2. Installation of the Link Gate ISDN

In this chapter we will see how to install the gateway in your telephone installation.
2.1 Installation step by step, for SIM cards and cables
a. Insert SIM card
Carefull with PIN code
Check as a preliminary if the SIM cards are protected by PIN code, if such is the case, you can use the
software provided to program the PIN codes. (See 3.1.1. page 12) before inserting the cards.
With a pencil or similar push the yellow button on the card holder to extract it, then install on the holder
the card as bellow and replace it.
Figure 1
b. Connection of antennas
Figure 5
c. Connection of Bri to the Link Gate ISDN
Figure 6
Ce document est la propriété de Linkcom.
Toute reproduction même partielle est strictement interdite
Figure 2
classe
classement
LGISDNeng 6.5
DR
Figure 3
numéro
002.02
Figure 4
date
page
09/11/04
5/22
