGHTING ILLUSTRATIONS MAIN BURNER LIGHTING ROTISSERIE BURNER & SEARING SIDE BURNER LIGHTING Open the top cover or lid 1. Push and turn rear burner knob slowly to “IGNITE / ON” setting, hold in until th burner is lit up, continue to press and hold for 15 seconds and release.

  • Page 18: To Match Light The Grill

    TO MATCH LIGHT THE GRILL If the burner will not light after several attempts using the control knobs, the burner may be lit with a match. 1. If you have already attempted to light the burner with the igniter, wait 5 minutes for any accumulated gas to dissipate.

  • Page 19: Grill Lights

    GRILL LIGHTS Light Operation Instruction 1. Make sure light’s power switch on the control panel is in the “OFF” position. 2. Connect power plug to properly grounded outlet. 3. Turn the light’s power switch to “ON”. WARNING Keep any electrical supply cord away from any heated surface.
  • Page 20 5. Use a screwdriver to loosen the two screws locking the bulb. Pull out the light bulb and replace with a new bulb. 6. Reverse the instruction from steps 5-1 for installation. Cleaning Method Follow steps 1-4 above for glass cover removal. Use a damp towel to clean the surface of glass cover.

  • Page 21: Using The Side Burner

    USING THE SIDE BURNER 3. If the burner does not light within 4 seconds, turn the control knob to the “OFF” position. Inspect the gas supply hose prior to turning on the gas. If there is evidence of cuts, wear or abrasion, it must be replaced prior to use.

  • Page 22: Care And Maintenance Of Side Burner

    CARE & MAINTENANCE OF SIDE BURNER BURNER CLEANING STAINLESS STEEL Clean the exterior of the burner with a wire brush. There are many stainless steel cleaners Clear any clogged burner ports with a straightened available. Always use the mildest cleaning paper clip.

  • Page 23: Care And Maintenance Of The Grill

    CARE & MAINTENANCE OF THE GRILL STAINLESS STEEL GRILL BURNERS Extreme care should be taken when moving a Grease specks can gather and bake onto the burner. It must be correctly centered on the orifice surfaces of the stainless steel, giving the before any attempt is made to relight the grill.

  • Page 24: Troubleshooting

    TROUBLESHOOTING WHEN TO LOOK FOR SPIDERS You should inspect the burners at least twice a WARNING year or immediately after any of the following Spiders and insects can nest inside the burners conditions occur: of the grill and disrupt gas flow. This very dangerous condition could cause a fire behind 1.

  • Page 25: Exploded View

    EXPLODED VIEW MODEL 730-0337 42( A) 42( B) 42( D ) 42( C )

  • Page 26: Parts List

    PARTS LIST M odel No. 730-0337 REF# DESCRIPTION Q’TY REF# DESCRIPTION Main Lid Front Trim Panel, Right Temperature Gauge Warming Rack Logo Cooking Grid With Hole Temperature Gauge Heat Insulating Flame Tamer spacer Main Lid Handle Heat Insulating Cover Main Burner Main Lid Handle Main Burner Igniter Wire (A.B.C.D)
  • Page 27 REF# DESCRIPTION Q’TY REF# DESCRIPTION Side Burner Grease Tray Wheel Axle Side Burner Orifice Brass Connector Axletree Base Side Burner Flex Gas Wheel Side Burner Gas Valve Lighting Rod Side Burner Control Panel Lighting Rod Cover Foot Brake Hardware...

  • Page 28: Grilling Hints

    GRILLING HINTS This Jenn-Air grill has an infrared side burner – It is recommended that meat be defrosted overnight commonly referred to as a “searing” burner. This in the refrigerator as opposed to a microwave. This type of burner produces extreme heat that can be generally yields a juicier cut of meat.
  • Page 29 FOOD WEIGHT FLAME APPROXIMATE SPECIAL OR THICKNESS SIZE TIME INSTRUCTIONS AND TIPS MEATS BEEF Hamburgers 1/2 to 3/4 inch Medium 10 to 18 minutes Grill, turning once when juices rise to the surface. Do not leave hamburgers unattended. A flare-up could occur quickly.
  • Page 30 FOOD WEIGHT FLAME APPROXIMATE SPECIAL OR THICKNESS SIZE TIME INSTRUCTIONS AND TIPS Breasts Medium 30 to 45 minutes Marinate with Italian dressing well-done FISH AND SEAFOOD Steaks Grill, turning once. Brush with Halibut 3/4 to 1 inch Medium to 8 to 15 minutes Melted butter, margarine or oil Salmon High...

  • Page 31: Grill Recipe Suggestions

    GRILL RECIPES seafood. Toss to coat. Cover, tender. Let stand 5 minutes before BBQ SALMON refrigerate 2 hours. serving. 2 large salmon steaks 2 tbs. oil BARBECUED LONDON BROIL Salt & pepper 4 to 6 servings 2 oz. thin bacon slices Half-hour before cooking, turn the ¾...
  • Page 32 Pound flank steak to ¼ inch thickness or Roast eggplant on gas grill over flatten chicken breasts. Mix oil, limejuice medium flame, turning occasionally PORK ROAST and seasonings in a zip lock bag. Add until thoroughly cooked. This may take Apple cider vinegar basting sauce: meat and shake bag to coat the meat.

  • Page 33: Limited Warranty

    Our telephone number is 1-800-554-5799, fax number 1-800-598-8829. Please direct all correspondence to: Nexgrill Industries, Inc. 280 Machlin Court, City of Industry, California, 91789, ATTN: Warranty Service Center. *Jenn-Air is a trademark of the Maytag Corporation and is used under license to Lowe’s Company Inc. Printed in China.
